Important – Please Read These Instructions Fully Before Starting Assembly
•
Check you have all the components listed on the next page.
•
Remove all parts from the plastic bags and separate them into their groups.
•
Keep children and animals away from the work area, small parts could choke if swallowed.
•
Make sure you have enough space to layout the parts before starting.
•
Assemble on a hard level surface.
•
Assembly of the axles/frame will be easier with 2 people.
If you have damaged or missing parts, call Customer Service: 404-344-0000
Guardrail Tranzcart
Assembly Instructions
Model 65049
Instructions #08323 (E1683 - Rev. 1/10/20)
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
sales@tiedown.com
Advertisement
Table of Contents
Related Manuals for TIE DOWN 65049
Summary of Contents for TIE DOWN 65049
- Page 1 Guardrail Tranzcart Assembly Instructions Model 65049 Important – Please Read These Instructions Fully Before Starting Assembly • Check you have all the components listed on the next page. • Remove all parts from the plastic bags and separate them into their groups.
- Page 2 Carriage Bolt - 5/8-11 x 6” Instruction Tube Part #MAX-WT100 10604 Safety Pin Self Tapping Screws (2) Part #10495 If you have damaged or missing parts, call Customer Service: 404-344-0000 TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 3 CT-34-00361-15 Hex Head Nut 65031 Tread Bite Plates 10627 Nyloc Nuts 10841 Washers 65027-1-5 Lifting Ring 10454 Carriage Bolts If you have damaged or missing parts, call Customer Service: 404-344-0000 TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 4 Use a 15/16” socket wrench on the nut/bolt and tighten to 35 ft. lbs. Counter rotate 1/4 turn. Rotate the axle frame making sure that it turns freely. TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 5 The Penetrator Roofing Cart has the option of locking the Steering Lock Position Holes steering with a pull pin (both sides). To lock the front steering: place the pull pin into the smaller inside round hole. TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 6 Repeat for each lifting ring. Tread Plates Tread Plates Step 3 Align and place tread plates over the Tranzcart frame as shown right. Make sure the mounting holes are it alignment. TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 7 Place the larger washer over the bolt and finish with the nyloc nut. Do not tighten, leave it loose until the other side bolt assembly is completed. Wide Washer Nyloc Nut TIE DOWN Roofing Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 8 Secure the pull pin with the safety clip. Roofing Products Division 605 Stonehill Drive SW, Atlanta, Georgia 30336 800-241-1806 • 404-344-0000 • www.tiedown.com ISO 9001:2015 Certification Intellectual property of TIE DOWN Inc. ©2018 TIE DOWN, Inc. Instruction #08323 (E1683 Rev. 1/10/20)
