homed JLN-S0 A Series User Manual

Shenzhen Homed Medical Device Co.,Ltd
1 Description and Intended use
Dear Client,
First of all we wish to thank you for choosing our products and congratulate you on your choice of JLN-S0xA
series piston compressor nebulizers, which are easy-to-use and extremely reliable. They are a kind of compact
medical devices designed to efficiently convert the medication suspension or high concentration medicine
solutions into an aerosol of microscopic droplets and deliver them into the bronchus and lungs. It is intended for
use in the treatment of asthma, COPD and other respiratory diseases for which an aerosolized medication is
required during therapy. The device is for pediatric and adult population, and wildly used in hospitals and health
care institutions.
The user manual is suitable for models of JLN-S01A, JLN-S02A, JLN-S03A, JLN-S04 A, JLN-S05A,
JLN-S06A, which have the same intended use and technical specifications, only the shape of enclosures are
different.
2 Warnings and Precautions
Warnings
- For type, dose and regime of medication follow the instructions of your physician or licensed healthcare
practitioner.
- Do not modify this equipment without authorization of the manufacturer.
- Do not cover the compressor with a blanket, towel, or any other type of cover during use, which could result in
the compressor overheating or malfunctioning.
- Do not use the device in anesthetic breathing systems or lung ventilator breathing systems.
- The device is not compatible with the use of oxygen and oxygen mixtures, and is not compatible between
oxygen and administrated drugs.
- Do not use the device where it may be exposed to flammable gas or vapors.
- Provide close supervision when this device is used by, on or near infants, children or compromised individuals.
- Keep the device out of the reach of unsupervised infants, children and physiological disable people.
- Do not insert any object into the compressor.
- Do not block the air filter cover.
- Do not add more than 8ml of medication to the medication cup.
- Do not operate the device if the motor is at temperature greater than 120℃.
- Do not use the device if the solution temperature greater than 40℃ when used in the max flow rate.
- Do not dismantle or attempt to repair the device or components.
- Use only HOMED authorized parts and accessories, parts and accessories which are not approved for use with
the device may damage the unit.
- Do not immerse the main unit in water or other liquid.
- Do not use the device for transposable use with solutions.
- Do not leave the cleaning solution in the medication cup, rinse the nebulizer parts with clean water and dry it
after disinfecting.
- Do not use the nebulizer parts if the package is broken at first use, change another one.
User Manual
Piston compressor Nebulizer
File No.: JLN-S0XA-CE-14
Serial number: REFJLN-S0XA
Issued date: 2014-10 -12
Version: A/0
Page 1 of 10
