PRODUCT SPECIFICATIONS

PowerGuard Pro
Part Number(s)
ECU Dimensions (Excluding Cables)
ECU Weight
Voltage Rating
Operational Input Voltage Range
Operation Temperature Range (°C)
Maximum Contactor Current
Current Consumption
Maximum number of Battery Banks
Voltage Reading Range
Voltage Reading Accuracy
LED Output
PC Communications

PRODUCT ACCESSORIES

Merlin Part Number
19-5002
19-5010
19-5011
19-5018
19-5019
10-4012
10-4013
HWC/FHMG/1
HWC/FME/200
HWC/ATOF/KIT
HWC/BF5
REF: QSF-030
Issue: D
Description
PowerGuard /SmartBank Pro Programming Lead
Battery Isolation Contactor 12V 200A
Battery Isolation Contactor 24V 200A
Input Switch (On)-Off Momentary with Red LED
Input Switch (On)-Off Momentary with Green LED
Cable Cap Insulation Boot 2 – 2/0 AWG Red
Cable Cap Insulation Boot 2 – 2/0 AWG Black
Mega Fuse Holder
200A Mega Fuse
ATO Single Blade Fuse Holder
5 Amp Blade Fuse
Merlin Equipment Ltd
PowerGuard Pro – User and Installation Guide
04-8100 (ECU Only)
04-8101 (12V 1 Batteries)
04-8102 (24V 1 Batteries)
04-8103 (12V 2 Batteries)
04-8104 (24V 2 Batteries)
141 x 71.5 x 32.5mm (L x W x H)
0.22Kg (Ex cabling
0.47Kg (Inc cabling)
12 or 24V DC
6.5 to 36V DC
-25 to + 105°
200A Continuous, 350A Peak
10mA*
*Unit in idle state with no contactors or LEDs powered
2
0 to 19.3V or 38.6V (Dependant on 12 /
24V Setting)
+/- 0.1V DC on 12V setting
+/- 0.2V DC on 24V setting
5V DC Source with 1K series limiting
resistor
Serial – RS232 Communications
