- Page 1 Pro Electra fORTADOR'' INDUSTRIAL STEAM CLEANER OPERATING MANUAL...
-
Page 2: Note
NOTE Before starting the machine, read this operating manual carefully to avoid improper use or situations that may be dangerous for people, animals or objects. The manufacturer shall bear no responsibility and shall exclude the possibility to apply guarantee terms in the following cases: any misuse or use in improper conditions, any damage resulting from normal wear-out or aging, inappropriate application, neglect, improper operation or storage, exposure to moisture, arbitrary modification or repair, improper installation, using wrong power supply source, operator errors, failure to follow this operating manual, or... -
Page 3: Table Of Contents
CONTENTS Note............................Contents..................................Introduction .................................. Technical specification ..............................Description of the machine ............................Safety requirements ............................... Unpacking ..................................Before each start-up ............................... How to install and use the machine for the first time ....................Cleaning ..................................Control panel functions ............................... Switch-off procedure .............................. -
Page 5: Introduction
INTRODUCTION Thank you for purchasing FORTADOR PRO Electra industrial steam cleaner. The FORTADOR brand is an effect of our long-standing experience, and a response to our Customers’ needs. The technology confined in the state-of-the-art enclosure provides for higher capacity and performance as well as lower failure rate than ever before. -
Page 6: Technical Specification
Technical data are placed at the rating plate at the rear wall of the cover in the area marked with the red frame. When contacting our Service Dept., please always refer to your machine’s serial no. from the rating plate. Fortador Pro Electra 400V 11,5Kw / 15,5Kw Ciśnienie pompy wody:... -
Page 7: Description Of The Machine
DESCRIPTION OF THE MACHINE 1. Tanks of water and detergent 2. Boiler 3. Hydraulic braid, washing – wet steam sensor, oblique filter 4. Pressure sensor (pressure switch) 5. Water pump 6. Wet steam and detergent pumps 7. Water filter Washing hose connection - safety quick coupling, valve Washing hose connection - safety quick coupling, valve Water drain - valve Detergent drain - valve... -
Page 8: Safety Requirements
SAFETY REQUIREMENTS The FORTADOR steam cleaner is an industrial machine that must not be operated by persons who are unaware of the hazards associated therewith. The guidelines and recommendations contained in this manual must be properly understood and followed, for proper and safe operation of the device. - Page 9 • Service department: help@fortador.com. • Do not pull or lift the machine by the power cord or hoses. • The machine should be installed on stable level ground. Make •...
-
Page 10: Unpacking
UNPACKING 1. Carefully remove the machine from its packaging. 2. Inspect the device for damage during delivery. STANDARD ACCESSORIES 3. Check for missing standard equipment. We recommend that you keep the packaging. Packaging dimensions Washing hose 2 pcs. Short lance, 1 piece Repair kit Briefcase (optional) -
Page 11: Before Each Start-Up
BEFORE EACH START-UP This procedure should be carried out before starting the machine to ensure its proper and safe operation. 1. Check if your hoses have been properly connected. 2. Make sure your valves work properly. 3. Refill the water tank. 4. -
Page 12: How To Install And Use The Machine For The First Time
HOW TO INSTALL AND USE THE MACHINE FOR THE FIRST TIME Startup procedure for the FORTADOR PRO Electra device Detergent tank Water tank Fill up the water and detergent tank, for the option with water pump, connect the fixed water connection to the valve number 12. - Page 13 Touch the button on the display to start the machine. The machine will automatically start filling the boiler with water, while when the minimum water level is reached, the heaters will turn on. After 2-7 minutes, the pressure will reach 16 bar. This information will be displayed on the screen.
-
Page 14: Cleaning
CLEANING Holding the pistol with both hands, press the trigger. Note: high pressure causes the pistol to kickback when the trigger is pressed. Exercise caution! Work with both hands. Pull on the hose, not the pistol! Don't pull the pistol by the hose! When moving around, never pull on the pistol, as this may damage the hose connection with the pistol or damage the pistol itself. - Page 15 Removing severe soiling may also require the application of detergent with steam jet. Before activating this function, the DETERGENT tank must be refilled with detergent diluted with water in the proportion described on the detergent label. NOTE: Failure to follow the steps in the right sequence may result in damage to the detergent pump! High-foaming and acidic preparations are not...
