9500R
Electro-Hydraulic Tire Changer
For Medium and Large Size Tires
IMPORCOM EQUIPOS AUTOMOTRICES
Blvd. Leyva Solano #830 A Pte.
Culiacan Sinaloa CP 80000
(667) 276 8141
(667) 716 0102
ID 92*1038450*4
1601 J. P . Hennessy Drive, LaVergne, TN USA 37086-3565 615/641-7533 800/688-6359
HENNESSY INDUSTRIES INC. Manufacturer of AMMCO
Installation Instructions
Operating Instructions
Safety Instructions
Maintenance Instructions
READ these instructions before placing unit in
service KEEP these and other materials delivered
with the unit in a binder near the machine for
ease of reference by supervisors and operators.
®
, COATS
®
and BADA
®
Automotive Service Equipment and Tools.
®
www.ammcoats.com
Manual Part No.: 8184345 02
Revision:
01/04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HENNESSY INDUSTRIES Coats 9500R
Summary of Contents for HENNESSY INDUSTRIES Coats 9500R
- Page 1 (667) 276 8141 (667) 716 0102 ID 92*1038450*4 1601 J. P . Hennessy Drive, LaVergne, TN USA 37086-3565 615/641-7533 800/688-6359 www.ammcoats.com Manual Part No.: 8184345 02 HENNESSY INDUSTRIES INC. Manufacturer of AMMCO ® , COATS ® and BADA ® Automotive Service Equipment and Tools.
-
Page 2: Table Of Contents
8.0 Storing The Machine ....18 Your safety, or the safety of others, is involved! 10.0 Trouble Shooting ....19 ii • COATS 9500R Tire Changer... -
Page 3: Operator Protective Equipment
ALWAYS disconnect the electric power and air supply before attempting any maintenance. ALWAYS keep all working surfaces clean and free of tire lube buildup. ALWAYS be aware of what each person is and will do before attempting any two-person operation. COATS 9500R Tire Changer • iii... -
Page 4: Bead Loosening Safety
Do not exceed the manufacturer’s recommended maximum inflation pressure. Failure to follow these instructions may cause the tire and rim to separate with tremendous force, resulting in serious per- sonal injury or death. iv • COATS 9500R Tire Changer... -
Page 5: Introduction
The use of this device is allowed only in locations with no explosion or fire hazards, consistent with state and local fire codes. This equipment is designed to use original or manu- facturer supplied spare parts and accessories only. COATS 9500R Tire Changer • 1... -
Page 6: Specifications
4 - 7 rpm Acoustic Pressure <70dBA 1.6 Dimensions Of The Machine Fig.3 #874009472 Mounting Clamp (fig.4). To hold the bead when mounting tires on steel rims. Instructions for use is in section 5.3. Fig.2 Fig.4 2 • COATS 9500R Tire Changer... -
Page 7: Optional Accessories
#874008257 Protectors for Alloy Rims (fig.7). #874019161 Extensions for 56” (fig.9/A). Suitable for rims with a center hole of 220 and 280 Necessary when clamping rims without flange and with a diameter exceeding 44” . Fig.7 Fig.9/A COATS 9500R Tire Changer • 3... -
Page 8: Carriage Instructions
Place the lags into the holes drilled in the floor and move the machine so that the holes of the cabinet are flush with the holes in the floor. Tighten the screws to (50 ft. lbs.). 4 • COATS 9500R Tire Changer... -
Page 9: Installation Instructions
If not, reverse any two phase cables on the plug (i.e. Reverse the brown and the blue cable). CAUTION Any damage caused by the non-application of the above instructions shall not be cov- ered by the manufacturer and will void the warranty. COATS 9500R Tire Changer • 5... -
Page 10: Operating Instructions
If the tool is required to rotate when the arm is raised, lower the arm to about 1/4 of the movement and lift it again to engage the rotation mechanism. 6 • COATS 9500R Tire Changer... -
Page 11: Mounting And Demounting - General Precautions
(fig.15). Fig.15 CAUTION If the wheel is very heavy be sure to use a suitable external lifting device (i.e. fork lift, Fig.16 crane etc.). COATS 9500R Tire Changer • 7... -
Page 12: Demounting Tubeless Truck Tires (Up To 13" Wide)
5. Move the tool holder arm all the way in. Lower the arm and secure. Bring the tool in contact with the inner bead. 6. Loosen the inner bead as described in point #3 above. Fig.18 8 • COATS 9500R Tire Changer... - Page 13 8. Move to the front of the tire and hold it with both hands in the last part of demounting operation to pre- vent the tire from falling or rolling away out of control (fig.22). Fig.21 Fig.22 COATS 9500R Tire Changer • 9...
