Westbo VICTORIA 85 Manual And Instruction

Hide thumbs

Advertisement

Table of Contents

MANUAL AND INSTRUCTION
WESTBO VICTORIA 85
Westbo of Sweden

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VICTORIA 85 and is the answer not in the manual?

Questions and answers

Related Manuals for Westbo VICTORIA 85

Summary of Contents for Westbo VICTORIA 85

  • Page 1 MANUAL AND INSTRUCTION WESTBO VICTORIA 85 Westbo of Sweden...
  • Page 2 The Westbo Victoria 85 6. Contact the chimney sweeper for inspection. has adjustabele feets. Westbo Victoria 85 is preassembled at the factory with the connection to the rear. Westbo of Sweden...
  • Page 3 Westbo Victoria 85 General instructions How to use Air controls Westbo Victoria 85 is equipped with one air control and it is located under the stove, see picture on the right. Fire up We recommend you to use fire starters or equivalent.
  • Page 4 Westbo Victoria 85 Replace side glass Replace the side glass 1. Start by taking out fire bricks ac- cording to the instructions on the next page. 2. Remove the grate bottom. The lever of the rust is assembled with a nut that can be accessed through the opening for the ash tray.
  • Page 5 Westbo Victoria 85 Assembling/removal of vermiculite Open the door to access the 1. Start with the small 2. Then remove the big fire chamber. side-brick. side-brick by first lift the roof-brick that locks the big side-brick. 3. Take down the roof-brick.
  • Page 6 Westbo Victoria 85 Technical data Weight 135 kg Drawn Date 2022/3/9 Checked Doc.Nr Material Cast iron Medium power 5,5 kW Sheet Size Efficiency 75 % CE-approved EN 13240 Distance to combustable: Back 100 mm Side 400 mm Front 1200 mm...
  • Page 7 Westbo Victoria 85 Wood handling Preparation We recommend a diameter of 6-10 centimetre and that the wood logs are 6 centimetre shorter than the fireplace. This will help the air to circulate in the best possible way. If the diameter is bigger, the wood logs must be splitted. Wood logs that are splitted will dry better.
  • Page 8 Westbo Victoria 85 Warranty WARRANTY Westbo of Sweden has a 15 year stove casting warranty and a 1 year warranty concerning natural wear and tear of articles of consumption such as firebricks, vermiculite, grates, glass, handles and rope seal. The warranty is only valid if the stove has been used in a proper way...
