CONTENTS ■ ......... 1 Safety precautions ■ ......2 Operation environment ■ ........Introduction ■ ......... Safety Information ■ ......Normal Care and Maintenance ■ ......Installation Requirements ■ ......Electrical Requirements ■ ....11 Requirements for Electric Connection ■ ......
Page 3
Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
Page 4
The refrigerant Should repair be necessary,contact your nearest Before install the Appliance filled authorized Service Centre. Any repairs carried out appliance, read with flammable by unqualified personnel may be dangerous. the installation gas R32. Compliance with national gas regulations shall manual first.
Safety precautions WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Safety precautions WARNING Prohibit inserting any objects into the air conditioner. Do not through sundries into the air duct. If there are sundries get into the air duct, please contact the professionals to deal with it. Do not use an extension cord. Specification of fuse on the main board:T3.15AH250V, the maximum current passes through.
Introduction NOTICE: Room air conditioners cool, dehumidify, and filter air inside Mechanical experience is required to install air condi- your home. Heat pump and electric heat models offer both tioner. heating and cooling. Opening sections of manual provide Installation can take from 1 to 3 hours, depending on general information for all room air conditioner models.
Page 8
OWNER'S PRODUCT IDENTIFICATION WARNING Instructions for installation and use of this MODEL NUMBER product are provided by the manufacturer. SERIAL NUMBER To prevent heat related illness or death,do MANUFACTURING NUMBER not use this device for unattended cooling of persons or animals unable to react to product failure.
page included with this manual or in the mounting kit Unit Plug Receptacle Circuit Rating, Voltage assembly. Follow these instructions carefully. Keep these Type Required Breaker, Time Rating On instructions with this manual for future reference. Your unit Delay Fuse Nameplate will be one of the following three designs: NEMA No.
Page 10
NOTICE: The life of your unit may be greatly reduced Reinstall air filter and grille by reversing removal procedure. if you live in a salt air or other corrosive type environment. Under these conditions, the unit should be removed from Front Grille and Cabinet Cleaning its case and completely cleaned at least once a year.
Page 11
General Operating Instructions To install, remove the unit chassis from the outer case. Insert While operation of all units is similar, controls vary slightly the condensate drain cup through the recessed ½” hole on from model to model. Operating Controls section shows the right side bottom flange of the outer case.
Installation Requirements IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions: Plug into a grounded 3 prong outlet. Do not use an extension cord. Do not remove ground prong. Unplug air conditioner before servicing.
Power cord includes a current interrupter 208/230-volt (198min. - 253 max.) device. A test and reset button is provided on 0-16 amps the plug case. The device should be tested on a 20-amp time-delay fuse or circuit breaker periodic basis by first pressing the TEST button and then the RESET button.
Page 14
WARNING Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock. To test your power supply cord: Plug power supply cord into a grounded 3 prong outlet.
Requirements for Electric Connection Safety precaution Must follow the electric safety regulations when installing the unit. and air switch. Make sure the power supply matches with the requirement of air conditioner. hazard or malfunction. Please make sure the power supply complies with the requirement of air conditioner.
Installation Instructions STORM WINDOW REQUIREMENTS PARTS INCLUDED Window (Appearance may vary) sash seal A s torm window fram e will not allow the Left air conditioner to tilt toward the outs ide, accordion panel and will keep it from draining properly. Foam top To adjus t for this , attach a piece of wood mounting...
Page 17
INSTALL THE CASE IN THE WINDOW Carefully slide the case into the window and center the case. Lower the window behind the top mounting rail. Pull the bottom of the case forward so that the bottom mounting rail is tight against the back of the window stool.
Page 18
INSTALL THE CASE INSTALL SUPPORT BRACKETS IN THE WINDOW (cont.) AND THE FOAM TOP WINDOW GA S K E T Adjust the leveling bolts and nuts against the outside wall so that the case has a slight tilt A ttach the s upport brackets with two to the outside.
