- Page 1 Assembly instructions for Gearwheel Mounting set for Netti 4U Part No. GW3048K...
- Page 2 Assembly instructions Part No. GW3048K ___________________________________________________________________________ 1. Remove wheels, brakes and hub sleeves from the wheelchair. Use Bracket 9 Use Bracket 10 2. Assembly the plate (right side) according to picture. 3. Parts pair mountingset: Item No. Part Number Description MED2000 Bracket 100 400 008...
- Page 3 Assembly instructions Part No. GW3048K ___________________________________________________________________________ 4. Adjust the Lock Rotation arm to a position that makes it easy for the end user to use the shifting knob. Fixate the arm by pushing it towards the hub. 5. Lock the arm with a retaining ring, use a circlip pliers to mount it. Ensure that the retaining ring is secured in the intended track.
