Aerpro AM7X User Manual

Multimedia receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MULTIMEDIA RECEIVER
Wireless Apple CarPlay & Android Auto
USER MANUAL
Android Auto and Apple CarPlay is not owned or controlled by any car manufacturer and are not respon-
sible for the privacy practices of third parties or the terms and conditions under which they offer such
products. We strongly encourage you to read the Android Auto or Apple CarPlay privacy policies and
terms and conditions to make sure they are acceptable to you.
INCLUSIONS: Head Unit, GPS Antenna, Microphone, Wiring Harness,
DISCLAIMER: We recommend using an Authorised Dealer that offers an installation service
to install this product. Never cut or modify a harness as this could damage the head unit and
vehicle, as well as void the warranty of the product.
AM7X
Android Auto, Google Play, Android, are registered trademarks of
Google, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Apple, Apple Car Play, Apple iPhone, Apple Music and Siri are registered
trademarks of Apple, Inc.
Audio-Video Lead, Plastic Trim & Screws
TM

Advertisement

Table of Contents
loading

Related Manuals for Aerpro AM7X

Summary of Contents for Aerpro AM7X

  • Page 1 MULTIMEDIA RECEIVER Wireless Apple CarPlay & Android Auto USER MANUAL AM7X Android Auto, Google Play, Android, are registered trademarks of Google, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. Apple, Apple Car Play, Apple iPhone, Apple Music and Siri are registered trademarks of Apple, Inc.

  • Page 2: Interface Icons

    FEATURES • Large 7” touchscreen LCD (1024 x 600) • Subwoofer level control • Works with Apple CarPlay (wireless or wired) • Time alignment capabilities • Supports Android Auto (wireless or wired) • Dual Rear USB: USB1: CP/AA/USB Media • Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP) USB2: USB Media •...
  • Page 3 MAIN MENU Home screen/back button Date/Time Current Source Music Info Connected device (Page 4) CarPlay/Android Auto mode* Display On/Off CarPlay Icon* Android Auto Icon* Radio Mode (Page 4) Bluetooth Mode (Page 6) USB Mode (Page 5) AV In Reverse Camera Camera 2 Setup (Page 8) * Icons will only be visible if a...

  • Page 4: Radio Mode

    RADIO MODE To enter Radio Mode, touch “Radio” icon on the Main Menu Seek down Radio frequency Seek up AF and TA settings FM Band button AM Band button Auto Store button EQ Mode button Keypad button Preset station list Auto Tuning Press the seek icon ( ) on the TFT Monitor screen to increase / decrease the...
  • Page 5 MEDIA PLAYING MODE This operation allows you to play various compatible formats. Touch the icon to return to previous track or press and hold the icon to fast rewind Touch the icon to play or pause the track Touch the icon to go to next track or press and hold the icon to fast forward Touch the end of the progress bar line and drag it left or right to the desired track time Touch the icon to repeat a folder or track...

  • Page 6: Bluetooth Mode

    • This unit can be paired with 5 mobile phones, but only one can be active at a time. • The unit Bluetooth name is AM7X. 5 5 5 5 5 5 6 Touch the icon to enter pairing mode...
  • Page 7 CONNECTED DEVICES SCREEN Touch the icon to access the connected devices screen This screen displays paired devices and allows the user to turn Android Auto/Apple Carplay or other bluetooth features on or off. (If applicable to the device) Paired devices Apple Carplay activate/deactivate Android Auto activate/deactivate Bluetooth calling activate/deactivate...