Page 19
INS TALL THE AIR CONDITIONER INSTALL THE AIR CONDITIONER IN THE CASE IN THE CASE (cont.) Slide the air Pull the coiled power cord from its shipped conditioner into position in the air discharge area. Attach the case. Do not the front grille frame to the case by inserting push on the the tabs on the grille frame into the slots...
Operating Controls(For Electronic units) Delay Timer Increase (+) / Decrease (-) Pads Operating your air conditioner properly helps you to obtain the best possible results. Each touch of the Increase / Decrease This section explains proper air conditioner operation. pads on the unit will set the delay time when IMPORTANT: using the Delay 0.5–24hr timer ( ).
Page 21
Buttons on remote controller ON/OFF button SAVE MODE button +/- button FAN button SWING button SLEEP button TIMER button Introduction for icons on display screen Timer on Timer off Sending signal auto operation swing operation cool operation sleep operation save operation SAVE lock fan operation...
Page 22
● When selecting auto mode, air conditioner will operate automatically according to ambient temperature. Set temper- ature can't be adjusted and won't be displayed either. Press FAN button to adjust fan speed. (The auto mode is not available for this model.) ●...
Page 23
Function introduction for combination buttons Child lock function Press “+” and “-” buttons simultaneously can turn on or turn off child lock function. When child lock function is started up, LOCK indicator on remote controller is ON. If you operate the remote controller, remote controller won’t send signal. Temperature display switchover function Under OFF status, press “-”...
Preventative Maintenance Qualification of workers Qualification of the working personnel for maintenance, service and repair operations should according to UL 60335-2 -40、CAN/CSA-C22.2 No. 60335-2-40-19 Annex HH.. Every working procedure that affects safety means shall only be carried out by competent persons according to Annex HH. Special training additionalto usual refrigerating equipment repair procedures is required when equipment with FLAMMABLE REFRIGERANTS is affected.
Before Calling Service WARNING To reduce the risk of electric shock,personal injury,or death,turn the fan control to the off position and remove the unit plug from the wall outlet before doing any inspection or maintenace work. The following is a list of problems that are sometimes encountered when using a room air conditioner. Possible cause and suggested remedies are given for each problem.
Thru-wall Installation Instructions Kit RS100 for GREE ® brand Compact Room Air Conditioner Introduction General Instructions This instruction sheet provides guidelines for installing a All GREE brand Compact Room Air Conditioners feature ® compact air conditioner through an outside wall. a slide-out chassis.
Page 27
When case is properly positioned in opening, use wood Brick Veneer or Frame Wall Construction. shims to fill any gaps between case and finished opening, See CAUTION under General Instructions. Cut or build especially in area where case will be secured to opening. rough opening large enough to allow a framed, finished opening 17-inches high and 26 -inches wide.
Specialist’s manual Aptitude requirement for maintenance Presence of fire extinguisher man(repairs should be done only be If any hot work is to be conducted on the refrige- specialists). ration equipment or any associated parts, approp- Any person who is involved with working on or riate fire extinguishing equipment shall be available breaking into a refrigerant circuit should hold a to hand.
Page 29
Specialist’s manual Replace components only with parts specified by are constructed of materials which are inherently the manufacturer. Other parts may result in the ign- resistant to being corroded or are suitably protec- ition of refrigerant in the atmosphere from a leak. ted against being so corroded.
Page 30
Specialist’s manual followed, since flammability is a consideration. The the technician is completely familiar with the equipm- following procedure shall be adhered to: ent and all its detail. It is recommended good practice a) safely remove refrigerant following local and that all refrigerants are recovered safely.
Page 31
Specialist’s manual that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge are available. All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant).
Page 35
LIMITED EXPRESS WARRANTY REMEDY PROVIDED BY THE LIMITED EXPRESS WARRANTY Congratulations on purchasing your new HVAC equipment. It’s been designed for long life and reliable service, and is backed The sole remedy under the Limited Warranty is replacement of the by one of the strongest warranties in the industry.
