USER GUIDE
Battery Charger
with built-in flashlight
for 6 – 200Ah lead-acid batteries
Please read this user guide carefully before using the charger
Use protective eyewear when handling batteries
INTRODUCTION
Thank you for choosing a professional quality product from
MODERNUM! This advanced and user-friendly battery charger
will optimize performance and lifetime of your battery.
This intelligent and fully automatic charger can be used to
charge any type of lead-acid batteries, including AGM and GEL
types from 6 to 200Ah. It has a flashlight that automatically
turns on while not connected to the battery.
Visit www.modernum.se for more info about us.
SAFETY
This charger is made for charging 12V lead-acid
•
batteries. Do not use it for other purposes or with other
battery types.
Do not try to recharge non-rechargeable batteries.
•
Do not use the charger if its casing, terminals, clamps or
•
cables are damaged.
If the supply cord is damaged, it must be replaced by the
•
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Use protective eyewear when handling batteries, and
•
connecting or disconnecting it.
Battery acid is corrosive. If it comes in contact with skin
•
or eyes – rinse with plenty of water and contact a doctor
immediately.
During charge, a battery can emit explosive gases. Make
•
sure there are not sparks or flames close to it, and
ensure good ventilation.
Never charge a battery that is frozen.
•
Do not place the charger on top of the battery.
•
Do not cover the charger.
•
The charger is protected against overheating. If the
•
ambient temperature is too high, the charging current is
reduced.
During the charge, the charger may intermittently
•
provide a 15.0V charge voltage. Ensure that no
Smart 50
Advertisement
Table of Contents
Related Manuals for Modernum smart 50
Summary of Contents for Modernum smart 50
-
Page 1: Battery Charger
Use protective eyewear when handling batteries INTRODUCTION Thank you for choosing a professional quality product from MODERNUM! This advanced and user-friendly battery charger will optimize performance and lifetime of your battery. This intelligent and fully automatic charger can be used to charge any type of lead-acid batteries, including AGM and GEL types from 6 to 200Ah. - Page 2 equipment that may be damaged by this voltage level is connected to the battery during charging. This appliance can be used by children aged from 8 years • and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazard involved.
- Page 3 it means “FAULT” and indicates wrong connection to battery (reversed polarity). Disconnect mains, then clamps and reconnect as said above. When charging, the yellow and green indicators will show the current charge level of the battery, when constantly lit. Lamp lit – Battery not connected Lamp+Red –...
- Page 4 SPECIAL FEATURES Flashlight: There is a built-in flashlight in the front of the charger, on the top of casing just in front of the battery symbol. It will automatically turn on when the charger is plugged in. It will switch off if connected to a battery. Temperature sensor: The temperature affects the batteries ability to receive charge.
- Page 5 be replaced. Fault: Charging started normally, but did not complete, and stopped. Yellow+Green+Red lights are lit. Probable cause 1: The battery has a fault that does not permit it to be charged, e.g. a short circuit. Action: Replace the battery (with lead-acid type). Probable cause 2: Parallel load.
- Page 6 CE MANUFACTURER DECLARATION Made by: SM Power Innovations AB (SMPower) Product: Battery charger Smart 50 The manufacturer guarantees that the unit complies with the relevant standards. Tested and approved by Intertek. LIMITED WARRANTY We guarantee the quality of this product. It is made to meet high industrial production standards for electronics.
