- Page 1 RANGEHOOD & INSTALLATION GUIDE DBH1200 www.schweigen.com.au Revision V2 18/10/23...
- Page 2 Cleaning & Maintenance Cleaning the Interior Cleaning the Exterior Baffles Installation Rangehood Size vs Cooktop Size BBQ Installation Mounting Instructions – Outdoor/Alfresco DBH1200 Wall Mount Installation Ducting Ducting Advice Roof Cowls/Roof Seal Kit Troubleshooting Troubleshooting Service 8. Specifications DBH1200 Dimensions...
- Page 3 The guide contains important information on the use and maintenance of the unit, as well as important safety notes. This will ensure your personal safety and the lasting value of your rangehood. We trust that you will enjoy your new Schweigen rangehood. Please always retain your proof of purchase to aid in any warranty queries.
- Page 4 2. Important Safety Information WARNING Please read this section thoroughly before attempting to operate the appliance. Inspect your product upon receipt. Any damage or defects MUST be reported within 48 hours, or no claim will be recognised. DO NOT INSTALL THIS APPLIANCE IF YOU FIND IT DAMAGED. If this product is installed damaged, neither the supplier, nor the retailer, will be responsible for the costs associated with the repair, replacement, removal or re-installation of the appliances.
-
Page 5: Before Installation
1. We recommend this appliance be installed or repaired by an experienced Home Appliance technician. 2. Please see our website www.schweigen.com.au for experienced installers. 3. It is dangerous to modify any part of this appliance. Modification of any kind, will immediately void the warranty. -
Page 6: Product Use
2. Important Safety Information Product Use This product is designed for household use and should not be used for commercial applications. After use, always ensure that all controls are in the “OFF” position. When frying with a gas flame, take particular care not to allow the oil or grease in the pan to catch fire. -
Page 7: Range Hood
3. Description Rangehood 1. Mounting Bracket 2. Flue 3. Socket lead for Isodrive motor ® 4. Main Power Cord 5. Rangehood Body 6. Baffles 7. Lights 8. Remote Control NOTE: Baffle and light quantity may vary from model to model. Page 7... -
Page 8: Remote Control
4. Operation Remote Control Starting the rangehood for the first time using the remote control: Put the safety switch ON (this switch is inside the main rangehood). Wait about 5 seconds for the circuit to test the memory. The rangehood has a 4-speed remote control device. The buttons have the following functions (valid for all rangehood models with remotes): A. -
Page 9: Synchronisation Of The Remote Control With The Rangehood
_n_. _RH Section_ 4. Operation Synchronisation of the Remote Control with the Rangehood If the remote control fails or the batteries run out, disconnect the rangehood using the safety switch inside the rangehood (which can be accessed from one of the s) and replace the batteries, then synchronise the remote. -
Page 10: Cleaning The Interior
5. Cleaning & Maintenance _n_. _LH Section_ Warning Always switch off and disconnect power before cleaning. Cleaning the Interior Clean the interior of the rangehood with a damp cloth and a neutral detergent. NOTE: Do not use denatured alcohol on the exterior of the rangehood. Do not clean the electric parts or the motor with liquids or solvents Cleaning the Exterior We recommended using a soft cloth, water and a liquid soap, rinsing it well and then drying it thoroughly. - Page 11 5. Cleaning & Maintenance _n_. _RH Section_ Baffles For this appliance to function effectively, regular maintenance is a must. • The function of the baffle is to collect the grease particles given off during cooking. • Clogged heavy oil deposits restrict airflow and may cause the motor to overheat and become a fire hazard.
-
Page 12: Bbq Installation
6. Installation Rangehood Size vs Cooktop Size In addition to the size, the height of the rangehood above the cooktop is important to obtain the best performance. INADEQUATE ADEQUATE OPTIMAL Rangehood smaller than Rangehood same size as Rangehood larger than cooking zone cooking zone cooking zone... - Page 13 *IMPORTANT: If the user decides to install the rangehood at a distance of less than minimum height above the cooking surface, Schweigen declines responsibility for damages suffered by the rangehood due to excess heat or damage to objects, people and others caused directly or indirectly by a malfunction, breakage or fire.
-
Page 14: Wall Mount Installation
6. Installation _n_. _LH Section_ Wall Mount Installation There are two primary mounting points and several secondary mounting points to firmly fix the rangehood in place. Suitable fixing screws must be used to mount the appliance on a secure surface. Please ensure that the holes for the two primary mounting points are level before installation. -
Page 15: Faulty Installation
Isodrive motor. Faulty Installation It is not the responsibility of Schweigen to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault. - Page 16 6. Installation Step 3 Place flue covers on the rangehood. (Be careful not to scratch the top of the rangehood). PLEASE NOTE: Only a standard length of stainless steel flue is provided. Any additional length will need to be sourced and manufactured by a sheet metal fabricator.
- Page 17 _n_. _RH Section_ 6. Installation Ducting Please DO NOT crush or kink the ducting. 1. Crushed or kinked ducting creates sharp corners that creates turbulence. This reduces the size and efficiency of the ducting, lowers extraction and may cause excessive noise. 2.
- Page 18 6. Installation _n_. _LH Section_ Ducting Advice Straight ducting is the most effective installation Keep the curves or bends to a minimum. If they do exist, try to keep the angles as open as possible. Never reduce flue diameter right next Never fit reductions next to curves or bends in to the rangehood outlet fitting.
-
Page 19: Roof Cowls / Roof Seal Kit
6. Installation Roof Cowls / Roof Seal Kit WARNING All electrical wiring should be kept inside the roof space. 1. Roof Cowls (Not supplied)* 2. Ducting must be pulled taut. DO NOT crush or kink the ducting. 3. Connect ducting to the outlet on rangehood using a ring clamp. - Page 20 7. Troubleshooting Before you contact the technical service department, make sure that the product is plugged in and power is supplied. • Do not take any action that will damage the product. IMPORTANT Never attempt to repair this appliance by yourself. Always refer to a qualified Service Technician.
- Page 21 0800 200 510 Faulty Installation It is not the responsibility of Schweigen to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault. Should the appliance be installed in such a way that the service agent is unable to gain access to the appliance, the person/s who own the premises or the property where the appliance resides —...
-
Page 22: Technical Specifications
8. Specifications Dimensions 1200 *All dimensions are in millimetres Technical Specifications Model DBH1200 Feeding Voltage 220–240V 50Hz Light Power (W) 3 x 2.1W Page 22... - Page 23 All information supplied is to be used for general reference purposes only and is on the understanding that Schweigen will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only.
- Page 24 Australia Unit 4/1-5 Lake Drive, Dingley Village, Victoria 3172. Phone 1300 881 693 Email sales@schweigen.com.au Web www.schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz...
