  • Page 1 TDI User Manual...
  • Page 2 Tucor, Inc. This publication is intended only to assist the reader in the use of the TDI controller. Tucor, Inc. shall not be liable for any loss or damage arising from the use of any information in this publication, or any error or omission in such information, or any incorrect use...

  • Page 3: Table Of Contents

    Connecting the TDI to 24VAC and Ground ..................9 3.1.3. Connecting the Master Valve ......................10 3.1.4. Connecting the Main Controller Outputs to TDI Station Inputs ............11 3.1.5. Connecting the Flow Input and Flow Output ..................12 3.1.6. Connecting the Alarm Output ......................13 3.1.7.
  • Page 4 When there is a Short Circuit in the Field ..................... 50 8.4.1. Using a Clampmeter .......................... 51 8.4.2. Locating the Short ..........................51 Appendix A. Flashing new Firmware to the TDI System ....................55 A.1. Requirements ............................... 55 A.1.1. Installing the USB driver ........................55 A.2.

  • Page 5: Chapter 1. Introduction

    1.3. The TDI Extender The TDI system may be expanded with the TDI Extender - an interface board like the TDI itself but without the display and control panel. By adding the TDI Extender to your TDI system you may increase the capacity...
  • Page 6 The TDI Extender with up to another 48 stations and an additional master valve. The master valve operates in parallel with the existing master valve input. The TDI Extender connects to the TDI system via the expansion terminal on the TDI board.

  • Page 7: Chapter 2. Technical Specifications

    The core of your TDI system is the TDI Board that manages the integration between your main controller and the stations. In the sections below you will find a description of the layout of the TDI Board and its input and output terminals.

  • Page 8: Station Inputs

    The Flow output terminal is determined by the flow input, but modified by the divisor and pulse width. If the divisor is set to x, then for every x flow input pulses, the TDI will generate an output pulse of at least the specified width.

  • Page 9: The Tdi Extender

    For more information, turn to Section 3.1.7, “Connecting the Two-wire” [14]. Warning While the TDI is running, a short on the two-wire will not clear the display and thus it might still display active stations even if they are not active. 2.2.8. Master valve activation Use this terminal to connect a push button which may turn on the master valve when activated.
  • Page 10 The TDI Extender...

  • Page 11: Chapter 3. System Installation

    • Connecting Decoders for Programming • Connecting the TDI Extender to the TDI Board In the following, each of these procedures are depicted in simple illustrations. Turn to the TDI Installation diagram at the end of this chapter for a full overview.

  • Page 12: Installing The Tdi Board In The Cabinet

    Ensure that the board is not shorted before applying power, or damage may occur. The photo below shows an example installation of a TDI with a typical controller. Please refer to the following sections for connecting the various terminals of the TDI Board.

  • Page 13: Connecting The Tdi To 24Vac And Ground

    Using a flat head screwdriver connect the 24VAC terminals to the 120 V mains using a suitable transformer (supplied by the customer). Also, to help secure your system against lightning, you must ensure that the TDI is grounded. Refer to the illustration below and to the TDI Installation diagram at the end of this chapter.

  • Page 14: Connecting The Master Valve

    Connecting the Master Valve 3.1.3. Connecting the Master Valve In terms of master valve connections, the TDI Board allows for the following: • Connection of the master valve to the primary controller. • Connection of a push button (supplied by the customer) for the manual activation of the master valve.

  • Page 15: Connecting The Main Controller Outputs To Tdi Station Inputs

    3.1.4. Connecting the Main Controller Outputs to TDI Station Inputs Using a flat head screwdriver, connect the main controller's outputs to the TDI station inputs. Refer to the illustration below and to the TDI Installation diagram at the end of this chapter.

  • Page 16: Connecting The Flow Input And Flow Output

    Using a flat head screwdriver, connect the flow input and flow output. Refer to the illustration below and to the TDI Installation diagram at the end of this chapter. Refer to Section 6.5, “Setting Up FloGuard” [31] for information on setting the flow input and output.

  • Page 17: Connecting The Alarm Output

    3.1.6. Connecting the Alarm Output Using a flat head screwdriver, refer to the illustration below and to the TDI Installation diagram at the end of this chapter for information on connecting the alarm output. Refer to Section 6.3, “Setting the Alarm...