-
Page 16: Control Panel Functions
CONTROL PANEL FUNCTIONS Main screen The white color of the water indicator Main screen and the orange color of the detergent 1 indicator indicates sufficient liquid level. Button that Button that activates the activates the information screen service screen Button to start detergent feeding Detergent 1 level indicator... - Page 17 Service screen Boiler water level indicator shows current water level (H - high, M - medium, L - low) ,by Boiler water level highlighting the corresponding indication indicator (L- in yellow. minimum, M-average, H- maximum) Return to main Information screen screen Heaters ON Water pump operation...
-
Page 18: Switch-Off Procedure
SWITCH-OFF PROCEDURE To ensure the longest possible life of your FORTADOR machine, take care of the device and follow the shut-down procedure outlined. Switch the machine off using the touch screen button, then disconnect it from its power supply. NOTE: failure to observe this sequence may cause damage to the machine controller. - Page 19 Clean the machine from dirt, if any. Cleaning the machine each time after operation ends will keep it in very good technical condition for a long period of time. Leave the machine in a dry, warm and dust-free place. Storing the machine in room with temperature below 0ºC (32 F) requires emptying machine...
-
Page 20: Maintenance Plan
MAINTENANCE PLAN The FORTADOR steam cleaner is made of the best materials and to keep it in perfect condition, it requires periodic maintenance, according to the following maintenance schedule. TIME INTERVAL MAINTENANCE TASKS (NO. OF MOTO-HOURS) Cleaning the water filter... -
Page 21: Service Screens
SERVICE SCREENS After reaching a relevant number of moto-hours, in line with the maintenance schedule, the FORTADOR Pro Electra steam cleaner will automatically report the need to check the relevant components by displaying a given service screen, as appropriate. Water filter cleaning required... - Page 22 Required descaling of the device Required technical inspection...
- Page 24 Diagnosis 1 problem Freezing pipes in the boiler supply path during the winter This indicates that the machine was left to "freeze" at season, bubbles in the water path pipes, a broken water filter, temperatures below 0 centigrade without emptying a damaged water pump.
- Page 25 Prevention Regular descaling and protection against freezing of the water path of the FORTADOR cleaner, not allowing the water pump to run dry. Solution Fill the water tank "up to the cap" so that the water level in the tank is higher than the height of the water filter. Loosen "glass" of the water filter so that the filter is freely filled with water, then remove the transparent tube from the inlet to the water pump and let the tube fill completely, with a vigorous movement put it back in its original place.
- Page 26 Diagnosis 7 problem • Accumulation of electrostatic charge Touching the machine or hose causes a slight tingling • on the device surface (flow of liquids and gases in plastic or sensation. Teflon hoses). • High humidity in the workplace of the machine, especially in Asian countries or rooms with poor ventilation.
- Page 27 The prerequisite for proper protection against electric shock is periodic inspection of electrical installations by authorized entities. Please use extreme caution when repairing and adjusting the machine, as most of the elements are very hot and direct contact may result in serious burns. Due to the fact that the device is a pressure device, please be especially careful when operating or adjusting the device, if the pressure system is unsealed during operation, you may be seriously burned by high temperature steam.
-
Page 28: Ce Declaration Of Conformity
DECLARATION OF CONFORMITY Fortador K.A. Traczyńscy S.K.A. Manufacturer Aleja Krakowska 108 05-090 Sękocin Stary, Poland Product designation Steam car wash Trade name Fortador Model name Pro Elektra Directive No. 89 / 336 / EEC Voltage during test AC 230 V / 50 Hz... -
Page 29: Transport
“Switch-Off Procedure”, par. 10-12. FINAL REMARKS When properly operated and maintained, this FORTADOR steam cleaner can provide long years of reliable operation. Problems that may occur when using the machine should be solved before it is started. While operating any machine, it is necessary to know its normal operation in order to be able to identify its improper operation. - Page 30 www.fortador.com...
