- Page 1 Assembly Instructions ADV5313, ADV5013, ADV5113 Adventus adaptor bar Etac Cross 6 2022-09 Revision 1...
-
Page 2: General Instructions
INFO Particularly important or explanatory information General instructions These instructions shall always be followed when placing the adaptor bar ADV5313, ADV5013, ADV5113 on a wheelchair. Adjustment of the Adventus wheel is described in the user manual of the Adventus wheel. - Page 3 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ 2. Overview Pic1 A Adapterbar INFO B Fork adapterbar Picture above (Pic1) show a Cross 6 wheelchair. C Adapterkit D QR Pin __________________________________________________________________________________ Page 3/9...
- Page 4 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ 3. Assembly adapterkit First mount the Adapterkit (C) on both sides of the frame. The pictures bellow (Pic2, Pic3, Pic4) show one side only. Tighten the screws crosswise (Pic4). Pic2 Pic4 Pic3 INFO The round part of the adapterkit shall be fitted inside the hole of the wheelchair frame.
- Page 5 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ 4. Adjustment of the adaptor bar Mount the adapterbar (A) and fork (B) to the adapterkit (C) using the QR-Axle (D) Mount the adjustment toll onto the fork (B). Remove the screws in the fork that locks the rotation (see picture bellow).
- Page 6 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ Now rotate both the adapter bar and the fork to a position where the adjustment tool shows the correct angle and the fork doesn’t collide with the footrests. If possible, make sure that the fork doesn’t sit lower than the footrest and that the height, if possible, corresponds to the picture bellow.
- Page 7 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ Reassemble the screw in the hole that is fits the best, see picture bellow for example. __________________________________________________________________________________ Page 7/9...
- Page 8 Assembly Instructions ADV5313. ADV5013, ADV5113 __________________________________________________________________________________ Now tighten the screws that sits in the clamp of the adaptor bar. Slightly tighten all four screws on the clamp. It is important to not completely tighten each screw, but to slowly tighten all four, a little at a time. Keep tightening until all four screws are secured (30-35Nm of torque).
- Page 9 Decon Wheel AB Södra Ekeryd 119, SE-314 93 Hyltebruk, Sweden Tel: +46 (0)345 40880 Fax: +46 (0)345 40895 E-mail: info@decon.se...