  • Page 18: Connecting The Two-Wire

    Using a flat head screwdriver, connect the two-wire by fastening it to the two-wire terminals (Line 1 and/or Line 2). A and B are required on each 2-wire. Refer to the illustration below and to the TDI Installation diagram at the end of this chapter.

  • Page 19: Connecting Decoders For Programming

    Refer to the illustration below and to the TDI Installation diagram at the end of this chapter. Once connected, you can assign an address to the decoder from the TDI panel. You can also test that the decoder is fully functional. For information on programming and testing decoders turn to Chapter 6: Configuring...

  • Page 20: Connecting The Tdi Extender To The Tdi Board

    TDI Board 3.1.9. Connecting the TDI Extender to the TDI Board Use the expansion terminal to connect the optional TDI Extender to the TDI Board enabling the expansion of up to 48 additional stations and a master valve. Using a flat head screwdriver connect the wires as follows: •...

  • Page 21: Tdi Installation Diagram

    TDI Installation Diagram 3.2. TDI Installation Diagram Refer to the TDI Installation diagram below for a full overview of the TDI Board and its terminal connections.

  • Page 23: Chapter 4. Operating The Tdi

    4.1. The Display The TDI has a back lit LCD display with two rows of 16 characters. Since the limit is 16 characters per row, sometimes words are abbreviated, but all messages should still be easy to understand. If in doubt about a message, consult this manual.

  • Page 24: Navigating The Menus Of The Tdi

    Navigating the Menus of the TDI 4.3. Navigating the Menus of the TDI 1. Use the item selectors to toggle (move right and left) and scroll (move up and down) through the menus of TDI. 2. In case more than one option is available in a particular menu or view, you will see Up and Down arrows.

  • Page 25: Chapter 5. Running The Tdi

    1. Power up the TDI. For a few seconds the current firmware information and the TDI number shows on the screen. While the TDI is turned on, the POWER ON LED will light green, and the LINE OUT LED will flash red/green every ½...

  • Page 26: Displaying Controller Status

    (in Hz), and tells how many gallons per minute (GPM) this corresponds to. When setting up the TDI, you define what type of flow sensor should be used, i.e., how it should convert from pulses to gallons. For more information, turn to Defining the Flow Input.

  • Page 27: Displaying The Totalizer Output

    If no stations are running, this view will not display anything. 5.2.5. Displaying the Alarm Status When the ALARM LED on the TDI panel indicates that one or more alarms have been detected, proceed to the Alarm Status view to get an overview and determine what action to take.
  • Page 28 Displaying the Alarm Status Note For each alarm type you may set the reaction type. For more information, turn to Section 6.5, “Setting Up FloGuard” [31]. To display the alarm status: 1. In the Main view, use the item selectors to scroll sideways to the Alarm Status view. 2.

  • Page 29: Chapter 6. Configuring The Tdi

    2. Test the decoder. To program a decoder: 1. Connect the decoder’s white and blue wires to the sockets labelled White and Blue on the TDI. 2. Scroll sideways to the Main menu, then scroll to the Dec Program menu, and press ENTER.

  • Page 30: Setting The Alarm Output

    5. Scroll through the IDs (ST1, ST2, ST3, etc). Press ENTER two times to confirm your selection. 6. The TDI will use a few seconds to verify the ID, then prompt you to label the decoder for future identification. Press ENTER.

  • Page 31: Configuring Relay Alarms Output

    Configuring Relay Alarms Output • Via the relay output • Via the master valve output The following two sections deal with configuring the alarm output and setting the reaction type for each alarm type. Note The thresholds for each alarm type is set under FloGuard. For more information turn to Section 6.5, “Setting Up FloGuard”...
  • Page 32 Configuring Relay Alarms Output 5. Press ENTER to confirm your selection. 6.3.1.2. Setting the Relay Default State for the Individual Alarm Type To set the relay default for the each alarm type: 1. Scroll sideways to the Main menu, then scroll down to the Alarms menu, and press ENTER. 2.

