- Page 1 Installation Manual INDUCTION RANGES RAIND MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 Cooking Safety ........4 Cleaning Safety . -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: WARNING Never Operate the Top Surface Cooking Section of this Appliance Unattended. • Failure to follow this warning statement could result in fire, explosion, or burn hazard that could cause property damage, personal injury, or death. •... - Page 6 IMPORTANT SAFETY INSTRUCTIONS WARNING: Never use this appliance as a space heater to heat or warm the room. Never use the top of the range or the interior of the oven as WARNING a storage areas, as items could melt or ignite, increasing the risk of fire, damage, and/or serious injury.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal WARNING injury, or death. • Before beginning installation, please read and follow these important instructions for the safety of your home and the people living in it.
-
Page 8: Cooking Safety
IMPORTANT SAFETY INSTRUCTIONS COOKING SAFETY • To prevent accidents and achieve optimal ventilation, allow for sufficient space around the cooking area. • This appliance is designed for built-in household use only. Do not use outdoors. • Wear proper apparel — loose fitting or hanging garments should never be worn while using the appliance. - Page 9 If your range top is broken, contact ZLINE immediately at 1-614-777-5004. • Always remove the covers on sealed or canned goods before heating to avoid explosion.
-
Page 10: Cleaning Safety
Do not operate any appliance if the cord is damaged, the appliance malfunctions, or the appliance is damaged. In the event your appliance is WARNING broken or damaged upon arrival, contact ZLINE immediately at 1-614-777-5004. PLACEMENT SAFETY • Do not carry or lift the range by the oven door handle or the control panel. - Page 11 Control the cooking process at all times. • The use of accessory attachments that are not recommended by ZLINE may cause injuries. • Items with a magnetic field, such as radios, televisions, credit cards, cassette tapes, etc., can affect the unit.
- Page 12 IMPORTANT SAFETY INSTRUCTIONS ENVIRONMENTAL SAFETY • This range should not be treated as household waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. • By ensuring this product is disposed of correctly, you will help prevent potential negative consequences to the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
-
Page 13: Before Installation
4" (102 mm) NOTE: “A” changes depending on size of range: • RAIND-24 series ranges: Actual product width is 23 7/8" (606 mm) • RAIND-30 series ranges: Actual product width is 29 3/4" (756 mm) • RAIND-36 series ranges: Actual product width is 35 3/4" (908 mm) NOTE: The above diagram is of the RAIND-36 series range model;... -
Page 14: Cabinet Cutouts
9 and 1 1; this allows for minimal clearance on each side. Kitchen layouts may vary slightly, so adjust accordingly.: • RAIND-24 series ranges: 24" (610 mm) • RAIND-30 series ranges: 30" (762 mm) •... - Page 15 23 7/8" W x 27 1/2" D x 36 1/8" H 18 1/2" W x 18 1/2" D x 14" H RAIND-24 series ranges 606 mm W x 699 mm D x 918 mm H 470 mm W x 470 mm D x 356 mm H 29 3/4"...
-
Page 16: Installation
INSTALLATION INSTALLING THE LEGS The ranges must be used with the legs properly installed. Height-adjustable legs are shipped with the range in a foam container above the range. Legs are 4" (102 mm) tall and can be adjusted up to 2 1/2" (64 mm) for a maximum height of 6 1/2" (165 mm). Installing the Legs 4"... -
Page 17: Installing The Anti-Tip System
INSTALLATION INSTALLING THE ANTI-TIP SYSTEM The chains shipped with the range must be properly secured to studs on the rear wall. The height of the bracket from the floor must be determined after the range legs have been adjusted to the desired height and after the range has been leveled. A child or adult can tip the range and be injured;... -
Page 18: Electric Power Rating
INSTALLATION ELECTRIC POWER RATING RAIND-24, RAIND-30, RAIND-36 SERIES RANGES Plug NEMA 14-50P (50 AMP plug) Amps 6200 Four-Wire Connection Receptacle NEMA 14-50R L2 (red) L2 (red) N (white) N (white) cable from power supply G (green) G (green) L1 (black) L1 (black) ELECTRICAL GROUNDING This oven is equipped with a four-prong plug for protection against shock hazard and... - Page 19 INSTALLATION Label all wires prior to disconnecting when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Only a qualified electrician or professional may conduct electrical service on this unit. Check your local code for which of the following options may be used in grounding the receptacle power supply connections.
-
Page 20: Installation Checklist
INSTALLATION INSTALLATION CHECKLIST 1. Is the range mounted on its legs and is the unit level? 2. Is the back guard securely connected? 3. Have the chains been properly installed? 4. Does the clearance from the side cabinets comply with the manufacturer’s direction? 5. -
Page 21: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath (“ZLINE”) induction ranges have a one year parts and service warranty. ZLINE warranty periods begin from the original purchase date of the product and solely cover the original purchaser of the product, delivered new and in its original carton. The limited warranty covers all parts and labor for necessary repairs if any part of the product, or the product itself, proves to be defective in materials or workmanship. - Page 22 ZLINE reserves the right to offer to replace the defective part or the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
- Page 23 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
- Page 24 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner. Scan the QR code to view the most up-to-date version of our User Manual...
- Page 25 1.5.1 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
