INSTALLATION AND INSTRUCTION MANUAL
ATTENTION!
The device must stand upright.
Always remove all water from the tank before moving the appliance.
The flame viewing area must be made of moisture-resistant materials. If it is made of wood, the wood must be
painted with waterproof paint.
It needs a ventilation grill at the bottom. Only if it is closed with glass at the top, is a ventilation grill also needed at the
top.
For best viewing, it is recommended to decorate the background of the flame viewing area with dark coloured
materials, not bright colours or reflective materials.
Make sure there is enough ventilation in the opening where you want to embed the appliance. Also, when positioning
the appliance, please avoid places near doors or windows, where air currents can be created that influence the
appearance of the flame.
ElectricSun
Electric Model
Fireplace Type
MISTique SKU: ESvapor60
60 cm 6426538000468
MISTique SKU: ESvapor100
100 cm 6426538000475
MISTique
SKU: ESvapor120
120 cm
MISTique SKU: ESvapor150
150 cm 6426538000598
www.ElectricSun.de
3D Water Vapour Fireplace
Power Supply Voltage
(Watts) (Volts)
AC 220-240V,
190 W
50/60Hz
AC 220-240V,
290 W
50/60Hz
AC 220-240V,
330 W
50/60Hz
AC 220-240V,
390 W
50/60Hz
E-mail: office@electricsun.de
ElectricSun MISTique
1. Overall dimensions
2. Embedding dimensions
Colour
3. Installation hole size
(Millimetres)
600 x 236 x H 225 mm
Black 585 x 200 x H 225 mm
590 x 215 x H 230 mm
1000 x 236 x H 225 mm
Black 985 x 200 x H 225 mm
990 x 215 x H 230 mm
1200 x 236 x H 225 mm
Black 1185 x 200 x H 225 mm
1190 x 215 x H 230 mm
1500 x 236 x H 225 mm
Black 1485 x 200 x H 225 mm
990 x 215 x H 230 mm
Water
Weight
tank
(Kilograms)
(Liters)
2,5 L 16 kg
5 L 20 kg
6 L 24 kg
7,7 L 28 kg
