- Page 1 Assembly manual Circulating Water Drain (148830) for Citymaster 1600...
- Page 2 In the case in this assembly manual may only be of necessary repair work, please make undertaken by a Hako service centre or sure that only original spare parts are a workshop authorised by Hako. Mem- used.
- Page 3 Circulating Water Drain Circulating Water Drain Parts list 1 T-piece - 3x hose clamp 2 Hose 3 Flat slider - 2x flanged button head bolt M8x16 - 1x adapter - 2x gasket - 1x hose clamp Assembly manual Fig.1...
- Page 4 Circulating Water Drain Fit the waste water hose Top view Insert the T-piece (Fig. 2/1) in the circu- lating water hose (Fig. 2/2) and fix it in position using hose clamps. Align as shown in the sketch. The elbow (Fig. 2/3) must face upwards! After the elbow, run the hose below the air filter (Fig.
- Page 5 Circulating Water Drain Fit the flat slider Fit the flat slider with the holder (Fig. 3/ 1) to the plate (Fig. 3/2) of the wheel case using two flanged button head bolts M8x16. Fit the two gaskets (Fig. 3/3) included in the scope of delivery for the flat slider as shown.
- Page 6 Circulating Water Drain Function If there is excessive water in the dirt hopper during vacuum cleaning, the surplus water can be drained off by the drain. Observe the disposal regulations for dirt. The valve of the drain is located next to the wheel case (Fig.
- Page 7 Circulating Water Drain...
- Page 8 Advanced Technology for a Cleaner, Better Environment · · · Hako GmbH Hamburger Str. 209-239 23843 Bad Oldesloe Germany · Phone +49 4531 806-0 Fax +49 4531 806-338...
