- Page 1 YN560-TX PRO For C 闪光灯信号发射器 Speedlite Transmitter User Manual 用户手册...
-
Page 2: Table Of Contents
MULI: Stroboscopic Flash Gr: Shooting with a Different Flash Mode for Each Group . . 12 About the YN560-TX PRO compatiability list(Spedlite/Receiver) C.Fn: Setting Custom Functions... 14-15 Reference ....16-17 . -
Page 3: Introduction
Introduction YONGNUO YN560-TX PRO speedlite transmitter is a upgrade Ÿ version based on YN560TX II, with TTL/ high speed sync functions, its radio protocol achieves cross-brand compatibility. YN560-TX PRO can control, trigger YN200/YN862 series and Ÿ the models which have been upgraded to the latest firmware... -
Page 4: Nomenclature
Nomenclature Radio transmission ※The protective flim status lamp can be torn out. Function button 2 Function button 1 LCD panel AF-assist beam emitter button Flash mode button :Test flash button Function button3 Select/Set button Function button4 Batter y compartment Select dial cover Mounting foot ON：Power on... - Page 5 Nomenclature Press <MODE> on the master unit and turn the dial to set flash mode. E-TTL（II） Autoflash ZOOM(Slave unit) FEC amount High-speed sync Flash exposure compensation(FEC) Radio transmission wireless shooting ETTL:E-TTL II/E-TTL autoflash A.50 MM Battery ETTL Channel RATIO:Flash ratio RATIO A B C Custom functions C.FEC...
- Page 6 Nomenclature Manual flash A.50 MM M：Manual Flash Manual Flash 2nd RATIO A B C curtain sync Manual flash output GR/PRE RATIO SYNC Multi(stroboscopic) flash MULTI: Multi flash A.50 MM MULTI Number of flashes 1- 1H Flash frequency RATIO A B C GR/PRE MULTI Group firing...
-
Page 7: Preparation Before Use
Preparation Before Use 1.Install two AA/LR6 batteries. 1.Open the cover:Slide the cover down as shown and open the battery compartment cover. 2.Install two AA batteries: Install two AA batteries according to the + and - marks, rechargeable batteries of 1.2V can be used. 3.Close the batter y: Close the batter y Compartment cover and slide it up. - Page 8 Preparation Before Use 3.Turning on the Power:Set the power switch to <ON>. The LCD panel illuminates. Ÿ During wireless shooting, press the Ÿ transmitter’s test flash button to fire a test flash. About the Lock Function By setting the power switch to <LOCK>, you can disable flash’s button and dial operations.
-
Page 9: Wireless Settings
Wireless Settings Using a transmitter and a Speedlite compatible with radio transmission wireless shooting makes it easy to shoot with advanced wireless multiple flash lighting, in the same way as normal E-TTL II/E-TTL autoflash shooting. Positioning and Operation Range (Example of wireless flash shooting) Before shooting, perform a Ÿ... -
Page 10: Wireless Flash Shooting
Wireless Flash Shooting 1.Position the camera and the flash. Set the flash as the slave unit A, B or C . The flash will not fire if it is set to D or E. 2.Press the <MODE> button on the master unit , turn <... -
Page 11: Ettl:fully Automatic Wireless Flash Shooting
ETTL:Fully Automatic Wireless Flash Shooting Support 1/3-stop increments to set FEC/FEB within ±3. FEC (Flash Exposure Compensation) 1.Press function button 4 to display < >.Press function MENU1 button 2 < >. < > is displayed and the FEC amount is highlighted. -
Page 12: M: Wireless Multiple Flash Shooting With Manual Flash Output
M: Wireless Multiple Flash Shooting with Manual Flash Output You can shoot with a different flash output setting for each slave unit(firing group). 1.Set the flash mode to <M>. 2.Set the number of firing groups. P ress function button < RATIO > Ÿ... -
Page 13: Muli: Stroboscopic Flash
MULTI: Stroboscopic Flash In stroboscopic flash, set the flash output, number of flashes, and flash frequency (number of flashes per second = Hz). 1 . S e t t h e f l a s h m o d e t o <MULTI>. -
Page 14: Gr: Shooting With A Different Flash Mode For Each Group
Gr: Shooting with a Different Flash Mode for Each Group 1.Set the flash mode to <Gr>. 2.Flash Group and Mode Setting When <MENU1> is displayed, Ÿ s h o r t p r e s s f u n c t i o n b u t t o n 1<GR/PRE>... - Page 15 Do not support CH16 the speedlite) support(Need to set CH1- support (all RF603(II) Series Do not Do not the flash out put on support support CH16 group can fire） RF602-RX the speedlite) *Need to upgrade the latest firmware from YONGNUO wedsite.
-
Page 16: C.fn: Setting Custom Functions
C.Fn: Setting Custom Functions V1.06 FN.00 30MIN AUTO OFF MODELING FEB AUTO CANCEL ON Press and hold the function button <C.FN> to enter the custom >or press the < >< > button to select function. Turn < the item to be set, and press < >to enter the setting. - Page 17 When a button or dial is operated, the LCD panel illuminates. You can change this illumination setting. 0: 12sec;1: OFF;2: ON (Illumination always on) C.Fn-07: (LCD Contrast) 0-9: Select LCD contrast C.Fn-08: (RF Compat) Please set to this mode when YN560-TX PRO is used 0:RF602( with RF602-RX receiver) 1:RF603(default)
-
Page 18: Reference
Reference 1.Shutter sync setting You can use 1st curtain Sync, high-speed Sync, or 2nd curtain sync . <SYNC> Press function button Ÿ and set the shutter sync. The setting changes as follows each time you press the button: :High-speed Sync :2nd Curtain Sync (no icon):1st Curtain Sync The 2nd curtain sync can be used in manual flash only. - Page 19 Reference 3.Transmitter Control from Camera’s Menu Screen When using EOS digital cameras released since 2007, you can set flash functions, transmitter functions or Custom Functions from the camera’s menu screen. See the camera’s instruction manual. 4.Clearing Transmitter Settings Press function buttons 2 and 3 simultaneously for 2 seconds or longer.
-
Page 20: Troubleshooting Guide
Troubleshooting Guide Power does not turn on. Make sure that the batteries are installed in the correct Ÿ orientation. Insert the mounting foot into the camera’s hot shoe all the Ÿ way, slide the lock lever to the right, and secure the transmitter to the camera . -
Page 21: Specifications
The functions of this user manual are based on test conditions of our company.Further notice will not be given if the design and specifications change. The YONGNUO logo in this manual includes the registered trademark or trademark of Shenzhen Yongnuo Photography E q u i p m e n t C o .
