- Page 1 Assembly Instructions INFM7001, INFM7101, INFM7201 Infinity Mounting set Etac Cross / Cross 5 2024-02 Revision 2...
- Page 2 Infinity. Warnings WARNING! Assembly work or changes made to the mounting set must be carried out by trained service technician, reseller or another person assigned by Decon. __________________________________________________________________________________ Sida 2/8...
- Page 3 Mounting set INFM7 Infinity Mounting set Universal __________________________________________________________________________________ 2. Overview A Center pipe adapter bar B Outer pipe adapter bar C Clamp adapter bar D Holder adapter bar E QR-Pin F Adapter plate G Spacer adapter plate H Washer adapter plate __________________________________________________________________________________ Sida 3/8...
- Page 4 Mounting set INFM7 Infinity Mounting set Universal __________________________________________________________________________________ 3. Assembly and adjustment of adaptor First mount the adapter plate (F), spacer adapter plate (G), washer adapter plate (H). This is kept into place using screws (I) that is tightened on the outside of the frame using spring washer (J) and domed nut (K).
- Page 5 Mounting set INFM7 Infinity Mounting set Universal __________________________________________________________________________________ Now mount the complete adapter bar that consists of center pipe (A), outer pipe (B) and clamp (C). The complete adapter bar is mounted into the holders (D) by using the QR-pins (E). Make sure the ends of the outer pipe (B) are parallell otherwise it can be hard to assemble it into the holders...
- Page 6 Mounting set INFM7 Infinity Mounting set Universal __________________________________________________________________________________ INFO Now use the leveling tool that is included in the delivery of Infinity. Since the adapter bar have splines inside it will not be possible to get the bubble of the spirit level exactly right. Just choose the most correct position.
- Page 7 Mounting set INFM7 Infinity Mounting set Universal __________________________________________________________________________________ Alt.2 Using the adjustment tool that is included in the delivery of Infinity (not this mounting set), set the angle of the adaptorbar. Only mount the inner pipe on one side and then rotate the center pipe to the correct angle.
- Page 8 Decon Wheel AB Södra Ekeryd 119, SE-314 93 Hyltebruk, Sweden Tel: +46 (0)345 40880 Fax: +46 (0)345 40895 E-mail: info@decon.se...
