- Page 1 Wave Plug US Z-Wave® smart plug with power measurements Extended User Guide (EN) Device: Wave Plug US USA Part number/Ordering Code: QNPL-001X16US Z-Wave Product type ID: 0x0002 Z-Wave Product ID: 0x0088 Z-Wave Manufacturer: Shelly Europe Z-Wave Manufacturer ID: 0x0460...
-
Page 2: Table Of Contents
1. User and safety guide ......................5 Z-Wave® Plug US with power measurement ..............5 2. Terminology and Abbreviations....................5 3. About Shelly Qubino ........................ 5 4. About the Device ........................6 5. Installation instruction ......................6 6. About Z-Wave® ........................7 7. - Page 3 Adding / Removing menu selected ..................13 Adding / Removing menu - while pressing S- button - Add/Remove process selected ..13 Factory reset menu selected ....................13 Factory reset - while pressing S - button - Factory reset process selected ......13 Overcurrent detected O ......................
- Page 4 12.1 Overheat detected ......................23 12.2 Overcurrent detected O ....................23 12.3 Overvoltage detected ....................24 13. Z-Wave Associations ......................24 13.1 Root device ........................25 Root device - Association Group 1 - Lifeline ................. 25 Root device - Association Group 2 ..................25 14.
-
Page 5: User And Safety Guide
2. Terminology and Abbreviations • Device - In this document, the term “Device” is used to refer to the Shelly Qubino device that is a subject of this guide. • Gateway (GW) - A Z-Wave® gateway, also referred to as a Z-Wave® controller, Z-Wave®... -
Page 6: About The Device
Shelly Qubino devices can be operated in any Z-Wave® network with other Z-Wave® certified devices from other manufacturers. All mains operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. Devices are designed to work with older generations of Z-Wave®... -
Page 7: About Z-Wave
⚠CAUTION! Do not immerse the Device or wash it under running water! Insert Wave Plug US into a power socket without an appliance/load connected to it. Then you can now plug an appliance into the Device socket. To power the appliance on press briefly the S button. -
Page 8: Z-Wave® Adding / Removing / Factory Reset
and forwards-compatible in the Z-Wave® ecosystem and well over 100 million devices currently in the market. With over 20 years in the marketplace, Z-Wave® technology has best-in-class security measures to keep your home network smarter and safer. Source: www.z-wavealliance.org, http://www.z-wave.com 7. -
Page 9: Adding (Inclusion) With The S Button
7.1.2 Adding (inclusion) with the S button 1. Connect the Device to a power supply. 2. Check if the blue LED is blinking in Mode 1. If so, the Device is not added to a Z-Wave® network. 3. Enable add/remove mode on the gateway. 4. -
Page 10: Factory Reset
7.3 Factory reset 7.3.1 Factory reset general After Factory reset, all custom parameters and stored values (kWh, associations, routings, etc.) will return to their default state. HOME ID and NODE ID assigned to the Device will be deleted. Use this reset procedure only when the gateway is missing or otherwise inoperable. 7.3.2 Factory reset with the S button Note! Factory reset with the S button is possible anytime. -
Page 11: Z-Wave Dsk Label And Qr Code (Example)
the side of the Device and a copy is inserted in the packaging, which must not be lost. Do not remove the Z-Wave DSK label from the Device. As a backup measure, use the label in the packaging. The first five digits of the key are highlighted or underlined to help the user identify the PIN Code part of the DSK text. -
Page 12: Led Signalization
9. LED Signalization 9.1 General rules • Switching between Normal and Settings mode is done by Single press on the S button • Ones in settings mode, LED automatically turns off after 10s • Press on the S button or device power cycle wakeup LED for 10s. Normal mode LED status: Normal mode is defined by stable device function that can remain for an infinite time. -
Page 13: Settings In Progress
9.4 Settings in progress Factory reset and reboot During factory reset, the LED will turn solid blue+red for approx. 1s (undefined in SW), then the blue and red LED will be blinking 0,1s On / 0,1s Off for about 2s. Adding / Removing During adding or removing, the LED will be blinking blue in Mode 2. -
Page 14: Overcurrent Detected O
Alarm Mode Overcurrent detected O The LED will be blinking red in Mode 4 Overheat detected The LED will be blinking red in Mode 4 Overvoltage detected The LED will be blinking red in Mode 4 Z-Wave® Parameters Parameter No. 17 - Restore the O (O1) state after a power failure This parameter determines if the on/off status is saved and restored for the load connected to O (O1) after a power failure. -
Page 15: Parameter No. 19 - O (O1) Auto Off With Timer