-
Page 14: Mounting Tubeless Truck Tires (Up To 13" Wide)
3. Lift the chuck arm and position the mounting hook or tubeless roller approximately 1.5 cm (1/2”) to the inside of the rim edge and approximately 1.5 cm (1/2”) away from the rim edge (fig.27). Fig.24 10 • COATS 9500R Tire Changer... - Page 15 WARNING Do not inflate the tire on the machine. This machine is not an inflation device. For inflation place the wheel in an approved inflation restraint device. Refer to OSHA standard number 1910.177. Fig.28 COATS 9500R Tire Changer • 11...
-
Page 16: Demounting Duplex And Supersingle Tubeless Truck Tires (Over 13" Wide)
4. Rotate the chuck counterclockwise until the outer bead is completely demounted (fig.30). Fig.32 2. Position the mounting hook about 3/4” (1.5 cm) to the inside of the rim edge and 1/2” (1 cm) away radi- cally. Fig.30 12 • COATS 9500R Tire Changer... - Page 17 WARNING Do not inflate the tire on the machine. This Fig.34 machine is not an inflation device. For inflation place the wheel in an approved inflation restraint device. Refer to OSHA standard number 1910.177. COATS 9500R Tire Changer • 13...
-
Page 18: Demounting Tires From Multi-Piece
6. When loosening the inner bead be sure not to damage the valve stem (fig.39). Fig.37 3. Turn the chuck counterclockwise and loosen the bead as described in #5.2.1.-5.2.3. Do not lubricate. Fig.39 14 • COATS 9500R Tire Changer... -
Page 19: Mounting Tires Onto Multi-Piece
For inflation place the wheel in an approved inflation restraint device. Refer to OSHA standard number 1910.177. Fig.42 4. Lubricate both beads and the rim surface (fig.43). Fig.43 COATS 9500R Tire Changer • 15... - Page 20 9. Lift the tool holder arm to the rest position. Shift the tire from the rim, moving the tool holder car- riage towards the outside: This will make it much eas- ier to remove the tube (fig.47). Tire Tool Fig.45 Fig.47 16 • COATS 9500R Tire Changer...
-
Page 21: Mounting Tractor And O.t.r. Wheels On One-Piece Rims
The edge of the hook should be about (1” or 2-3 cm) inflation restraint device. Refer to OSHA away radically from the rim edge and (1” or 2-3 cm) to standard number 1910.177. the outside. Fig.49 COATS 9500R Tire Changer • 17... -
Page 22: Maintenance
Oil change is not required. and check for correct functioning of all devices before 4. Clean & grease the sliding bar once a month (fig.54). using the machine again. 18 • COATS 9500R Tire Changer... -
Page 23: Trouble Shooting
• The protectors for light-alloy • Replace the protectors for alloy wheels are damaged or worn out. wheels. • The check valve or manifold of • Call the authorized service center the chuck cylinder leak oil. for assistance. COATS 9500R Tire Changer • 19... - Page 24 If the machine is serviced by COATS authorized personnel, labor charges will ® be covered for a period of 90 days after the date of installation. 8184345 02 01/04 © Copyright 2003 Hennessy Industries and COATS ® All Rights Reserved Printed in USA...
