• Effortless maneuvering: Multi piece formed handle and multi
axis casters provide easy movement on all surfaces.
• Enhanced Safety: pinned caster lock prevents caster from
rotating and prevents cart from rolling down sloped surfaces.
• Durable tires: Flat-free tires provide reliable performance
without the need for maintenance.
• Strong construction: All-steel frame ensures long-lasting
durability.
• Adjustable tilt for better control.
• Safe and efficient transport solution.
Serious injury or death may occur if this equipment is used for purposes other than intended. Tie Down
provides the following instructions for the use and care of this equipment. It is the responsibility of the user
to understand and convey proper instruction to any and all individuals who use this product.
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to
chemicals including Nickel, which is known to
the State of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
Locking Pull Pin
WARNING: This product can expose you
to chemicals including Nickel, which is
known to the State of California to
Safety Pin
cause cancer. For more information
Co er Pin
Washer
Washer
Rear Axle
Assembly
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
Tilt Back Pallet Carrier
Part ID: 73058
The Tilt Pallet Carrier moves everything from
insulation to rubber rolls; large tires allow
easy movement on all decks. Rear wheels
adjust to change tilt for easy control. The
Tilt Back Pallet Carrier can also be used on
job sites to transport portable restrooms,
water storage tanks, tool boxes or just about
anything else.
Specifications:
• 69" max. hight x 54" wide
• Fork length 32" x 33" wide
• Pallet carrier weight: 200 lbs.
• Shipping weight 2 per pallet: 450 lbs.
• All steel, heavy-duty frame
• (2) 18" x 8.50" & (2) 8"x 6" flat-free tires
• Load limit: 800 lb
Instruction #08434 (E1958 - Rev. 3/2/23)
