- Page 1 CRMX Stardust User Manual LumenRadio AB 2022-04-11...
-
Page 2: Table Of Contents
CRMX Stardust 2022-04-11 Contents Safety information English .......... - Page 3 CRMX Stardust 2022-04-11 WiFi ..........
-
Page 4: Safety Information
CRMX Stardust 2022-04-11 Safety information WARNING / WARNUNG / ATTENTION / ADVERTENCIA / VARNING / ADVARSEL / VAROITUS / ADVARSEL This product must be earthed. Das Gerät muss an eine geerdete Steckdose angeschlossen werden. Cet appareil doit être branché à une prise de terre. -
Page 5: English
CRMX Stardust 2022-04-11 English 1. Please read these instructions and safety instructions carefully before using this product. 2. Keep these instructions for future reference. 3. Never plug the product into the mains supply while it is still in its packaging. Never cover during use. -
Page 6: Deutsch
CRMX Stardust 2022-04-11 Deutsch 1. Bitte lesen Sie diese Hinweise und Sicherheitshinweise sorgfältig durch, bevor Sie dieses Produkt verwenden. 2. Bewahren Sie diese Anleitung zum späteren Nachschlagen auf. 3. Das Produkt nie anschließen, wenn es sich in der Verpackung beőndet- Außerdem darf das Produkt beim betrieb nicht abgedeckt werden. -
Page 7: Introduction
Welcome to the large family of users of LumenRadio’s world-leading wireless DMX system. We hope that you will enjoy your brand new devices. We, at LumenRadio, have tailored this wireless DMX system to deliver reliability at its best. No matter if you’re using them at a night-club, a community theatre or on the set of a feature őlm, you should be able to trust its cable-like reliability, but without the hassle... - Page 8 CRMX Stardust 2022-04-11 One universe in a point-to-multipoint setup Figure 2: It is possible to have multiple universes being transmitted simultaneously in what’s called a multipoint- to-multipoint setup. Simply link each receiver to the transmitted universe you want it to output. The system will automatically exchange encryption keys and other security parameters.
-
Page 9: Cognitive Coexistence
. They have historically not been fully compatible due to different technologies being used. But CRMX receivers have been able to receive the W-DMX G3 protocol. However, your new CRMX Stardust multi-universe transmitter can be operated in different modes; 1. CRMX - transmit 8 universes of CRMX data 2. -
Page 10: Linking Key
CRMX Stardust 2022-04-11 For W-DMX receivers, please use the W-DMX G3 mode for maximum compatibility. Note: This mode can also be used with CRMX receivers, but security and DMX ődelity is not as good as when running CRMX mode. Mode... -
Page 11: Your Stardust Device
CRMX Stardust 2022-04-11 Your Stardust device Overview Stardust back and front Figure 5: 1. Antenna for Output 1 and Output 2 2. Antenna for Output 3 and Output 4 3. Antenna for Output 5 and Output 6 4. Antenna for Output 7 and Output 8 5. -
Page 12: M10 And 3/8Ž Holes
CRMX Stardust 2022-04-11 4. Wall mounted - using the wall mount kit accessory. M10 and 3/8ž holes On either side of your Stardust unit you’ll őnd holes for M10 (1.5 mm pitch) and 3/8ž (UNC). These can be used with any standard truss mounting clamps or spigots, for instance a standard TV spigot. Do not use screws that can go deeper than 27 mm. -
Page 13: Settings And Operation
őrmware in the new weeks and months. How to update 1. Go to https://lumenradio.com/products/stardust/ to download the latest őrmware release. 2. Unzip the release and copy the .swu őle to the root directory of a USB stick. -
Page 14: Linking
CRMX Stardust 2022-04-11 Stardust Web UI Figure 7: Linking Linking and unlinking receivers is done from the Linking menu or from the web UI. Each output can be linked/unlinked individually. Linking When linking, all available (currently unlinked) receivers within range will be linked to the output. -
Page 15: Streaming Acn
CRMX Stardust 2022-04-11 Streaming ACN Streaming ACN (ANSI E1.31), or simply sACN, is a standard for transferring DMX-512 universes over IP networks. The standard allows for up to 64,000 universes on the same IP network. Streaming ACN supports, and most commonly uses, multicast allowing the protocol to work even if IP settings are not set up properly. -
Page 16: Static Ip
CRMX Stardust 2022-04-11 Static IP When conőguring for static IP, you need to conőgure the following: • IP • Netmask • Gateway (if no gateway exist, leave blank or set it to 0.0.0.0) DHCP By enabling DHCP your Stardust will obtain IP settings automatically if there is DHCP server available on the network. -
Page 17: Battery Backup
CRMX Stardust 2022-04-11 Battery backup Stardust comes with a built-in battery backup for uninterrupted operation. When fully charged, the unit can operate under full load for up to 20 minutes, depending on the load. The device will automatically shut down when it detects the battery is reaching a level where normal operaton is no longer assured. -
Page 18: Compliance Information
FCC Declaration of Conformity We LumenRadio AB, Svangatan 2B, 416 68 Gothenburg, Sweden, declare under our sole responsibil- ity that this product complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:... -
Page 19: Fcc Radio Frequency Interference Warnings & Instructions
• Connect the equipment into an electrical outlet on a circuit different from that which the radio receiver is connected • Consult the dealer or an experienced radio/TV technician for help. Modiőcations made to the product, unless expressly approved by LumenRadio AB, could void the user’s right to operate the equipment. Industry Canada This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. -
Page 20: Accessories
CRMX Stardust 2022-04-11 Accessories All accessories can be ordered from your local CRMX distributor. Order code Description 800-2204 Stardust Rack Mounting Kit 800-2206 TNG Wall Mounting Kit 800-2208 TNG V-mount Battery mount LumenRadio AB...
