Modernum Smart 75 User Manual

USER GUIDE
Battery Charger
with built-in flashlight and power supply
for 1 - 150Ah lead-acid batteries
Please read this user guide carefully before using the charger
Use protective eyewear when handling batteries
INTRODUCTION
Thank you for choosing a professional quality product from
MODERNUM! This advanced and user-friendly battery charger
will optimize performance and lifetime of your battery.
This intelligent and fully automatic charger can be used to
charge any type of lead-acid batteries, including AGM and GEL
types from 1 to 150Ah.
It can also act as a power supply in the 13.7V mode. It has a
flashlight that automatically turns on while not connected to
the battery.
Visit www.modernum.se for more info about us.

GETTING STARTED

1. Connecting the charger: Connect the charger to the
supply mains. The flashlight in front of the charger will
automatically turn on to assist you in dark situations.
The battery terminal not connected to the chassis has to
be connected first. The other connection is to be made
to the chassis, remote from the battery and fuel line.
The red clamp should connect to the positive (+) pole of
the battery and the black clamp to the negative (-) pole.
For stand-alone batteries: Connect the charger to the
supply mains. Connect the red clamp to the battery's
positive (+) pole, and then the black clamp to the
battery's negative (-) pole.
2. Select a charge mode, or 13.7V supply, by pressing the
selection button.
3. A green light next to "full battery" symbol means the
battery is fully charged and has entered maintenance
mode (not applicable for 13.7V mode).
4. After charging is complete, the charger will switch to a
Maintenance mode to keep the battery fully charged as
long as charger is plugged in to the mains.

INSTRUCTIONS

1. Connect the charger as explained in GETTING STARTED,
point 1, above.
Smart 75
