Mars HRG14 P Series Installation Instructions Manual

Split system heat pump

Advertisement

Quick Links

Installation and Operation Manual - HRG14xxS1P
HRG14*P SPLIT SYSTEM HEAT PUMP
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.

Table of Contents

Safety Precautions ......................................................2
Installation ...................................................................2
Electrical Connections .................................................5
Start-Up Procedure......................................................6
Operation .....................................................................7
Homeowner's Information .........................................10
NOTE TO INSTALLING DEALER
These instructions and warranty are to be given to the
owner or displayed near the indoor air handler unit.
Improper installation, adjustment, alteration, service
or maintenance will void the warranty. The qualified
installer or agency must use factory-authorized kits
or accessories when added to this products. Refer to
the individual instructions included with the specific
accessory kit.
Manufactured By
Comfort-Aire / Century
1900 Wellworth Ave.
Jackson, MI 49203
506318-03P
INSTALLATION INSTRUCTIONS
(R410A REFRIGERANT)
This manual must be left with the homeowner for future reference.
CAUTION
Save these instructions for future reference
These instructions are intended as a general guide and
do not supersede national, state or local codes in any
way.
Installation or repairs made by unqualified persons can
result in hazards to you and others. Installation MUST
conform with local building codes and with the National
Electrical Code NFPA 70/ANSI C1-1993 or current
edition and Canadian Electrical Code Part 1 CSA C22.1.
Before installing, modifying, or servicing system, main
electrical disconnect switch must be in the OFF position.
There may be more than 1 disconnect switch. Lock out
and tag switch with a suitable warning label. Electrical
shock can cause personal injury or death.
*P506318-03P*
1
Issue 1850
NOTE
WARNING
WARNING
(P) 506318-03P
Page 1 of 11
