- Page 1 MimioPro G Interactive Display User Manual – Aug 2023 Note All the pictures in this manual are for reference only, subject to our available products. To learn more, visit boxlight.com or call 866.972.1549.
-
Page 2: Table Of Contents
Remote Control Instructions ................... 13 Range of Remote Control ....................14 Connections and Setting ....................14 Troubleshooting ......................17 Maintenance ........................22 Clean Screen ......................... 22 Clean Frame ........................22 Recommendation for Extended Breaks ................22 To learn more, visit boxlight.com or call 866.972.1549. -
Page 3: Safety Warning
• Use the original power cable from the accessory bag, don't modify or lengthen it. • Unplug the power supply, when there is nobody home or the unit will be in idle for a long time. To learn more, visit boxlight.com or call 866.972.1549. -
Page 4: Led Screen General Care
2 hours, making sure the moisture inside the unit is all evaporated. Humidity & Ventilation Make sure indoor environment is dry and cool. Normal operating humidity is 10%~90%RH. To learn more, visit boxlight.com or call 866.972.1549. -
Page 5: Earphone
Caution risk of fire or explosion if the battery is replaced by an incorrect type. Cleaning Instructions There are vents on the back cover, please do not use any liquid or spray directly during cleaning. Power Switch Status “I” means power on, “O” means power off. To learn more, visit boxlight.com or call 866.972.1549. -
Page 6: Control Panel
Control Panel Prepare to install. To learn more, visit boxlight.com or call 866.972.1549. - Page 7 : Tap to enter energy-saving, press at least 2 seconds to enter standby mode Loudspeaker Light sensor Microphone Temperature and humidity sensor: Detect the temperature and humidity of the environment. CO2 sensor: Detect the CO2 concentration of the environment. To learn more, visit boxlight.com or call 866.972.1549.
-
Page 8: Terminal Interface
If the charging power of the electronic device exceeds the rated charging power of this port, please Do not directly use this port for charging. Connect USB devices such as mobile hard disk, U disk, USB keyboard and mouse, USB drives, etc. To learn more, visit boxlight.com or call 866.972.1549. - Page 9 Serial interface, used for mutual transfer of data between devices. AC IN AC power input, connect AC power supply. To open or shut down AC power supply. “I” means power on, “O” AC SWITCH means power off. To learn more, visit boxlight.com or call 866.972.1549.
-
Page 10: Remote Control
Remote Control To learn more, visit boxlight.com or call 866.972.1549. - Page 11 Alt+Tab PC's Alt+Tab key Alt+F4 PC's Alt+F4 key Numeric keys Numeric input Display Display channel information Input Pop up settings menu Home Return to Android system main screen Menu Pop up menu To learn more, visit boxlight.com or call 866.972.1549.
- Page 12 Pop out or close the screen freezing tools Blue Turn off or turn on the screen backlight PC's Backspace Scroll Up Scroll Left Scroll Right Scroll Down Enter Confirm selection state Quickly start writing software To learn more, visit boxlight.com or call 866.972.1549.
-
Page 13: Remote Control Instructions
("+"to"+", "-" to "-"), please do not mix using old and new batteries. 3. After battery is installed, close the back cover of battery components, and buckle the clip to the bottom. To learn more, visit boxlight.com or call 866.972.1549. -
Page 14: Range Of Remote Control
If battery is replaced by an incorrect type, it may lead to explosion. Connections and Setting For the safety of you and the machine, please do not connect any power before connection. External Computer and Touch Device To learn more, visit boxlight.com or call 866.972.1549. - Page 15 2. After cable connection, plug in the power cord, and switch power on. 3. Press to turn equipment on. 4. Switch the input source to the HDMI channel in the main menu. USB Connection To learn more, visit boxlight.com or call 866.972.1549.
- Page 16 1. Use HDMI cable to connect audio and video equipment with HDMI input. 2. After cable connection, plug in the power cord, and switch power on. 3. Press to turn equipment on. Audio Out LAN Connection To learn more, visit boxlight.com or call 866.972.1549.
-
Page 17: Troubleshooting
Check whether there is a sudden power outage. The system will automatically shut down if the interactive intelligent Panel's external channel loses signal for 5 minutes. Please check the input and connection of the signal. To learn more, visit boxlight.com or call 866.972.1549. - Page 18 Adjust clock and phase position in menu. Image lack of Color, Color is Incorrect Check whether VGA is not well connected or has quality problem. Adjust chromatic and brightness or contrast in menu. To learn more, visit boxlight.com or call 866.972.1549.
- Page 19 Adjust clock and phase position in menu. Touch Function Touch Function is Invalid Check whether the size of article touched is comparable with finger. Touch Positioning is Incorrect Check whether touch pen is facing the screen. To learn more, visit boxlight.com or call 866.972.1549.
- Page 20 Check whether other electronic equipment or power tools are placed around the machine. No Color, Color is Weak or Image is Weak Adjust chromatic and brightness or contrast in menu. Check whether signal wire is well connected. To learn more, visit boxlight.com or call 866.972.1549.
- Page 21 Adjust sound balance in menu. Check whether computer sound control panel only sets up one sound channel. Check whether audio line is connected correctly. HDMI Output Without Sound Check whether connect external device. To learn more, visit boxlight.com or call 866.972.1549.
-
Page 22: Maintenance
In case of no use of machine for a long time, such as holiday, please make sure to unplug the plug to prevent any possible dangers caused by power supply ripple from lightning. To learn more, visit boxlight.com or call 866.972.1549.
