B.E.G. LUXOMAT TS-DW1 Installation And Operating Instruction

LUXOMAT
Installation and Operating Instruction for B.E.G. weekly time switch TS-DW1
Removable control panel
3. Menu overview
Program
monday
New
Program
Program
Query
Program
Modify
Automatic-
Mode
5. Key function
M
1. To access the Enter-Mode (program, adjustments, options)
from the Automatic-Mode.
2. To revert to the beginning of the current (sub-) menu.
1. To adjust the flashing digit.
+ –
2. To scroll through a choice
1. Automatic-Mode: To switch the channel ON or OFF until the
A B
next programming step occurs.
C D
2. Automatic-Mode: A push longer than 3 sec. = Permanent
switching status (7).
1. To activate the time switch when operated without power
OK
supply.
2. To confirm the selection or the entered data.
8. New Program (see also the example 9)
D.
New
Program Channel A
Connection
diagram
Adjustment
Date-Time
Summertime
Language
Factory
Program
defaults
Delete
Program
End
Copy
End
Step A. to C. please refer to point 9. (Example "New Program")
E. F.
ON
OFF
Pulse
Permanent
End
TS-DW1
®
1. Safety instructions
The installation and assembly of electrical equip-
ment must be only carried out only by a skilled
person! Otherwise fire danger or danger of an
electric shock exists!
Connect the supply voltage/ frequency as stated
on the product label!
Warranty void if housing opened by unauthorised
person!
The electronic circuit is protected against a wide
range of external influences. Incorrect operating
may occur if external influences exceed certain
limits!
Options
Counter
PIN-Code
End
6. Handling advice
The time switch is programmable without external

power supply after pressing the OK
To revert one step or one level back while in the

Enter-Mode press M .
After completion of a (sub-) menu confirming End

will return the device into the Automatic-Mode.
With + – the choice changes from End to continue.

By confirming continue the time switch returns to
the beginning of the current (sub-) menu.
When confirming End before completion, the time

switch returns to the Automatic-Mode without sav-
ing the entered data.
G.
Yes
Monday
Yes
Tuesday
No
Wednesday
Yes
Thursday
Yes
Friday
No
saturday
No
sunday
2. Initial operation
The time switch is delivered in sleep-mode, the

display is switched off.
Press -button for 1 second.
OK

The current date and time is already programmed

and European daylight savings time is activated.
Select the desired language by pressing + – -

buttons and confirm it by pressing
pressing you move one step backwards from the
M
current position.)
If required, date, time and daylight savings time

mode can be adjusted also by pressing + – -
buttons and a subsequent confirmation with
4. Symbol legend
Channel is switched ON
ON
Channel is switched OFF
OFF
End
For the current date the "holiday program"/
"permanent by date" is activated
Standard programming step
Current state is based on a manual
The state will be cancelled with the next
programming step.
Current state is based on a manual over-ride.
The state is permanent until terminated
P
manually (7).
Days of the week Monday, Tuesday, ... Sunday;
The underscores indicate if the program is active
for the days above.
Current state is based on a switching time
with pulse function
The time switch is locked; to unlock the device
the PIN has to be entered (12).
Menu
Enter-Mode
7. Channel ON OFF / Permanent P
Channel ON OFF
- buttons.
- button ( + – -button) a manual switch of
A
By pushing
the channels take place. The resulting switching status
is marked with the hand-symbol and remains until the
next programming step occurs. (temporary over-ride)
Permanent switching status P
By pressing the corresponding channel button
more than 3 sec. the channel is permanently switched
ON or OFF. The status remains until the next manual
switching occurs (> 3 sec.). (permanent over-ride)
H. I.
time
hour On (OFF)
edit
switching
Delete
switching
time
End
Minute
GB
OK . (Remark: By
OK .
over-ride .
for
A
J.
Next
Switching
End
