Photoelectric Sensor with Analog Output IRS/IRN/IRD-2LA(-OP)
IRN-2LA/AI/A-I4-OP
II 3(2)G Ex nA [op is Gb] IIB T4 Gc
II 3(2)D Ex tc [op is Db] IIIA T135°C Dc IP67
Technical data
Type of Ex protection Gas, at 94/9/EG
Type of Ex protection Dust, at 94/9/EG
Applicable in Ex Zones
Output signal range, voltage
Output signal range, current
Voltage output, nominal range, on white paper. A4. 80g
Current output, nominal range, on white paper. A4. 80g
Working range, adjustable (on white paper A4, 80g)
Light source
Optical Beam pattern
Response time
Power up delay time
Supply voltage
Current consumption
Maximum power dissipation
Output type, voltage, IR.(-U)-2A
Output type, current, IR.(-U)-2A-I
Input, only types IR.-..-DI (Disable input)
Housing
Enclosure rating, at EN 60529
Vibration and shock resistance
Working temperature range T
amb
Storage temperature range
Connection cable
Connection cable, types IR.-..-DI
Socket, types IRS/IRN-.. S99
Accessories, all types
Accessories, types IRN/IRD-..-OP
Accessories, types IRN-..-OP S99
Accessories, not included, only for IRS/IRN-.. S99
Options:
- Cable length:
- IRS-U/IRN/IRD-2LA(-OP)-DI:
- IRS-U/IRN/IRD-2LA-I4(-OP):
- IRS-U/IRN/IRD-2LA-X(-OP):
- IRS-U-2LA S66:
- IRS/IRN-2LA S99:
- IRN-2LA-I4-OP S110:
- IRS-U-2LA S133:
- IRS/IRN/IRD-2LA-I4(-OP) S137: Reduced optical power for level measurement with the fibre optic type SKM-2000-2-T-FG
- IRS-U/IRN/IRD-2LA(-OP) S155: Response time: 1.5ms.
- IRS-U-2LA S176:
- IRS-U-2LA S177:
Function and LED indication
Wiring and connection
Output diagram
(measured on white paper,
80g, 20cmx30cm)
Potentiometer on MINIMUM and
MAXIMUM
Housing M30
• With voltage or current loop output available
• Applicable for range measurement or position detection
• Applicable as turbidimeter with glass fibre optics
• Also applicable with different types of fibre optics,
also as light barrier
• Type IRD applicable in Ex Zones (0), 1, 2, (20), 21, 22
• Type IRN applicable in Ex Zones (1), 2, (21), 22
Type V-Out IRS-U-2LA
Type I-Out IRS-U-2LAI/-I4
none
none
none
IP 54
-20°C ... +60°C
TPU, AWM 20236, 3+PE x 0.5mm
TPU, AWM 20236, 4+PE x 0.5mm
- 2 nuts M30 (or 1 clamp on request)
- 1x Spare safety screw with packing ring for potentiometer sealing
- 1x Safety lock device, mount at the cable connection,
for locking the connection. (black synthetic device)
- 1x Warning plate
for gluing on the cord set.
- 1x Protection cap for the sensor socket.
- Cordset Lumberg
Up to 100m on request.
With emitter disable input "DI".
Output current 4 - 20mA.
Operational curve function selectable by the polarity of the supply voltage.
Socket M12, Binder 713/4-pins, at cable 200mm, additional optic DL30, range: 5V at a distance of appr. 75cm.
With socket M12, Lumberg RSF5.
With additional optic DL30.
Socket M12, Binder 713/4-pins, at cable 200mm.
and the probe QPR-6/320.
Working temperature range: -20°C to +80°C, additional optic DL30, range: 5V at a distance of appr. 75cm.
Working temperature range: -20°C to +100°C, additional optic DL30, range: 5V at a distance of appr. 75cm.
Light barrier
with fibre optic
Proximity switch
Proximity switch
with fibre optic
The brightness of the LED and the
output level,
quantity of the detected light.
PNP=OFF
R 25Ω
IRS/IRD-..A
V-Out
2 0
18
16
14
12
MIN
10
8
6
4
2 . 5 7.5 12 . 5
ISO 9001:2008 / ATEX
IRD-2LA/AI/A-I4-OP
II 2(1)G Ex d [op is Ga] IIC T6 Gb
II 2(1)D Ex tb [op is Da] IIIB T100°C Db IP67
IRN-2LA-OP
IRN-2LAI/-I4-OP
II 3(2)G Ex nA [op is Gb] IIB T4 Gc II 2(1)G Ex d [op is Ga] IIC T6 Gb
II 3(2)D Ex tc [op is Db] IIIA T135°C Dc IP67 II 2(1)D Ex tb [op is Da] IIIB T100°C Db IP67
(1), 2, (21), 22
0.05VDC - 10.5VDC( Ripple:<20mV)
0.1mA - 21mA (Ripple:<40uA), (4mA - 20mA optional)
5VDC output voltage at a distance of 20cm, adjustable
10mA output current at a distance of 20cm, adjustable
5VDC/20cm or 10mA/20cm
Infrared 870nm
appr.12°
5ms
70ms
24VDC +-15%
60mA
1.4W
PNP, output impedance appr. 25Ω, RLoad: 2kΩ to 1MΩ
NPN, output impedance appr. 500Ω, RLoad: 0Ω to 100Ω
PNP compatible, Ri 10kΩ
M30, brass, nickel plated
IP 67
Vibration: 30g over 20Hz to 2kHz. Shock: 100g for 3ms
-20°C < T < +50°C
amb
-30°C ... +70°C
2
, shielded, leads numbering marked, length: 3m
2 , shielded, leads numbering marked, length: 3m
Lumberg, M12 male receptacle, type RSF 5 contacts
"Do not separate when supply voltage connected", self-sealing,
RKTS 5-298/xx or RKWTH 5-298/xx
Light barrier
with fibre optic
Light beam free
Proximity switch
Proximity switch
with fibre optic
is dependant on the
No light detected. Output=Off, LED=OFF
+24VDC
Output
0.05-
V
10.5VDC
0V (-)
MAX
17. 5 2 2 . 5 2 7. 5 3 2 . 5
Distanz in cm
0158
IRD-2LA-OP
IRD-2LAI/-I4-OP
(0), 1, 2, (20), 21, 22
IP67
-20°C < T < +50°C
amb
Light beam interrupted
+24VDC
0.1-21mA
A
(4-20mA)
R 500Ω
Output
IRS/IRD-..A-I
I-Out
0V (-)
3 7. 5 4 2 . 5 4 7. 5 52 . 5 57.5
