Description of Parts & Accessories
1
2
3
8

Attaching the Accessories

CAUTION Ensure that the vacuum cleaner is not connected to the mains supply
before using the attachments.

The Floor Attachment

1. Push the Telescopic Tube (10) onto the Air/Dust Inlet (1) as shown below:
2. Push the Floor Tool (8) onto the other end of the Telescopic Tube (10)
Adjust the lever on the Floor Tool (8) according to the type of floor being
cleaned. Push the lever down for use on hard floors (i.e. non carpeted), pull the
lever up for vacuum cleaning carpets:
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4
9
Cyclone Essential 600W Corded Vacuum
7
1. Air/Dust Inlet
6
2. Cyclonic & Hepa Filters
3. Dust Compartment Release Catch
4. Dust Compartment
5. Handle
6. Air Intake
5
7. On/Off Switch
8. Floor Tool
9. Crevice & Upholstery Tool
10. Telescopic Tube
11. Wall Mount Bracket with Screws &
Plugs
11
Model No. FLR00038
User Manual
10
Appearance of the
bracket may vary slightly
