TX -680RDS
Natural Sound AM/FM Stereo Tuner
Syntonisateur AM/FM stéréo de la série "Natural Sound"
"Natural Sound" MW/UKW-Stereo-Tuner
Natural Sound AM/FM stereotuner
Sintonizzatore stereo AM/FM a suono naturale
Sintonizador estéreo de AM/FM de sonido natural
Natural Sound Stereo Tuner
OWNER'S MANUAL
MODE D'EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
Advertisement
Table of Contents
Related Manuals for Yamaha TX-680RDS
Summary of Contents for Yamaha TX-680RDS
- Page 1 TX -680RDS Natural Sound AM/FM Stereo Tuner Syntonisateur AM/FM stéréo de la série “Natural Sound” “Natural Sound” MW/UKW-Stereo-Tuner Natural Sound AM/FM stereotuner Sintonizzatore stereo AM/FM a suono naturale Sintonizador estéreo de AM/FM de sonido natural Natural Sound Stereo Tuner OWNER’S MANUAL MODE D’EMPLOI BEDIENUNGSANLEITUNG BRUKSANVISNING...
-
Page 2: Supplied Accessories
SUPPLIED ACCESSORIES ACCESSOIRES FOURNIS MITGELIEFERTE ZUBEHÖRTEILE MEDFÖLJANDE TILLBEHÖR ACCESSORI IN DOTAZIONE ACCESORIOS INCLUIDOS BIJGELEVERDE ACCESSOIRES U.K. model Modèle pour le Royaume-Uni Großbritannien-Modell Brittisk modell Modello per la Gran Bretagna Modelo para R.U. Modellen voor Groot-Brittannië AM Loop Antenna/Indoor FM Antenna Cadre-antenne AM/Antenne FM intérieure MW-Rahmenantenne/UKW-Innenantenne AM ramantenn/FM inomhusantenn... -
Page 3: Table Of Contents
Thank you for selecting this YAMAHA stereo tuner FEATURES • Multi-Functions for RDS Broadcast Reception • 40 Station Random Access Preset Tuning • Station Name Storing Capability • Automatic Preset Tuning for RDS Stations • Multi-Status Station Memory • Preset Station Shifting Capability •... -
Page 4: Connections
ANTENNA CONNECTIONS Each antenna should be connected to the designated terminals correctly, referring to the following figure. Both AM and FM indoor antennas are included with this unit. In general, these antennas will probably provide sufficient signal strength. Nevertheless, a properly installed outdoor antenna will give clearer reception than an indoor one. If you experience poor reception quality, an outdoor antenna may result in improvement. - Page 5 Connecting the indoor FM antenna (U.K. model) *If you connect an outdoor FM antenna to this unit, do not connect the indoor FM antenna to this unit. Connecting the AM loop antenna * The AM loop antenna should be placed apart from the main unit. The antenna may be hung on a wall. Positioning of the AM loop antenna/indoor FM antenna (U.K.
- Page 6 TUNER Connection cord (included) OUTPUT * This unit has a remote control sensor. It receives signals from the separately purchased remote control transmitter or a remote control transmitter provided with a YAMAHA amplifier. Amplifier This unit To AC outlet Remote control sensor...
-
Page 7: Tuning Operations
Normally, if station signals are strong and there is no interference, quick automatic-search tuning (AUTOMATIC TUNING) is possible. However, if signals of the station you want to select are weak, you must tune to it manually (MANUAL TUNING). AUTOMATIC TUNING POWER Select the reception band (FM or AM) while watching the display. -
Page 8: Manual Tuning
MANUAL TUNING Follow steps 1 and 2 on the previous page. TUNING MODE AUTO/MAN’L “AUTO TUNING” goes off. Other functions to improve FM reception signal quality MODE button Normally, press this button so that the “AUTO ST” indicator illuminates. When receiving an FM stereo broadcast in this mode, it is received in stereo automatically. -
Page 9: Preset Tuning
MANUAL PRESET TUNING This unit can store station frequencies (selected by tuning operation) by using the preset station buttons. With this function, you can select any desired station by only pressing the corresponding preset station button. Up to 40 stations (8 stations x 5 pages) can be stored. - Page 10 To store stations with names of your own giving You can store a station with a name of your own giving. As many as 8 letters and/or numerals can be selected for naming. By using this function, you can easily find a certain station even if you are not sure of that station’s frequency. You can give names to all preset stations.
