Installation guide automatic cash drawer SafeMoney Smart index 1. General informations ............... Safety instructions and regulations ................................2.1 Skills ....................2.2 Cables ................3 2.3 Temperature ranges ..................Weight and modules 3.Product presentation................4 4. Product dimensions ................5.Parts included.................... -
Page 3: General Informations
Installation guide automatic cash drawer SafeMoney Smart 1. General information We thank our users for choosing a Ditron product, for further information and details visit the website www.ditron.eu SAVE THESE INSTRUCTIONS. This manual contains important instructions to follow during installation and maintenance. -
Page 4: Safety Instructions And Regulations
Installation guide automatic cash drawer SafeMoney Smart 2. Safety instructions and regulations Installation and removal The installation and removal of the device and its modules must be carried out exclusively by expert personnel. Warning: Before carrying out any removal or maintenance work, ensure that the power supply has been disconnected. Warning: When installing SafeMoney Smart, ensure that the modules are securely attached to the internal frame of the system to prevent them from falling or tipping over. -
Page 5: Skills
Installation guide automatic cash drawer SafeMoney Smart 2. Safety instructions 2.1 Skills Personnel working on equipment, machinery or electrical systems must be adequately qualified. The degree of competence required for individual interventions depends on their complexity and the level of knowledge required. -
Page 6: Product Presentation
Installation guide automatic cash drawer SafeMoney Smart 3. Product presentation 12 - front Front adhesive frame 1 - coin acceptor 13 - fan 2 - integrated space for fiscal printer 3 - hard reset 4 - 10.1'' adjustable touchscreen display 5 - banknote acceptor 6 - coin dispenser 7 - front door opening lock... -
Page 7: Product Dimensions
Installation guide automatic cash drawer SafeMoney Smart 4. Product dimensions SIDE VIEW FRONT VIEW 10.1 38.0 36.5 TOP VIEW measurements expressed in "cm" REV.00... -
Page 8: Parts Included
Installation guide automatic cash drawer SafeMoney Smart 5. Parts included 1 - Safemoney assembly 2 - keys 3 - cables 4 - Safemoney “shield” sticker 5 - activation module 5- mounting fixture 6- quick installation guide REV.00... -
Page 9: Preparing For Installation
For correct use of the Easy automatic cash register, make sure that the base is at least 40cm from the floor. For further information and further information, contact the Ditron Technical Assistance Service REV.00... -
Page 10: Recessed Positioning
Installation guide automatic cash drawer SafeMoney Smart 6. Preparing for installation 6.1 Built-in positioning 36.5 pic. 1 The SafeMoney Smart has also been designed to be installed under the pre-existing counter, with the peripherals facing the customer or operator. 10.1 To ensure correct installation inside the workbench, some requirements are essential to ensure adequate ventilation of the device and correct use by the operator (or user). -
Page 11: Recessed Positioning
Installation guide automatic cash drawer SafeMoney Smart 6. Preparing for installation ATTENTION To avoid hindering the extraction of the internal modules and facilitating product maintenance, allow the door to be opened completely, as in pic. 3 (min. 105°). If you want to completely recess the case, do not cover the coin chute. Evaluate the work to be carried out. In pic. -
Page 12: Installation
Installation guide automatic cash drawer SafeMoney Smart 7. Installation Remove the unit from the packaging and after checking the points in the "preparation for installation", proceed with the installation. For greater safety it is possible to fix the automatic cash register to the support surface; in this case, we recommend carrying out the operation with the fixing template supplied. -
Page 13: Fixing The Case To The Floor
Installation guide automatic cash drawer SafeMoney Smart 7. Installation 7.3 Fixing the case on the surface pic.7 Position the case on the surface where the holes were previously made using the template. Proceed with fixing the case. The diameter and type of screws to use depend on the support surface. - Page 14 +39 081242855 +39 0812428552 w. www.ditron. a. Via Antiniana 115 - 80079 Pozzuoli (NA) - Ita All information contained in this manual may be subject to changes by Ditron S.r.l. without prior notice. REV. 00 | FEB. 2024...
