- Page 1 RAZER BLACKSHARK V2 MASTER GUIDE...
- Page 2 If esports is everything, give it your all with the Razer BlackShark V2. Introducing a triple threat of amazing audio, superior mic clarity, and supreme sound isolation. Fitted with titanium-coated drivers, a USB sound card, softer ear cushions and THX Spatial Audio, your time to turn pro is now.
-
Page 3: Table Of Contents
2. LET’S GET YOU COVERED ........................5 3. TECHNICAL SPECIFICATIONS ........................6 4. CONNECTING THE HEADSET ........................7 5. USING THE RAZER BLACKSHARK V2 ....................... 9 6. CONFIGURING YOUR RAZER USB SOUND CARD ..................12 7. SAFETY AND MAINTENANCE ........................26 8. LEGALESE ..............................27 ™... -
Page 4: What's Inside / What's Needed
1. WHAT’S INSIDE / WHAT’S NEEDED WHAT’S INSIDE ▪ Razer BlackShark V2 Adjustable padded headband Ultra-soft memory foam ear cushions 3.5 mm audio + mic jack Volume control knob Mic mute button ▪ Removable Razer HyperClear cardioid mic ▪ USB sound card ▪... - Page 5 PRODUCT REQUIREMENTS ▪ Devices with a free USB port ▪ Devices with 3.5 mm audio + mic combined jack* RAZER SYNAPSE REQUIREMENTS ▪ Windows® 10 64-bit (or higher) ▪ Internet connection for software installation *Compatible with PC / Mac / Switch / PS4 / Xbox One (Xbox One Stereo Adapter may be required, purchased separately).
-
Page 6: Let's Get You Covered
2. LET’S GET YOU COVERED You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com Your product’s serial number can be found here. -
Page 7: Technical Specifications
3. TECHNICAL SPECIFICATIONS HEADPHONES ▪ Frequency response: 12 Hz - 28 KHz ▪ Impedance: 32 Ω @ 1 KHz ▪ Sensitivity (@1kHz): 100 dB SPL / mW,1KHz ▪ Drivers: Customized Dynamic 50 mm Driver ▪ Inner ear cup diameter: 65 mm x 40 mm / 2.56 in x 1.57 in ▪... -
Page 8: Connecting The Headset
4. CONNECTING THE HEADSET TO YOUR PC VIA USB PORT 1. Plug your headset to the USB Sound Card, and then to your PC. 2. On your PC, right-click on the sound icon on the system tray, and then select Open Sound settings. - Page 9 3. On the Sounds window, set Razer USB Sound Card as the default Output and Input device. TO OTHER DEVICES VIA USB PORT Plug your Razer BlackShark V2 to the Razer USB Sound Card*, and then to your device. Make sure the Razer USB Sound Card is set as the default input and output device.
-
Page 10: Using The Razer Blackshark V2
5. USING THE RAZER BLACKSHARK V2 USING THE MICROPHONE Plug the Razer™HyperClear Cardioid Mic to the headphone, then bend until it is parallel to your mouth. Make sure the mic diaphragm is in front and the air vent is facing away from your mouth. - Page 11 ADJUSTING THE VOLUME Rotate the volume control knob as shown below to increase or decrease the volume. Increase volume Decrease volume EXTENDING YOUR HEADSET’S LIFESPAN We recommend stretching the headset gently apart before placing them over your head to minimize headband stress.
- Page 12 ACTIVATE THX SPATIAL AUDIO Unleash the full potential of your Razer BlackShark V2 by enabling 360° positional audio for a natural and lifelike experience through Razer Synapse. ™ F O R G AM E RS . BY G A ME R S .
-
Page 13: Configuring Your Razer Usb Sound Card
SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse. This tab allows you to navigate the Dashboard subtab. Dashboard The Dashboard subtab is an overview of your Razer Synapse where you can access all your Razer devices, modules, and online services. - Page 14 Modules The Modules subtab displays all installed and available modules for installation. ™ F O R G AM E RS . BY G A ME R S .
- Page 15 Global Shortcuts Bind operations or Razer Synapse functions to custom key-combinations from any Razer Synapse- enabled device inputs which apply across all device profiles. Learn more about Profiles Only Razer Synapse-enabled device inputs will b e recognized. ™ F O R G AM E RS . BY G A ME R S .
- Page 16 The Audio tab is the main tab for your Razer USB Sound Card. From here, you can customize your device’s settings to unleash its full potential. Changes made under this tab are automatically saved to your system and cloud storage.
- Page 17 Sound Properties Set a default output device that the THX Spatial Audio will use when the Razer USB Sound Card is not connected. You may also click on the Windows Sound Properties link to manage the sound settings of your system such as modifying the playback and recording device settings, sound scheme and default communications activity.
- Page 18 MIXER The Mixer subtab allows you to enable or disable the THX Spatial Audio and its settings, as well as calibrate the audio positioning of all virtual speakers of the active spatial audio mode. THX Spatial Audio THX Spatial Audio technology is an advanced positional audio solution that delivers a heightened, immersive experience as you game.
- Page 19 On any Custom Mode, click on the miscellaneous button ( ) to rename, duplicate, or delete the selected custom mode. To revert the current mode to its original settings, click on the Reset button. ENHANCEMENT The Enhancement subtab is for customizing the incoming audio settings and frequency response of your audio system.
- Page 20 Audio Equalizer Select any of the available equalizer presets created for the best audio experience designed for balance, gaming immersion, movie viewing, or enjoying your favorite music. Manually adjusting any equalizer preset will automatically set it to Custom. The Mic subtab enables you to change the settings for all outgoing mic audio. Microphone Control the mic volume and amount of mic input for a clearer mic audio.
- Page 21 Mic Boost Enable this feature to further amplify the mic volume. Voice Gate Control the amount of mic input so that it cuts out background noises and isolates your voice. Any sound that registers below the threshold will be muted. Enhancements Improve the quality of the microphone by enabling any of the listed features below: ▪...
- Page 22 PROFILES TAB The Profiles tab is a convenient way of managing all your profiles and linking them to your games and applications. Devices View which games are linked to each device’s profiles or which Chroma Effect is linked to specific games using the Devices subtab.
- Page 23 ™ F O R G AM E RS . BY G A ME R S .
- Page 24 You can also sort games based on alphabetical order, last played, or most played. Added games will still be listed here even if it is not linked to a Razer device. To link games to connected Razer devices or Chroma Effects, simply click on any game from the list, and then click Select a device and its profile to launch automatically during gameplay to select the Razer device or Chroma Effect it will link with.
- Page 25 Reset tab The Reset tab allows you to perform a factory reset on all connected Razer devices with on-board memory and/or reset Razer Synapse tutorials to acquaint yourself again with Razer Synapse’s new features on its next launch.
- Page 26 The About tab displays brief software information, copyright statement and provides relevant links for its terms of use. You may also use this tab to check for software updates, or as a quick access to Razer’s social communities. ™ F O R G AM E RS . BY G A ME R S .
-
Page 27: Safety And Maintenance
7. SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer BlackShark V2, we suggest that you adopt the following guidelines: Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com... -
Page 28: Legalese
Product. In no event shall Razer’s liability exceed the retail purchase price of the Product.
