USER INSTRUCTIONS
5K ZINC PLATED SWIVEL ANCHOR
Complies with ANSI Z359.18 Type A,
OSHA 29 CFR 1910 and 1926 regulations.
OPERATION AND INSTRUCTION MANUAL
Swivel Anchor
Models: DAS-5K, DAS-5KC
WARNING:
UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE
FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL USERS OF THIS PRODUCT MUST BE PROPERLY
INSTRUCTED ON HOW TO USE THE DEVICE. AVOID CONTACT
WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL, ELECTRICAL,
ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
ALL USERS OF THIS EQUIPMENT MUST READ AND
V3.0-D
Advertisement
Table of Contents
Related Manuals for Gemtor DAS-5KC
Summary of Contents for Gemtor DAS-5KC
- Page 1 Complies with ANSI Z359.18 Type A, OSHA 29 CFR 1910 and 1926 regulations. OPERATION AND INSTRUCTION MANUAL Swivel Anchor Models: DAS-5K, DAS-5KC WARNING: ALL USERS OF THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 PURPOSE The DAS-5K & DAS-5KC are anchorage connectors designed to function as an interface between the anchorage and a fall arrest, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector” in this manual include, and apply to the DAS-5K &...
- Page 3 LABEL LOCATIONS 180˚ 2.25 inches ø (57.15mm) 8 inches ø (203.2mm) 5.5 inches (139.7mm) 360˚ 3 inches (76.2mm) Tensile Strength (UTS): 5,000-lbf (22kN) Weight: 1.2-lbs (544.3g) Materials: Zinc Plated Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7-2019 OSHA 29 CFR 1926.502, OSHA 29 CFR 1910.140 LOADING CONDITIONS DIAGRAM LOAD...
- Page 4 CONCRETE MOUNTING MODEL: DAS-5KC - Use a proper drill & bit for concrete. (SDS drill bit) - Drill a .5 inch (13mm) hole no less than 4.5 inches (114mm) deep and 8 inches (203mm) away from any edge. - Hole must be straight and perpendicular to surface.
- Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 1800-lbf (8 kN). (ANCHOR POINT) WORK SURFACE *The structure the anchorage is attached to must be able to support 5,000-lbf (22kN) and installed...
- Page 6 KIT CONTENTS PART NUMBER DAS-5K (Anchor Swivel 5K) DAS-5KS-KIT (Steel Mounting Hardware Kit) DAS-5KS (Swivel with Steel Mounting kit) DAS-5KC-KIT (Concrete Hardware Kit) DAS-5KC (Swivel with Concrete Mounting Kit) For more information: Page 6...
- Page 7 MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
- Page 8 Gemtor, Inc. One Johnson Ave Matawan, NJ 07747 732-583-6200 800-405-9048 (toll-free) 732-290-9391 (fax) sales.info@gemtor.com www.gemtor.com Page 8 REV D...