  • Page 8: Setup Menu

    SETUP MENU Setup menu allows you to change the settings within unit, General, Display, Audio and Others General Touch “General” on the Setup Menu display for general settings •...
  • Page 9 SETUP MENU Setting Options Functions Date Day / Month / Year Select to adjust calendar date Time Hour / Minutes Select to adjust time Time Format 12 Hour / 24 Hour Choose clock mode 12H/24H GPS Time Sync On / Off Uses provided GPS module for time and date Daylight Savings Adds +1 hour to clock for daylight savings...
  • Page 10 SETUP MENU Audio Touch “Audio” on the Setup Menu display for audio adjustment settings Setting Options Functions Equalizer Balance and EQ setting Time Alignment Default / Presets / Reset Speaker delay Crossover settings Filter On / Off Sound boost Loudness Bass switch Subwoofer Gain On / Off...
  • Page 11 SETUP MENU 5 5 5 5 5 5 6 5 5 5 5 5 5 10 5 5 5 5 5 5 5 5 5 5 9 5 5 11 Balance fade presets Speaker selection filter (Sub/Front Speak- ers/Rear speakers) Subwoofer volume Crossover type (Low pass/High Audio position...
  • Page 12 SETUP MENU Display • Touch “Display” on the Setup Menu display, then select a feature you want to adjust. * Requires an illumination wire to be present in the vehicle (Usually orange wire in ISO harness needs to have a connection) Setting Options Functions...
  • Page 13 Touch “Others” on the Setup Menu display, then select for information and factory reset. * The Steering Wheel Controls are pre-programmed to suit Aerpro AM7X kits, and is not required to be manually adjusted unless the user wants to customize these functions.
  • Page 14 SETUP MENU Others • When the vehicle is put into reverse, you can tap the screen to display the camera switching icon. Tapping on this icon will switch the view to the second camera. NOTE: The reverse trigger wire must be connected in order to display the reverse camera when the vehicle is in reverse.
  • Page 15 3. A pair message and a pairing request code may appear on your compatible device and head unit. Click allow to accept 4. An ‘Allow CarPlay with Aerpro while phone is locked’ message may appear on your device. Click allow to accept 5.
  • Page 16 1. Before using Android Auto wirelessly, turn on the Bluetooth and WiFi function on the compatible device. 2. Navigate to the Bluetooth settings on your compatible device and select AM7X for pairing 3. A pair message and a pairing request code may appear on your compatible device and head unit.
  • Page 17 HOW TO USE CARPLAY ® Requirements • Lightning Data Cable • iPhone 5 or later • iPhone with iOS 7.1 or later • Data Plan for in app content • Siri activated Phone Setup (Before you begin): 1. Apple CarPlay ® features may operate differently than on your Apple iPhone ® 2.

  • Page 18: Using Siri

    USING SIRI ® Apple CarPlay uses Siri to perform many actions like sending messages, placing calls, and looking up/setting POI/Destinations. A Siri session can be initiated on any screen • Touching and holding the Home icon on the CarPlay screen or •...
  • Page 19 HOW TO USE ANDROID AUTO ® Requirements • A high-quality USB cable • Compatible Android® phone with OS Android 8.0 or higher • Data Plan for in app content • Wireless Android Auto requires 5GHz(802.11/ac) Wi-Fi support (refer to page 18 of this manual) •...

  • Page 20: General Wiring Diagram

    GENERAL WIRING DIAGRAM GENERAL WIRING DIAGRAM GPS antenna External Mic Input Fuse Input Replace with same USB1: CP/AA/USB Media specification USB2: USB Media value Head unit Antenna Input ISO Wiring Harness Audio-Video Lead 20 PIN 20 PIN 18 PIN 18 PIN NOTE: This diagram shows a basic wiring configuration.

  • Page 21: Specifications

    SPECIFICATIONS Display LCD Size 7" (7X) Resolution 1024*600 Touch Screen Capacitive System Specification OS System/CPU Linux 3.4.5 / SPHE8368U RAM / Flash Memory 128MB / 256MB DIN Size 2.0 DIN 2DIN short body Power Output Rated Power 4CH x 25W MAX Power ( 4CH x 45W 4 Ohm @ 14.4 V, 1 kHz, THD 10 %...

  • Page 22: Faq & Troubleshooting

    • Navigate to your Bluetooth Settings • Tap the Cog on the previously paired Aerpro head units Bluetooth. If you have not previously paired with the head unit, you can skip to re-pairing your phone with the Aerpro head unit.
  • Page 23 Red Blinking Power Light on the Head Unit • This can mean the head unit doesn't have enough power to power on the unit or there is a wiring issue. Please refer to the aerpro website for specific instructions related to your vehicle.

  • Page 24: Safety Information And Warnings

    TECHNICAL ASSISTANCE Please retain this user guide for future reference. If you would like to download a digital copy of this manual, or other Aerpro manuals/software, please visit the Aerpro.com website and search for information on your model. This quick start guide is considered correct at time of printing but is subject to change.