Parameter No. 19 - O (O1) Auto OFF with timer If the load O (O1) is ON, you can schedule it to turn OFF automatically after the period of time defined in this parameter. The timer resets to zero each time the Device receives an ON command, either remotely (from the gateway or associated device) or locally from the switch. -
Page 16: Parameter No. 25 - Set Timer Units To S Or Ms For O (O1)
• 1 - NC Relay logic: Par-NO/NC Command (switch, Z-Wave…) Device output state NO (0) OFF (0 V) NO (0) ON (230 V) NC (1) ON (230 V) NC (1) OFF (0 V) Parameter No. 25 - Set timer units to s or ms for O (O1) Set the timer units to seconds or milliseconds. -
Page 17: Parameter No. 39 - Minimum Time Between Reports (O) O1
be sent more frequently than defined by Parameter No. 39. Parameter No. 39 - Minimum time between reports (O) O1 This parameter determines the minimum time that must elapse before a new power report on O (O1) is sent to the gateway. Values size: 1 Byte Default value: 30 Values &... -
Page 18: Parameter No. 92 - Smoke Alarm
Parameter No. 92 - Smoke Alarm This parameter determines how the device should respond to the reports of alarm frames. The parameters consist of 4 bytes, the three most significant bytes are set according to the official Z-Wave protocol specification. The notification types it reacts to are as followed, Notification Type: - NOTIFICATION_TYPE_SMOKE_ALARM 0x01... -
Page 19: Parameter No. 94 - Heat Alarm
Parameter No. 94 - Heat Alarm This parameter determines how the device should respond to the reports of alarm frames. The parameters consist of 4 bytes, the three most significant bytes are set according to the official Z-Wave protocol specification. The notification types it reacts to are as followed, Notification Type: - NOTIFICATION_TYPE_HEAT_ALARM 0x04... -
Page 20: Parameter No. 201 - Serial Number 1
The parameter is Advanced and may be hidden under the Advanced tag. Values size: 1 Byte Default value: 0 Values & descriptions: · 0 - Don’t do Factory reset · 1 - Do the Factory reset Parameter No. 201 - Serial Number 1 This parameter contains a part of device’s serial number. -
Page 21: Parameter No. 203 - Serial Number 3
Parameter No. 203 - Serial Number 3 This parameter contains a part of device’s serial number. The parameter is Read-Only and cannot be changed. The parameter is Advanced and may be hidden under the Advanced tag. Values size: 4 Byte Default value: Device specific Values &... -
Page 22: Supporting Command Class Basic
Supporting Command Class Basic COMMAND_CLASS_BASIC is mapped into COMMAND_CLASS_SWITCH_BINARY, for enabling Switch (O) control: Switch (O) will be turned ON or OFF, after receiving the BASIC_SET command: Basic Command received Mapped Command (binary Switch) Basic Set (0xFF) Switch binary Switch (0xFF) Basic Set (0x00) Switch binary Switch (0x00) Basic GET... -
Page 23: Z-Wave Notifications Command Class
Z-Wave Notifications Command class Z-Wave Z-Wave Device Action to Device Z-Wave Notification Notification colour reaction restore specific definition Type Name Name status 12.1 Overheat detected Any of the following activities reset this notification alarm: power cycle, type=heat alarm Remote Device Value=0x04, Check the Switch OFF... -
Page 24: Overvoltage Detected
12.3 Overvoltage detected Any of the following activities reset this alarm: notification power cycle, type=power Remote Device management reboot (with Value=0x08, Check the Switch OFF Parameter No. event=State Power Overvoltage RGB LED all outputs 117), short Notification Management detected signalization and send a press on the S name=Over-... -
Page 25: Root Device
13.1 Root device Root device - Association Group 1 - Lifeline 1. INDICATOR_REPORT: LED status 2. DEVICE_RESET_LOCALLY_NOTIFICATION: triggered upon request. 3. SWITCH_BINARY_REPORT: status change report for output O (O1) 4. NOTIFICATION_REPORT: triggered on Overheat. 5. NOTIFICATION_REPORT: triggered on Overcurrent detected O (O1) 6. -
Page 26: Technical Specifications
Technical Specifications Power supply 120 V ±10 %, 60 Hz Power consumption < 0.3 W Power measurement [W] Max switching voltage AC 140 V Max switching current AC 15 A Overheating protection Overcurrent protection Overvoltage protection up to 40 m indoors (131 ft.) Distance (Depends on local condition) Z-Wave repeater:... -
Page 27: Important Disclaimer
This symbol on the product or in the accompanying literature indicates that the product should not be disposed of in the daily waste. Wave Plug US must be recycled to avoid possible damage to the environment or human health from uncontrolled waste disposal and to promote the reuse of materials and resources. -
Page 28: Manufacturer
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction Manufacturer Shelly Europe Ltd. (former Allterco Robotics EOOD) Address: 103 Cherni vrah Blvd., 1407 Sofia, Bulgaria Tel.: +359 2 988 7435 E-mail: zwave-shelly@shelly.cloud...
