- Page 1 PETROL WOOD CHIPPER INSTRUCTION & USER MANUAL JCB-CH75100P Original Instructions IM-CH75100P-EN...
-
Page 2: Table Of Contents
Maintenance Schedule Oil Servicing Spark Plug Sediment Filter Storage Troubleshooting Specification Warranty, Manual Updates, Returns, Reviews & Spare Parts Contact Us Recycling and Disposal & Environmental Protection CE Declaration of Conformity UKCA Declaration of Conformity JCB-CH75100P Instruction & User Manual... -
Page 3: Introduction
Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by JCB Tools, and should be kept with the product. Please read and understand these instructions before you use your product. -
Page 4: General Warnings & Disposal
Smoking and Drugs Warning: NEVER smoke whilst operating the machine due to close proximity of flammable liquids. Also NEVER operate the machine under the influences of drugs including smoking and alcohol. JCB-CH75100P Instruction & User Manual... -
Page 5: Safety Information
ALL MAINTENANCE other than that listed in this manual, should be carried out by professionally trained and • certified personnel. When using this machine for the first time and before actual work, you MUST learn how to handle the machine • from an experienced or skilled person. JCB-CH75100P Instruction & User Manual... -
Page 6: Personal Safety
The operator or user must take all necessary precautions to ensure their own safety and that of others, especially on slopes or rough, slippery and unstable ground. JCB-CH75100P Instruction & User Manual... -
Page 7: Inspect Your Machine
Keep the machine in good operating condition. Operating the machine in poor or questionable condition could • result in serious injury. Be sure all safety devices are in working order and warning labels are in place. These items are installed for your • safety. JCB-CH75100P Instruction & User Manual... -
Page 8: Work Area & During Use
NEVER use inside a confined space such as but not limited to a house, garage, large vehicle, boat or tent. • Never operate the machines near other machines which use flammable liquids as a fuel source. • Only use the machine outside far away from open windows, doors and vents. • JCB-CH75100P Instruction & User Manual... -
Page 9: Fuel Safety
When fuel is spilled on yourself or your clothes, wash your skin and change clothes immediately. • ALWAYS clean up spills promptly using absorbent granules and a lidded bin. • JCB-CH75100P Instruction & User Manual... -
Page 10: Fuelling/De-Fuelling & Storage
(such as a water heater, furnace, or clothes dryer). Allow the engine to cool before storing in any enclosure. Replace all fuel tank and container caps securely and wipe up spilled fuel. Never operate the unit without the • fuel cap securely in place. JCB-CH75100P Instruction & User Manual... -
Page 11: Features
Features JCB-CH75100P Instruction & User Manual... - Page 12 The Air filter ensure the ensure only breathes clean air. O – Outlet chute switch. This detects if the chute is open or closed during operation. It prevents the machine running whilst the outlet chute is open. JCB-CH75100P Instruction & User Manual...
-
Page 13: Assembly
F – Outlet Chute B – Inlet Guide G – Leg Stand C –Safety Bar H – Tow Bar D – Wheels I – Wheel Axle E – Main Body & Engine J – Outlet Guide JCB-CH75100P Instruction & User Manual... -
Page 14: Outlet Chute
Assembly Outlet Chute This machines requires at least 2 people for the assembly, as components are heavy. Attach the Outlet Chute (F) the Main Body (E) as shown below. JCB-CH75100P Instruction & User Manual... -
Page 15: Inlet Chute
Assembly Inlet Chute Attach the Inlet Chute (A) to the Main Body (E) as shown below. JCB-CH75100P Instruction & User Manual... -
Page 16: Wheels And Axle
Assembly Wheels and Axle Firstly attach the Wheel Axle (I) and then the Wheels (D) as shown below. JCB-CH75100P Instruction & User Manual... -
Page 17: Leg Stand And Tow Bar
Assembly Leg Stand and Tow Bar Firstly attach the Leg Stand (G) and then the Tow Bar (H) as shown below. *NOTE* - The Tow bar is only suitable for off road use. JCB-CH75100P Instruction & User Manual... -
Page 18: Outlet Guide
Assembly Outlet Guide Attach the Outlet Guide (J) to the Outlet Chute (F) as shown below. JCB-CH75100P Instruction & User Manual... -
Page 19: Inlet Guide And Safety Shut Off Bar
Firstly attach the Inlet Guide (B) to the Inlet Chute (A). The Safety Shut off bar © and then be inserted into place on the Inlet Chute (A) Safety Cut Off When assembly is complete YOU MUST ensure the Safety Cut Off is connected from the Inlet Chute (A) to the Engine as shown below. JCB-CH75100P Instruction & User Manual... -
Page 20: Pre-Operation Checks
WARNING! Operating the engine without an air filter, or with Carburettor a damaged air filter, will allow dirt to enter the engine, body causing rapid engine wear. This type of damage is not covered by the Distributor’s Limited Warranty. JCB-CH75100P Instruction & User Manual... -
Page 21: Check Fuel Level & Recommended Fuel
Petrol/Gasoline is highly flammable, volatile and corrosive. You can be burned or seriously injured when handling fuel. NEVER fill above the Maximum Fuel Level. Standard E10 and E5 are both suitable for use with this machine Maximum Fuel Level JCB-CH75100P Instruction & User Manual... -
Page 22: Operation
> Operator Area – These areas are where you can safely stand when feeding material into the machine > Infeed – This is where you should load the machine. > Outlet Area – This is where you can safely direct the outlet from the machine. Operator Area Outlet Infeed Area Operator Area JCB-CH75100P Instruction & User Manual... -
Page 23: Starting
To start a cold engine, move the choke lever to the CLOSED position. To restart a warm engine, leave the choke lever in the OPEN position. > Move the throttle lever away from the SLOW position about 1/3 of the way toward the FAST position. Fuel Valve Lever Choke Lever Throttle Lever JCB-CH75100P Instruction & User Manual... - Page 24 Chipper output is controlled by adjusting engine speed. Moving the throttle lever in the FAST direction will increase chipper output, and moving the throttle lever in the SLOW direction will decrease chipper output. Ignition Switch Recoil Starter Grip Throttle Lever Choke Lever Slow Fast Open JCB-CH75100P Instruction & User Manual...
