LumenRadio W-DMX STICK Manual

SPECIFICATIONS
Power supply DC:
Max. power consumption:
Self-healing fuse:
IP rating:
Dimensions (W x H x D):
Weight:
Antenna:
Operating temp. range:
Storage temp. range:
Humidity:
Frequency range:
Max. RF output power:
Supported protocols:
Supported RF protocols:
LEGAL
CRMX is a trademark of LumenRadio AB, W-DMX is a trade-
mark of Wireless Solution Sweden AB.
Wireless Solution Sweden AB is a fully-owned subsidiary of
LumenRadio AB.
DMX-512A refers to ANSI national standard developed and
maintained by ESTA, Entertainment Services and Technology
Association.
This product makes use of US patents 9,208,680; EU patents
EP 2415317, EP 2803248, China patents CN 102369774,
CN 104041189B and others.
Version of this quick start guide: Version 1 (2023-11-01)
MANUFACTURER
LumenRadio AB
Johan Willins gata 6
416 64 Gothenburg
Sweden
Stick_QST_2023_november.indd 1 Stick_QST_2023_november.indd 1
5 VDC +/- 10%
0.5W
Yes
IP 20
21 x 23 x 98 [mm]
50 g
Built-in
-20 to +55 °C
-30 to +80 °C
0 – 90% non-condensing
2402 – 2480 MHz (ISM band)
10 mW
DMX-512A
CRMX, CRMX , W-DMX, G3, G4,
2
G4S, G5
LumenRadio
Alfred-Herrhausen-Allee 3-5
DE-65760 Eschborn
Germany
FCC: XRSMLE201
IC: 8879A-MLE201
W-DMX STICK
Scan for additional
information
www.wirelessdmx.com
by LumenRadio