  • Page 33: Configuring Master Valve Alarms Output

    Configuring Master Valve Alarms Output 6. Press ENTER to make your selection. 7. Repeat steps 4 to 6 for each relay alarm. Note The thresholds for each alarm type is set under FloGuard. For more information turn to the section "Setting Up Floguard" later in this chapter. 6.3.2.

  • Page 34: Configuring Current Alarms

    Configuring Current Alarms 6.4. Configuring Current Alarms Current alarms enables you to monitor the standby current level on the two-wire (i.e. when no decoders are running). As part of configuring current alarms you need to set the current limit and the reaction delay. These are set under the menu option in the menu.

  • Page 35: Setting Up Floguard

    Setting Up FloGuard 6.5. Setting Up FloGuard The FloGuard feature is your insurance that no excessive flow will occur, neither while the system is active nor when it is idle. More precisely, using FloGuard you tell the system how to protect your system from excessive flow in different situations and how to react.

  • Page 36: Setting The Reaction Delay For Floguard Alarms

    3. Use the item selectors to set the limit for each alarm in turn, and press ENTER 4. Press until you are back at the TDI main view. CANCEL 6.5.2. Setting the reaction delay for FloGuard alarms This setting indicates the time period (in minutes) in which the alarm condition (high flow alarm, unscheduled flow alarm, and master pump failure) must remain active before an actual alarm is triggered.

  • Page 37: Setting The Flow Output

    • The "K" value can be looked up in the data sheet for your sensor. 4. Press to confirm your selection, and then press until you are back at the TDI main view. ENTER CANCEL 6.5.4. Setting the Flow Output When setting the flow output you may indicate a division factor (a divisor) and a pulse width.

  • Page 38: Setting The Totalizer Output

    Setting the Totalizer Output 5. Press to confirm your selection, and then press until you are back at the TDI main view. ENTER CANCEL 6.5.5. Setting the Totalizer Output The totalizer value signifies the number of gallons measured before a pulse is generated. When the sum has been reached a pulse will be generated.

  • Page 39: Setting The Master Valve Override

    2. Use the item selectors to set the time period (in hours). The range is 1 to 12 hours press ENTER to confirm your selection. 6.7. Adjusting the Power Levels TDI allows you to adjust the power levels for each station and the master valve independently. Choose between: • Normal power •...

  • Page 40: Adjusting The Master Valve Power

    Adjusting the Master Valve Power 2. Scroll down to the ST Power command, and press ENTER. 3. Choose between Normal power, High power, Higher power and Highest power. 4. Press ENTER to confirm you selection. 6.7.2. Adjusting the Master Valve Power To adjust the power levels for the master valve: 1.

  • Page 41: Checking The Number Of Active Stations

    6.7.4. Checking the Number of Active Stations Increasing the power levels for your stations mean that fewer stations in your system may be simultaneously active. The TDI lets you supervise the impact of changing these settings. To check the number of active stations: 1.
  • Page 42 Resetting Data 1. Scroll sideways to the Main menu, then scroll down to the Data Reset menu, and press ENTER. 2. Press ENTER again to confirm you want to reset your configuration data.

  • Page 43: Chapter 7. Troubleshooting From The Tdi

    7.1.2. Running the Electrical Test The TDI has a built-in test that will activate each station in turn for just one second in order to check if they are responding correctly. The stations must be connected to the solenoids that activate valves in the landscape, and the test can tell whether the stations and solenoids are working correctly in conjunction.

  • Page 44: The Built-In Short Finding Test

    7.1.3. The Built-in Short Finding Test If you suspect your system has a short somewhere in the field, use the built-in short test in the TDI. This test won't tell you anything you can't already see if you've configured the controller to display voltage and...

  • Page 45: Testing The Two-Wire Path

    The first indication that you might have a short or a fault somewhere on the two-wire path is that the Line Out indicators (the green and red LEDs on the TDI) will flicker very quickly, or be not lit at all.

  • Page 46: Increasing Station Power

    Increasing Station Power There are two stages of testing the two-wire for shorts: you can run a built-in short test from the TDI, and if something seems wrong, you can inspect the two-wire in the field, using a clampmeter. 7.3. Increasing Station Power In case the stations are not giving out enough power for the valves or pumps to pull open, it is possible to increase the power.

