User Manual
MagniLink AIR – iOS
LVI America Inc.
302 Saunders Road, Suite 200
Riverwoods, IL 60015, USA
LVI Low Vision International
Verkstadsgatan 5
SE-352 46 Växjö
Phone: (888) 781-7811
Tel: +46 470-727700
Faks: +46 470-727725
info@lviamerica.com
www.lviamerica.com
info@lvi.se
www.lvi.se

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MagniLink AIR and is the answer not in the manual?

Questions and answers

Related Manuals for LVI MagniLink AIR

Summary of Contents for LVI MagniLink AIR

  • Page 1 User Manual MagniLink AIR – iOS LVI America Inc. 302 Saunders Road, Suite 200 Phone: (888) 781-7811 info@lviamerica.com Riverwoods, IL 60015, USA www.lviamerica.com LVI Low Vision International Verkstadsgatan 5 Tel: +46 470-727700 info@lvi.se SE-352 46 Växjö Faks: +46 470-727725 www.lvi.se...

  • Page 3: Table Of Contents

    7.1 System requirements ..............13 7.2 Installation of software ............. 13 7.3 Connect to network ..............14 7.4 Using the software ..............15 Ergonomics ................... 37 Technical information ..............38 10 Declaration of Conformity ............40 User Manual 7946662a | MagniLink AIR - iOS...
  • Page 4 MagniLink AIR - iOS User Manual 7946662a | MagniLink AIR - iOS...

  • Page 5: About Lvi

    MagniLink AIR - iOS 1 About LVI LVI Low Vision International AB was founded in 1978 and is one of the world's leading manufacturers of equipment for persons with visual impairments. Development of new products takes place in close cooperation with users and professional staff within the low vision rehabilitation industry.

  • Page 6: Introduction To Magnilink Air

    MagniLink AIR Uno with a combined distance and reading camera. MagniLink AIR Duo with a distance camera and a reading camera. MagniLink AIR Distance is a distance camera that connects to a computer via a network cable. You can also connect various LVI reading cameras to the system.

  • Page 7: Information

    • Please follow the instructions in the document called “Assembly and Installation”. • Store cables and power supplies securely. • LVI recommends having two persons present when mounting the unit to a ceiling. • Make sure the system is installed correctly.
  • Page 8 • Make no further adjustments, even if the product does not function normally after following the functional descriptions. Pull out the power cable and contact service staff or the product distributor. Only use spare parts that are specified by LVI. If in doubt, contact your supplier. Warning The product is supplied packed in a plastic bag.

  • Page 9: Unpacking

    Make sure there is no external damage before opening the box. In the event of damage, contact the courier to report the damage. Open the box, take out the MagniLink AIR and remove the packaging parts. For further information, please see the chapter on Installation.

  • Page 10: Accessories

    MagniLink AIR - iOS 5 Accessories Roof bracket (MLAIR-A014). Used if the ceiling is not using 60x60cm panels. Text To Speech for PC (TTS-PC), Mac (TTS-MAC) or Chromebook (TTS- CHROME). User Manual 7946662a | MagniLink AIR - iOS...

  • Page 11: Magnilink Air Distance

    6 MagniLink AIR Distance The distance camera is connected using the included network cable. To connect it to an iPad, an adapter is required. The distance camera is available with various brackets. Table bracket (MLAIR-DISTANCE). User Manual 7946662a | MagniLink AIR - iOS...
  • Page 12 MagniLink AIR - iOS Ceiling bracket (MLAIR-DISTANCE-C). Wall bracket (MLAIR-DISTANCE-W). User Manual 7946662a | MagniLink AIR - iOS...

  • Page 13: Magnilink Viewer

    7.1 System requirements • iPad with iPadOS 15.0 or later. 7.2 Installation of software Enter App Store and click Search in the lower right-hand corner. Click the download icon to install the software. User Manual 7946662a | MagniLink AIR - iOS...

  • Page 14: Connect To Network

    Click Allow while using the app. Click OK. 7.3 Connect to network To be able to stream video from MagniLink AIR Uno or Duo, you must connect to its network. Open the iPad’s WiFi settings and connect to the ML_AIR network. Enter the password provided.

