1
Velcro strap
Adjustable screws to
ensure a comfortable fit
Lead for the connector
cord to plug into
In The Box
SYMBYX Neuro
1
2
Connector cord which links helmet to the battery pack
3
Battery
SYMBYX Neuro User Guide
4
5
Protective storage case
Before Starting Treatment
Position the SYMBYX Neuro on your head with the Velcro straps
in the front. The straps should fit comfortably across your
forehead roughly between the eyes and your hairline. Adjust the
Velcro straps so that the SYMBYX Neuro fits snugly. The circular
disc on the top of the helmet should be placed in a way that it
rests flat on the crown of your head, and the curved sections
on the sides should frame your ears. The back of the helmet
should cover the back of your head and the top of the neck.
Treatment Time
The SYMBYX Neuro is pre-programmed to run automatically for
a full 24 minutes. includes 12 minutes of red light followed by 12
minutes of infrared light.
Power Charger Input /
Interconnect Port
2
Frequency of Use
For the first two weeks of treatment use the SYMBYX Neuro
2-3 days per week on alternating days, for the subsequent
weeks use the SYMBYX Neuro up to 5 days a week. If you are
using the SYMBYX Neuro in combination with a handheld
laser, please follow the separate combined protocol.
Use once per day only, at a broadly similar time. SYMBYX
recommends using the SYMBYX Neuro first thing in the
morning unless you are experiencing interrupted sleep. If so,
in the afternoon or early evening would be preferable.
Treatment Protocol
1. Place and fit the SYMBYX Neuro snugly on your head
2. Connect the SYMBYX Neuro
to the battery
1
connecting cord
. Either USB output on the battery can be
2
used.
3. The SYMBYX Neuro will turn on automatically. This is indicated
by a long audible beep, following by a short testing cycle: 2
seconds of red light, then 2 seconds of infrared light.
4. The treatment will then commence automatically, first with
12 minutes of red-light treatment, followed by 12 minutes
of infrared light treatment. You will hear two audible beeps
at the 12-minute mark (halfway point). Do not remove the
SYMBYX Neuro at this point, as there is another 12 minutes of
treatment to go. No flashing lights will be visible during the
infrared cycle (the second 12 minutes).
5. After 24 minutes, the SYMBYX Neuro helmet will audibly beep
and flash five times in order to inform you that the treatment
session is complete.
POWER
Button
3
4
6.
Once the treatment is complete, remove the SYMBYX Neuro
from your head and disconnect it from the battery. The
battery will automatically turn off.
If You Wish To Pause Mid-Treatment
If you wish to stop treatment at any time, simply remove the
SYMBYX Neuro from your head and remove the cord from the
battery pack. The battery will turn off automatically after 30
seconds. To turn the SYMBYX Neuro back on, simply reconnect the
cord to the battery. The treatment will reset and start again from
the beginning.
After Each Treatment Session
using the
Disconnect the battery from SYMBYX Neuro helmet and place it on
3
a charger after each treatment. This will ensure that it is ready for
your next treatment.
Battery Care & Cleaning
• In order to charge the battery
Neuro
.
1
• Connect the battery to any Micro USB or TYPCE C charging cord
you have at home.
• The battery will take approximately 4 hours to charge completely.
• To clean the SYMBYX Neuro wipe gently with 70% alcohol or
antiseptic wipes, or a soft dry cloth. Do not use abrasive cleaners.
Do not submerge the helmet in liquid or cover with any material
during use.
5
, first disconnect it from SYMBYX
3
