Summary of Contents for TechniSat iMETEO P1
- Page 1 P1 user manual Weather station with temperature, pressure and weather trend function, equipped with an external measuring sensor and projector.
- Page 2 Notes on recycling Your new device was protected by the packaging on its way to you. All materials used are environmentally friendly and recyclable. Please help us to dispose of the packaging in an environmentally friendly manner. Please contact your retailer or local waste disposal facility for information on current disposal methods.
- Page 3 affects the recovery of secondary raw materials. If this product is not disposed of properly, penalties may be imposed in accordance with national legislation. 1. Introduction Security Read all safety instructions carefully and keep them for future reference. Always follow all warnings and instructions in this manual and on the back of the appliance.
- Page 4 - Do not open the housing. Otherwise there is a risk of electric shock. - Never attempt to repair a defective unit yourself. Always contact one of our customer service centres. - Do not open the unit under any circumstances - this can only be done by a specialist.
- Page 5 2. Special functions of the device - DCF radio clock - Time format 12 or 24 hours - Calendar to 2099 - Display of days of the week in 7 languages: English, German, Italian, French, Spanish, Dutch and Danish. - Alarm and snooze function - Low battery indicator - Comfort level indicator - Relative humidity: Indoor and outdoor measurement range:...
- Page 6 Note on battery selection and DCF time retrieval The external sensor can operate at temperatures from -30°C to +70°C. The zinc-manganese alkaline battery can operate at temperatures from -20°C to +60°C. The lithium-ion polymer battery can operate at temperatures from -40°C to +70°C. A CR2032 battery (not supplied) is the reserve power source for the weather station.
- Page 7 3. View of the device...
- Page 8 Base station front A1: Time A2: Calendar A3 : Week A4: Weather forecast A5: Temperature outside A6: Humidity outside A7: Humidity inside A8 : Internal temperature Rear base station B1: SET button B2: ALARM button B3 : MAX/MIN button B4: SNOOZE/LIGHT button B5: +/CH button B6: -/C/F button button B8 :...
- Page 9 C2: External humidity C3: Transmission LED C4: Unit selection °C /°F C5 : Manual transmission with transmitter (TX) C6: Channel switch C7: Battery compartment 4. First configuration of the device a. Switching on the weather station for the first time - Connect the 5V DC (600mA) power supply to the power connector (B13).
- Page 10 b. DCF radio signal reception - The unit will start automatically picking up the DCF signal 7 minutes after start-up or after a battery change. The radio mast icon will flash (the screen will dim). - Each day at 1:00 / 2:00 / 3:00 a.m., the unit automatically synchronises the time settings according to the received DCF signal, thus correcting any deviation from the correct time indication.
- Page 11 c. Device configuration - Press and hold the SET button (B1) for 3 seconds to enter the setting mode. The display will start to flash "ON" - Use the +/CH (B5 ) and -/C/F (B6) buttons to set the radio control timing function to ON or OFF.
- Page 12 - Press the SET button (B1) to confirm the setting and complete the configuration, the unit will return to normal display mode. Additional information - If no settings have been made within 20 seconds, the device will automatically return to normal display mode. - When making a selection, longer pressing the +/CH (B5) and -/C/F (B6) will change parameters more quickly.
- Page 13 If M-F and S-S are set together, the alarm will be active throughout the week. - Press the ALARM button (B2) to confirm the setting, the snooze time minutes will flash on the display. Use the +/CH (B5) and -/C/F (B6) buttons to set the snooze time minutes.
- Page 14 temperature and humidity, from an external sensor, after connection to a 5V DC power supply. - The outdoor sensor automatically transmits temperature and humidity data to the weather station when the batteries are inserted. - The station can be connected to three external sensors at the same time (channels: 1,2,3).
- Page 15 If there are any discrepancies between the forecasts, the forecast from the local weather station should be used. If there is a discrepancy between the forecasts, the forecast from the local weather station should be used. 9. Pressure trend The station allows the pressure trend to be displayed - The following indications are visible: pressure increases pressure does...
- Page 16 Customer Service Tel: 071 310 41 41 e-mail: biuro@technisat.com TechniSat Digital Sp. z o.o. hereby declares that the IMETEO P1 me- teorological station is compliant with Directive 2014/53/EC and RoHS. The full text of the EU Declaration of Conformity is available at the following internet address: hמּp://konf.tsat.de/?ID=23023...
