Please read this user guide carefully before using the charger
Use protective eyewear when handling batteries
Thank you for choosing a professional quality product from
MODERNUM! This advanced and user-friendly battery charger
will optimize performance and lifetime of your battery.
This intelligent and fully automatic charger can be used to
charge any type of lead-acid batteries, including AGM and GEL
types from 6 to 200Ah. It has a flashlight that automatically
turns on while not connected to the battery.
Visit www.modernum.se for more info about us.
•
This charger is made for charging 12V lead-acid batteries
(including AGM and GEL). Do not use it for other
purposes or with other battery types.
•
IF THE CHARGER IS WRONGLY INDICATING
REPEATED STARTUPS, WITHOUT A BATTERY
CONNECTED, THEN THE CHARGER'S SPARK
PROTECTION MAY BE FAULTY, WHICH CAN
CAUSE SPARKS THAT CAN IGNITE EXPLOSIVE
GASES AND THE CHARGER SHOULD BE
DISCARDED.
•
Do not try to recharge non-rechargeable batteries.
•
Do not use the charger if its casing, terminals, clamps or
cables are damaged.
•
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•
Use protective eyewear when handling batteries, and
connecting or disconnecting it.
•
Battery acid is corrosive. If it comes in contact with skin
or eyes – rinse with plenty of water and contact a doctor
immediately.
•
DURING CHARGE, A BATTERY CAN EMIT
EXPLOSIVE GASES. MAKE SURE THERE ARE
USER GUIDE
Battery Charger
with built-in flashlight
for 6 – 200Ah lead-acid batteries
INTRODUCTION
Smart 60
SAFETY
Advertisement
Table of Contents
Related Manuals for Modernum Smart 60
Summary of Contents for Modernum Smart 60
- Page 1 Use protective eyewear when handling batteries INTRODUCTION Thank you for choosing a professional quality product from MODERNUM! This advanced and user-friendly battery charger will optimize performance and lifetime of your battery. This intelligent and fully automatic charger can be used to charge any type of lead-acid batteries, including AGM and GEL types from 6 to 200Ah.
- Page 2 NOT SPARKS OR FLAMES CLOSE TO IT, AND ENSURE GOOD VENTILATION. • Never charge a battery that is frozen. • Do not place the charger on top of the battery. • Do not cover the charger. • The charger is protected against overheating. If the ambient temperature is too high, the charging current is reduced.
- Page 3 battery chargers, in which case you should follow those. For stand-alone batteries: Connect the charger to the supply mains. Connect the red clamp to the battery’s positive (+) pole, and then the black clamp to the battery’s negative (-) pole. When all 4 charge level indicators are constantly lit, the battery is fully charged and has entered maintenance mode.
- Page 4 CHARGING CURVE Reference charging time (hours) to 85 % capacity. Time varies with different batteries and conditions. 25Ah: 5h 75Ah: 10h 100Ah: 18h 150Ah: 26h Note: If left connected, it is programmed to restart from Step3 after 7 days, to refresh the battery. SPECIAL FEATURES Flashlight: There is a built-in flashlight in the front of the charger, on the top of casing just in front of the battery...
- Page 5 connection to battery. Action: Check that clamps are connected well to metal on both battery poles. Check that connector on the clamp cable is pushed all the way into connector on charger’s connector. Probable cause 2: The battery voltage is too low (<5V) for the charger to detect it, and it will not start.
- Page 6 230x40x38 mm International Protection class IP54 Weight 0.5 kg (net) CE MANUFACTURER DECLARATION Made by: HF SM Power Innovations AB Product: Battery charger Smart 60 The manufacturer guarantees that the unit complies with the relevant standards. Tested and approved by Intertek.
- Page 7 LIMITED WARRANTY We guarantee the quality of this product. It is made to meet high industrial production standards for electronics. This limited warranty is made to the original purchaser of this product, and is valid from the date of purchase, meeting the mandatory warranty rights for the country of purchase.
