Phoenix Contact EV-T2M3SE24-3AC32A-07M60E10 Manual

EV-T2M3SE24-3AC32A-0,7M6,0E10 - Infrastructure
charging socket
1405216
https://www.phoenixcontact.com/us/products/1405216
Please be informed that the data shown in this PDF document is generated from our online catalog. Please find the complete data in the user
documentation. Our general terms of use for downloads are valid.
Product description
Infrastructure charging socket for charging electric vehicles (EV) with alternating current (AC), compatible with type 2 Infrastructure Plugs, for
installation at charging stations for E-Mobility (EVSE)
Your advantages
• Complete product range
• Uniform, space-saving installation space
• Available with your logo on request – for consistent branding of your charging station
• Integrated interlock during charging
• Manual emergency release of the locking actuator
• Developed and produced in accordance with the IATF 16949 automotive standard and ISO 9001
Commercial data
Item number
Packing unit
Minimum order quantity
Note
Sales key
Product key
Catalog page
GTIN
Weight per piece (including packing)
Weight per piece (excluding packing)
Customs tariff number
Country of origin
Arrow.com.
Downloaded from
CHARX connect, Infrastructure charging socket, for charging electric vehicles (EV) with
alternating current (AC), Type 2, IEC 62196-2, 32 A / 480 V (AC), Single wires, length: 0.7 m,
locking actuator: 24 V, 4-pos., Rear panel mounting, PHOENIX CONTACT logo
1405216
1 pc
1 pc
Made to order (non-returnable)
EM01
XWBADC
Page 36 (C-7-2019)
4046356738491
656.4 g
0.56 g
85444290
DE