  • Page 15: Using The Software

    Switch views Switches to the OCR view. Press and hold to switch to the Notepad view. Change camera Switch between the LVI camera and the front and rear cameras. Split Mode Opens a submenu where you can set the split mode.
  • Page 16 Position 2 Move the camera image to position 2. Press and hold to save the position. Position 3 Move the camera image to position 3. Press and hold to save the position. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 17 Stop recording by pressing the button again. The clip can then be opened in the “Images” app. The file name will be today’s date and the current time. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 18 Switch between artificial colours. Press and hold to switch back. Reduce brightness/contrast Increase brightness/contrast Mirror the camera image Press again to reverse the mirror image. Rotate the camera image Rotates the camera image clockwise. Press and hold to rotate anti-clockwise. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 19 • At the bottom is a menu bar with buttons. • To the left is a list of pages that have been OCR processed previously. By clicking on a page, you can navigate to it. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 20 Skip backwards in the text. Depending on which reading mode is selected, you will skip back to the previous character, word, sentence or block. Press and hold to switch to the previous page. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 21 Image settings Open a submenu with the following buttons. Switch natural colours Switch between natural colours and grey scale. Switch artificial colours Switch between artificial colours. Press and hold to switch back. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 22 • An area where you can draw, enlarge and pan through the image. • At the bottom is a menu bar with buttons. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 23 Draw with a pen. Press and hold to open a dialog box where you can choose the colour and size. Highlight Highlight with a highlighter. Press and hold to open a dialog box where you can choose the colour and size. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 24 Enlarge and pan in the image. Undo Restore Restore after pressing undo. Rotate Any changes you made to the image will be removed if you rotate. Settings Open the settings dialog boxes. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 25 Press with three fingers on the top of the screen Change split mode Press with three fingers on the bottom of the Open settings screen 7.4.2.2 OCR view Pinch Change magnification User Manual 7946662a | MagniLink AIR - iOS...
  • Page 26 Natural colours fn + F2 Positive picture with increased contrast Artificial colours; White/Black, Yellow/Black, Green/Black, Red/Black, Yellow/Blue, White/Blue Press F2 to toggle through the different colours. (Shift + fn + F2 toggles backwards.) User Manual 7946662a | MagniLink AIR - iOS...
  • Page 27 + F5 Take a snapshot There is an audible click, and the image is saved. The file name will be today’s date and the current time. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 28 OCR processed text is read aloud. Minus Decrease font size Plus Increase font size Start/Pause reading If no reading is currently in progress, reading starts, otherwise reading is paused. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 29 Take a picture and open in Notepad Option + N New Page Option + O Open image Option + S Save image Cmd + Z Undo Shift + Cmd + Z Redo Option + R Rotate clockwise User Manual 7946662a | MagniLink AIR - iOS...
  • Page 30 The Information and settings window consists of a number of different tabs that contain application information and alternative settings. 7.4.4.1 About the application Under this tab you will find information about the camera and the software version. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 31 Activate this function to limit the recording length. Length in minutes If you have chosen to limit the recording length you can set the limit here in minutes, from 1 to 60 minutes. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 32 60 Hz, but it may be appropriate to set the frame rate at 30 Hz for computers with a lower level of performance. Quality Depending on performance, you may want to use a lower video quality setting. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 33 If this box is checked, text will automatically be read aloud after an image has been OCR processed. Font Here the user can set the font for displaying the OCR processed text. The choice of font has no bearing on the OCR result. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 34 MagniLink AIR - iOS 7.4.4.5 Gestures Here you can choose which gestures will be used. To turn off a gesture, you can untick the relevant box. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 35 If a combination already being used for another command is entered, the other command will be erased. A new keyboard combination will need to be entered for the other command. User Manual 7946662a | MagniLink AIR - iOS...
  • Page 36 • To remove either the positive or the negative component. Uncheck the “Positive” or “Negative” checkboxes. • To restore the colours, press “Default colours”. Grey scale Choose if you wish to have grey scale or not. User Manual 7946662a | MagniLink AIR - iOS...

  • Page 37: Ergonomics

    • If you use the device for long periods of time, there is a risk of repeated movements causing you pain in your neck, shoulders and back. Your eyes can also get tired from looking at a screen for too long. User Manual 7946662a | MagniLink AIR - iOS...

  • Page 38: Technical Information

    Frequency, distance camera 60 Hz Weight, distance camera 2 kg Power source Power consumption 30 W Acceptable temperature ranges Transport and storage -20 °C – +60 °C Operation: +5 °C – +35 °C User Manual 7946662a | MagniLink AIR - iOS...
  • Page 39 Recycling helps in the management of our natural resources. For more detailed information regarding the recycling of this product, you can contact your municipality, your waste management company or the store where you purchased the product. User Manual 7946662a | MagniLink AIR - iOS...

  • Page 40: Declaration Of Conformity

    MagniLink AIR - iOS 10 Declaration of Conformity User Manual 7946662a | MagniLink AIR - iOS...
  • Page 41 Reuse, installation and maintenance ............ 7 Safety information .................. 7 Short cut commands ................35 Speech Settings ..................33 System requirements ................13 Technical information ................38 Unpacking ....................9 Using the software ................15 User Manual 7946662a | MagniLink AIR - iOS...