- Page 11 AUTOMATIC PRESET TUNING You can also make use of an automatic preset tuning function for RDS stations only. By this function, this unit performs automatic tuning and stores RDS stations with strong signals sequentially. Up to 40 stations are stored automatically to the preset station buttons in the same way as in the manual preset tuning method on page 9.
-
Page 12: Exchanging Preset Stations
EXCHANGING PRESET STATIONS You can exchange the places of two preset stations each other by easy operations. Example) If you want to shift the preset station on E1 to A5, and vice versa. Recall the preset station on E1 (by following the method of “To recall a preset station”... -
Page 13: Receiving Rds Stations
RECEIVING RDS STATIONS RDS (Radio Data System) is a data transmission system gradually being introduced by FM stations in many countries. Stations using this system transmit an inaudible stream of data in addition to the normal radio signal. RDS data contains various information, such as AF (Alternative Frequencies for the same program station), PI (Program Identification), PS (Program Service station name), PTY (Program Type name), etc. - Page 14 To turn the unit into the PS mode or PTY mode Press the FREQ/PS/PTY button. Whenever pressed, the mode changes into the PS mode, PTY mode and returns to usual mode in turn. * When an RDS station is received, the display is automatically turned into the PS mode. Do not press the FREQ/PS/PTY button until the display is turned into the PS mode.
- Page 15 Calling a preset RDS station by the station name (PS SEEK) You can call a desired RDS station stored in this unit by only inputting the name of the station in the PS mode. By this operation, this unit searches all preset stations for the station. You do not have to input a full name, even only the first letter can be used for calling.
- Page 16 Calling a preset RDS station by the program type (PTY SEEK) By designating a program type, the unit automatically searches all preset stations for RDS stations of that program type. * There are 15 program types to classify RDS stations. For details, refer to page 13. Turn the unit into the PTY mode.
- Page 17 Calling the best quality RDS station which broadcasts the This function automatically searches for and calls another RDS station of the best reception quality which broadcasts the same program now you are listening to. This function utilizes AF (Alternative Frequencies for the same program station) and PI (Program Identification) of RDS data service. The search is carried out among the RDS network stations.
-
Page 18: Remote Control Transmitter (Separate Purchase)
REMOTE CONTROL TRANSMITTER Functions This unit has a remote control sensor. It receives signals from a remote control transmitter provided with a YAMAHA amplifier. Remote control sensor Remote control transmitter operation range Remote control sensor Within approximately 6 m (19.7 feet) -
Page 19: Troubleshooting
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center for help. SYMPTOM Crackling sounds from time to time (especially in weak signal areas). -
Page 20: Specifications
SPECIFICATIONS FM SECTION Tuning Range ...87.5 to 108 MHz 50 dB Quieting Sensitivity (IHF) [U.K. model] 75 ohms Mono ...1.55 µV (15.1 dBf) 75 ohms Stereo (NARROW) ...21 µV (37.7 dBf) Usable Sensitivity [U.K. model] 75 ohms, 1 kHz, 100% mod. (30 dB S/N Quieting) ...0.8 µV (9.3 dBf) [Europe model] (DIN) 75 ohms Mono (S/N 26 dB) ...0.8 µV... - Page 21 YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, D-2084 RELLINGEN BEI HAMBURG, F.R. OF GERMANY YAMAHA ELECTRONIQUE FRANCE S.A. 17 RUE DES CAMPANULES, LOGNES 77321 MARNE LA VALLEE CEDEX 2, FRANCE YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B.