  • Page 47: Chapter 8. Troubleshooting In The Field

    (refer to Section 3.1.7, “Connecting the Two-wire” [14]). If the high current disappears, the two-wire is the problem. If the high current remains, the TDI has the fault. To get a more precise idea of how your current reading should be, you should add the standby usage and...
  • Page 48 If the power reading is below 25V The field installation is consuming so much power that the TDI has lowered the power on the two-wire, and you should go locate the problem in the field (See Section 8.4, “When there is a Short Circuit in the Field”...

  • Page 49: Problems On The Two-Wire

    12-15mA 24-30mA 36-45mA 48-60mA 60-75mA You might have a problem somewhere on the two-wire (+20% - +50%) causing an excess consumption. The TDI can handle this, but you could be looking at problems that dramatically increase under wetter conditions. See Section 8.1.1, “Problems on the...

  • Page 50: Dealing With Unstable Stations

    The resistance between the station and TDI the is 0.75*R To find out whether your loop is broken, follow this procedure: Open the loop in one end - if the loop goes all the way back to the TDI, just detach one of the two-wires on the controller.

  • Page 51: Dealing With Failing Stations

    Perform an "electrical test" as described in "Running the Electrical Test" in Chapter 7: Troubleshooting from the TDI. This will activate each in turn - if you see stations failing, chances are that they are on a stretch of the two-wire that has been orphaned by a break of the loop in the field.
  • Page 52 • Take the station to the TDI and perform a direct test before replacing it. If the station fails with too high current reading • Check the two-wire between the solenoid and the station for cracks in the insulation or bad connections.

  • Page 53: Several Stations Fail

    Several Stations Fail Figure 8.2. Testing the path to a station 8.3.2. Several Stations Fail Here is a checklist if multiple stations fail: • If two stations are configured with identical IDs you can get a rather confusing behavior in the system. Imagine the following scenario: •...

  • Page 54: When There Is A Short Circuit In The Field

    But you can't always be sure that the TDI will be able to detect a short circuit in the field - if the short is in the far end of the cabling, the controller may just experience it as heavy usage. However, the current reading will always reveal a short as the current will be significantly higher than normal.

  • Page 55: Using A Clampmeter

    This means that you can "follow the current" and eventually be led to the short: Figure 8.4. Faulty station Note If your installation loops back to the TDI you must open the loop, or you won't know which way the current is running around the loop and troubleshooting will be almost impossible. Note...
  • Page 56 Make a note of your readings as you'll use these for comparison if you need to locate a faulty branch in the field. • If one of the cables connected to the TDI loops back to the controller, you must open the loop before measuring.
  • Page 57 • If you get no readings from either branch, the problem is on the part of the two-wire leading back to the TDI - perform a binary search (see procedure below) on this part of the cable. • If your readings on one of the branches are the same as when measuring at the controller (This is the first thing you do when troubleshooting the two-wire you move on further out one branch at a time, measuring in every fork you meet (J2, J3, J4 etc.) until you locate the faulty branch).
  • Page 58 Locating the Short When you locate the faulty branch, move on and perform a binary search. See next section. Procedure 8.4. Phase III: Performing a "Binary Search" on a Faulty Branch A binary search can help you locate a problem on the two-wire in a structured manner. The concept of a binary search is this: Find a point on the cable where you know for sure current is running.

  • Page 59: Appendix A. Flashing New Firmware To The Tdi System

    Appendix A. Flashing new Firmware to the TDI System This appendix contains procedures for flashing new firmware to both the TDI Board and the TDI Extender. Note The most recent firmware version is available from Tucor. Please check www.tucor.com for contact information.

  • Page 60: Flashing New Firmware To The Tdi Extender

    Press 4 to re-start. Remove the USB cable. Proceed to the TDI Vers Info screen to verify that the firmware has been updated successfully. A.3. Flashing New Firmware to the TDI Extender Connect the USB cable to the extender board and select upgrade mode for the extender board. Continue from step 6.
  • Page 61 Flashing New Firmware to the TDI Extender 3. On the TDI Board, use the item selectors to scroll to main menu, then select Ext upgrade. 4. Repeat steps 6 through 17 from procedure A.2 Flashing New Firmware to the TDI Board.
