Gima NB-222C Instructions

PROFESSIONAL MEDICAL PRODUC TS
ISTRUCTIONS
Thank you for purchasing the NB-222C Compact Compres-
sor Nebulizer.
This product was developed for the successful treatment
of asthma, allergies and other respiratory disorders. The
compressor forces air to the nebulizer. When the air enters
the nebulizer, it converts the prescribed medication into an
aerosol of microscopic droplets that can eas ly be nhaled.
The Patient is an intended operator Contraindiation: None
SYMBOLS
Symbols Meaning
Manufacturer
Rappresentante autorizzato nella comu-
nità Europea
WEEE disposal
Class II device
Product compliant with the European Di-
rective
Keep in a cool and dry place
Follow the instructions for use
Applied part of type BF
SAFETY INFORMATIONS
To assure the correct use of the product, basic safety me-
asures should always be followed including the warnings
and cautions listed in this instruction manual.
WARNING
• For regime of medication shall follow the instructions of
your physician or licensed healthcare practitioner.
• Do not cover the compressor with a blanket, towel, or any
other type of cover during using. This could result in the
compressor overheating or malfunctioning.
• Do not use the device where the device may be exposed
to flammable gas or vapors.
• Do not use mineral water in the nebulizer for nebulizing
purposes.
• Always dispose of any remaining medication in the me-
dication tank after each use. Use fresh medication each
time you use the device.
• Do not leave the device or its parts where it will be expo-
sed to extreme temperatures or changes in humidity, such
as leaving the device in a vehicle during warm or hot mon-
ths, or where it will be exposed to direct sunlight.
CAUTION
• Limit the use of the device to 20 minutes at a time, and
wait 40 minutes before using the device again.
• Provide close supervision when this device is used by, on,
or near infants, children or compromised individuals.
• Do not insert any object into the compressor.
• Make sure that the air filter is clean. If the air filter has
changed color or has not been used for 60 days, replace
the filter.
• Make sure that the nebulizer kit is correctly assembled,
the air filter is properly installed, and the air tube is cor-
rectly connected to the compressor and the nebulizer kit.
Air may leak from the air tube during use if not securely
connected.
• Inspect the compressor (main unit) and the nebulizer par-
ts each time before using the device. Make sure no parts
are damaged, the nozzle and a r tube are not blocked and
the compressor operates normally.
• Do not use the device if the air tube is bent.
• Do not block the air filter cover.
• Do not alter the baffle, the nozzle in the medication tank
or any part of the nebulizer kit
• Do not add more than 10ml of medication to the medica-
tion tank.
CAUTION
• Do not operate the device at temperatures greater than
40"C.
• Do not tilt the nebulizer kit so the angle of the kit is greater
than 45°. Medication may flow into the mouth.
• Do not shake the nebulizer kit while using the device.
• Do not subject the compressor, or any of the components
to strong shocks, such as dropping on the floor.
• This device is approved for human use only.
• Do not disassemble or attempt to repair the device or
components.
• Use the device only for its intended use as described in
the instruction manual. Do not use attachments not re-
commended by the manufacturer.
• Dispose of the device, components and optional acces-
sories according to applicable local regulations. Unlawful
disposal may cause environmental pollution.
• Make sure that the air tube is securely attached to the
compressor (main unit) and nebulizing parts, and does
not come loose. Twist the air tube slightly when inserting
it into the connectors to avoid the tube disconnecting du-
ring use
RISK OF ELECTRICAL SHOCK
• Do not use the compressor (main unit) and the power
cord while they are wet.
• Do not plug or unplug the power cord into the electrical
outlet with wet hands.
• Do not immerse the compressor (main unit) in water or
other liquid.
• Do not spill water or other liquids on the compressor.The-
se parts are not waterproof. If liquid spills on these parts,
please unplug the power cord and wipe off the liquid with
gauze or other soft absorbent material immediately.
• Do not use or store the device in humid locations or out-
doors. Use the device within the operating temperature
and humidity.
• Do not overload power outlets. Plug the dev ce nto the
appropr ate voltage outlet.
• Do not use extension cords. Plug the power cord directly
into the electrical outlet.
• Unplug the power cord from the electrical outlet after
using the device. Never leave this product unattended
when plugged in.
• Unplug the power cord from the electrical outlet before
cleaning the device.
• Completely read all of the instructions included the optio-
nal accessories before using them.
• Not to position the ME EQUIPMENT so that it is difficult to
operate the disconnection device.
• The power switch is used to isolate the device from the
supply mains.
• The direction of movement of the actuator of the supply
mains switch is comply with IEC 60447
MAINTENANCE AND STORAGE
• Keep the device out of the reach of unsupervised infants
and children. The device may contain small parts that can
be swallowed.
• Do not leave the cleaning solution in the nebulizer parts.
Rinse the nebulizer parts with clean hot tap water after
disinfecting.
• Wash the nebulizer parts after each use. Dry the parts
immediately after washing.
• Do not store the air tube with moisture or medication re-
maining in the air tube. This could result in infection as a
result of bacteria.
• Store the device and the components in a clean, safe lo-
cation.
• Do not carry or leave the nebulizer with medication in the
medication tank.
• Do not place or attempt to dry the device, components or
any of the nebulizer parts in a microwave oven.
• Do not wrap the power cord around the compressor (main
unit).
SAFETY INFORMATIONS
The followings are maintenance and repair which can be
taken by operator, or which must be operated by manu-
facturer or distributor..
Overhaul and maintenance
Change the inhalation tube
Cambiare la parte applicata
Change the applied part
Change the surface of the device
Daily cleaning and disinfection
Work on any of the components (in-
cluding fuses and the power cable) for
which repair or replacement requires
dismantling the device
WARNING:
• Do not modify this equipment without authorizaiton of the
manufacturer
• Do not service or maintenance the device while in use
with the patient
MAIN UNIT
1. Power switch 10. Mask(Optional)
2. Holder for Nebulizer 11. Child Mask(Optional)
3. Air plug 12. Adult Mask(Optional)
4. Dust Screen Cover 13. Adult Nasal-piece(Optional)
5. Nebulizer Kit 14. Child Nasal-pieces(Optional)
6. Logo 15. Inhalation Mouthpiece
7. 8Via thermal 16. Air Filter
8. Rubber Foot
9. Tubo di inalazione
The nebulizer kit and mask, nasal-piece, mouthpiece are
applied part
PREPARING THE NEBULIZER FOR USE
CAUTION
• Clean and disinfect the nebulizer kit and optional masks
before using them for the first time after purchase.
• If the device has not been used for a long period of time,
please cleans and disinfects the nebulizer kit and optional
masks before using them.
• To prevent the risk of cross infection, different persons
should never use the same nebulizer kit..
1. At normal use, place the dev ce on a stable, sturdy and
flat surface horizontally, such that the unit can be easily
reached when you are seated. Caution: place the device
at least 10cm distance from walls.
2. Make sure that the unit is in the "off "(0) position by pres-
sing on the right side of switch.
3. Insert the power plug into the electrical outlet.
4. Rotate the inhalation top counterclockwise to remove the
inhalation top from the medication tank.
5. Add the correct amount of prescribed medication to the
medication tank.
6. Turn the inhalation top clockwise until securely closed.
7. Attach the desired inhalation accessory.
ATTACHING THE AIR TUBE
1. Push the Air Plug on one end of the Air Tube onto the Air
Connector on the front side of the compressor.
2. Push the Air Plug on the other end of the Air Tube onto
the Air Tube Connector on the bottom of the Nebulizer Kit.
