Fitting The Wall Bracket For Storage Of Your Vacuum Cleaner - Daewoo CYCLONE ESSENTIAL FLR00038 User Manual

Fitting the Wall Bracket for Storage of your Vacuum Cleaner

Fit the Wall Bracket (11) to the wall using supplied Wall Plugs and Screws (or
alternative appropriate fixings for the wall) as follows:
WARNING! Be careful whilst drilling the holes, care must be taken not to
damage concealed cables and pipes in the wall. If in doubt obtain the services of a
qualified tradesman to fit the wall bracket.
1. Choose a suitable position to mount your
vacuum cleaner on the wall.
2. Measure 1 metre above the floor and mark the
wall with a pencil as shown right.
3. Hold the Wall Bracket level on the wall in
line with the 1 metre mark made and mark
the position of the three screw holes
through the Wall Bracket using a pencil as
shown.
4. Remove the Wall Bracket and using the
marks, drill holes in the wall using a suitable
6mm masonry drill bit (not supplied).
5. After drilling the holes, push the three
supplied Wall Plugs into the holes as shown
right:
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
1 & 2
3
4
5
Model No. FLR00038
User Manual
13