-
Page 25: Stopping
> Move the throttle lever to the SLOW position. > Turn the ignition switch to the OFF position. > Turn the fuel valve lever to the OFF position. Throttle Lever Slow Ignition Switch Fuel Lever JCB-CH75100P Instruction & User Manual... -
Page 26: Wood Chipping
Aim the outlet chippings into a suitable outlet area as shown below. IF the machine stalls, turn off the engine and clear the obstruction. NEVER try this whilst the machine is operating. Operator Area Outlet Infeed Area Operator Area JCB-CH75100P Instruction & User Manual... -
Page 27: Maintenance
Carbon monoxide poisoning from engine exhaust. Be sure there is adequate ventilation whenever you operate the engine. －Burns from hot parts. Let the engine and exhaust system cool before touching. －Injury from moving parts. JCB-CH75100P Instruction & User Manual... -
Page 28: Maintenance Schedule
Every 100 interval. Each Use Hours Hours Hours Check Engine Oil Level Check General Machine Condition Check Belts Check Tire Pressure Clean Engine Change Engine Oil First 5 hours Replace Air Filter Replace Spark Plug JCB-CH75100P Instruction & User Manual... -
Page 29: Oil Servicing
SJ, SL, or equivalent. SAE 15W-40 is recommended for general use. Other viscosities shown in the chart may be used when the average temperature in your area is within the indicated range. JCB-CH75100P Instruction & User Manual... -
Page 30: Spark Plug
After properly seated, fully tighten using spark plug wrench. > When the washer has started to compress tighten to the following instruction: 1. New Sparkplug – a 1/2 Turn tight 2. Re-used Spark Plug – a 1/8 to 1/4 Turn tight JCB-CH75100P Instruction & User Manual... -
Page 31: Sediment Filter
Place the O-ring in the fuel valve, and install the sediment cup. Tighten the sediment cup securely. > Move the fuel valve to the ON position, and check for leaks. Replace the O-ring if there is any leakage. Fuel Valve Lever O-Ring Washer/Gasket Drain Bolt Sediment Cup JCB-CH75100P Instruction & User Manual... -
Page 32: Storage
Pull the starter grip several times to distribute the oil around the cylinder walls. > Reinstall the Sparkplug. Pull the starter cord until resistance is felt. This ensures the valves are closed preventing moisture build up. > Return the recoil grip gently. JCB-CH75100P Instruction & User Manual... -
Page 33: Troubleshooting
3. Take engine to an Fuel filter clogged, carburettor Replace or repair faulty authorized servicing dealer, or malfunction, ignition components as necessary. Refer to shop manual. malfunction, valves stuck, etc. JCB-CH75100P Instruction & User Manual... -
Page 34: Specification
Specifications Model JCB-CH75100P Maximum Material Diameter 100mm Maximum Material Width 150mm Chipping Capacity 3-5 CBM/hour Blade Type Twin Reversible Blades 2000RPM Blade RPM 378x450 Inlet Hopper Opening Dimensions (mm) 148x223 Infeed Throat Opening Dimensions (mm) 4-Stroke OHV single Cylinder Engine Type... -
Page 35: Warranty, Manual Updates, Returns, Reviews & Spare Parts
We reserve the right to make any modifications without prior notice whenever necessary. Our latest manuals are also placed online. All our manuals can be downloaded at: www.jcb-tools.co.uk Returning Your Product If you are returning your product, please contact the dealer for their returns policy. -
Page 36: Contact Us
Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687 880 Email aftersales@Genpower..co.uk Post JCB Tools, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW. Support Website Go to www.jcb-tools.co.uk JCB-CH75100P Instruction & User Manual... -
Page 37: Recycling And Disposal & Environmental Protection
> You must comply with local regulations for the disposal of waste materials after mowing. > When disposing, do not pollute the environment with the machine, but hand it over to a disposal centre, in accordance with the local laws in force. JCB-CH75100P Instruction & User Manual... -
