Schematic diagram is for example purposes. Some parts may differ in certain details.
13 – Removing the trim of the additional brake light
14 – Remove additional brake light
https://www.newtis.info/tisv2/a/en/g20-m340i-xdrive-lim/repair-manuals/51-body-equipment/51-44-headlining/1Vndqfc83F
Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof)
▶ Remove C-pillar trim panel
Unclip clamp (4).
Unclip clips (3).
Feed out C-pillar trim panel (2) from the guides to the
front.
Thread out C-pillar trim panel (2) from the lip of edge
protection (1).
If required, remove the clips (1) and the clamp (2) and
connect it to the trim panel.
Loosen the clips (1).
Release the latch mechanisms (2) and remove the
trim of the additional brake light (3).
