BMW M340i G20 xDrive Repair Manual

BMW M340i G20 xDrive Repair Manual

Removing and installing/replacing the headlining
Hide thumbs Also See for M340i G20 xDrive:

Advertisement

Quick Links

Download this manual
5/28/22, 10:13 AM
BMW G20 M340i xDrive Sedan
Headlining
/
51 44 011 Removing and installing/replacing headlining
Fold the headlining.
If the headlining is folded, it may have to be replaced.
Carry out tasks with a second person to assist.
Support the headlining at the front and back.
The following procedure forms the basis for these repair instructions and must be observed
without fail.
For more information see: 51 31 ... General procedure for disassembly/installation of bonded
window glass
Perform window removal using the "spider".
For additional information see: 51 31 ... Window glass removal using "spider"
PRELIMINARY WORK
1 – Removing the trim panel for the rear left and right water channel
Description is for left component only. Procedure on the right side is identical.
https://www.newtis.info/tisv2/a/en/g20-m340i-xdrive-lim/repair-manuals/51-body-equipment/51-44-headlining/1Vndqfc83F
Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof)
/
Repair Manuals and Technical Data
/
51 Body equipment
/
51 44
1/39

Advertisement

loading

Related Manuals for BMW M340i G20 xDrive

Summary of Contents for BMW M340i G20 xDrive

  • Page 1 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) BMW G20 M340i xDrive Sedan Repair Manuals and Technical Data 51 Body equipment 51 44 Headlining 51 44 011 Removing and installing/replacing headlining Fold the headlining. If the headlining is folded, it may have to be replaced.
  • Page 2 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Unclip the trim panel for the water channel (1) with the special tool 0 496 569 (00 9 325). 2 – Removing the covers for the interior mirror Version A: Release the cover (1) at the centre from the latch mechanisms (2) with a suitable plastic wedge and...
  • Page 3 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Detach cover (1) from the clamps (2) in the marked area using a suitable plastic wedge and pull down a certain distance. Release cover (1) at the retaining lugs (3) and remove from the guides to the rear.
  • Page 4 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Pyrotechnic components. Danger! Life-threatening injuries! All work on pyrotechnic parts may be carried out by technically experienced and appropriately trained personnel only. Replace any damaged part or ones that have been dropped. For additional information see: 72 00 Safety regulations on handling components with gas generators.
  • Page 5 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Pull out the cover (1). Detach the sun visor (2) from the counter support . Disengage the sun visor (2) in front to the bottom and thread it out of the headlining at the rear. Unlock associated plug connection and disconnect.
  • Page 6 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Lever out the front vanity mirror light (1) using special tool 0 496 569 (00 9 325) from the headlining (2). Unlock and disconnect connector (1). Remove the front vanity mirror light (2). 7 –...
  • Page 7 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Open insulation (1). Disconnect plug connection. Remove hands-free microphone (2). 8 – Removing the roof function centre (FZD) Unclip the cover (1). Loosen screws (1). https://www.newtis.info/tisv2/a/en/g20-m340i-xdrive-lim/repair-manuals/51-body-equipment/51-44-headlining/1Vndqfc83F 7/39...
  • Page 8 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Unclip the roof function centre (FZD) (1) from the clamps (2). Thread the roof function centre (FZD) (1) out of the guides (3). Unlock and disconnect plug connections (1). Unclip the cable for the roof function centre (FZD) (2) from the cable clip.
  • Page 9 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Unclip clips (3). Feed B-pillar trim panel (1) out of the front and rear lip of edge protections and the guides (2). Feed upper seat belt (2) out of B-pillar trim panel (1). 10 –...
  • Page 10 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Pull the grab handle (2) slightly to the inside and hold Use a suitable screwdriver (3) to detach the upper and lower release tabs (1). Guide the grab handle (2) out. Repeat the operation on the other side of the grab handle (2).
  • Page 11 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) ▶ Remove C-pillar trim panel Schematic diagram is for example purposes. Some parts may differ in certain details. Unclip clamp (4). Unclip clips (3). Feed out C-pillar trim panel (2) from the guides to the front.
  • Page 12 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Disconnect plug connection (1). Unlock both slides (2) outwards in the direction of the arrow and remove additional brake light (3). 15 – Remove rear window Unlock plug connection (1) and disconnect. Secure cable to rear window with adhesive tape.
  • Page 13 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Unlock plug connection (1) and disconnect. Secure cable (2) to rear window with adhesive tape. Tape off body in area of piercing point with fabric adhesive tape. Push the thread (1) through the adhesive bead along the line from the inside.
  • Page 14 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Unclip the headlining (1) on the clips (2) downwards. Loosen screw (1). Unclip the headlining on the clips (2) downwards. Carefully unclip headlining (1) from the slide/tilt sunroof unit and clamps (2) in the area of the dotted line.
  • Page 15 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Fold the headlining. If the headlining is folded, it may have to be replaced. Carry out tasks with a second person to assist. Support the headlining at the front and back. Check the clips (1) on the headlining (2) for damage.
  • Page 16 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Clip headlining (1) to the clips (2). POSTPROCESSES 18 – Replace the spacer Completely remove the available spacer buffers (1). Remove the adhesive residue on the body and clean the adhesive area.
  • Page 17 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Clean the bonding surfaces on the body and on the rear window. Provide two glue cartridges. Prepare a glue cartridge with the standard jet nozzle Apply bead joint in area (1). Apply adhesive bead within the mark on the rear window Adhesive bead...
  • Page 18 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Open tailgate (1) approx. 1/3 and secure in this position. Carefully perform the following actions on rear window (2) with suction lifters Bring it parallel to C-pillar Feed it in under tailgate Position at top Align sides evenly...
  • Page 19 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Gap dimension rear window to roof outer skin 1 rear window; 2 roof outer skin 3,2 ( 1,9 - 4,5) mm 2,6 ( 1,3 - 3,9) mm Measure short length (A) of the rear window (1) to the roof outer skin (2) with the special tool 0 495 259 (51 0 010).
  • Page 20 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Secure cable (2) with nuts (1) at the attachment point. Loosen cable (2) from the rear window. Connect connector (1). 21 – Install the auxiliary stop lamp Position the additional brake light (3).
  • Page 21 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Check the clips (3) for damage and renew if necessary. Check latch mechanisms (2) and guides (4) for damage. Result » The latch mechanism or the guide is damaged. Measure Renew the trim for the additional brake light.
  • Page 22 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Check clips (1) and clamp (4) for damage, renew if necessary. Check the guides (3) for damage. Result » Guide is damaged. Measure Renew the C-pillar trim panel . Schematic diagram is for example purposes.
  • Page 23 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Result » Clamps (1) are damaged. Measure Renew the interior roof light (2). Connect connectors and lock. Clip in the interior roof light (1) with clamps (2). 25 –...
  • Page 24 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) ▶ Install the B-pillar trim panel Check the clips (1) for damage and renew if necessary. Guide upper seat belt (2) in B-pillar trim panel (1). Insert B-pillar trim panel (1) into guides (2) and under the front and rear lips of edge protection.
  • Page 25 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Fully position the front seat to the front and top. Insert the end fitting (2). Renew the screw (1). Parts: Screw Tighten down screw (1). End fitting to seat mechanism Flat-head Renew screw.
  • Page 26 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Check the latch mechanisms (1) on the two covers (2) for damage, renew the covers (2) if necessary. The covers (2) must not be damaged or missing. Position the covers (1) correctly on the mirror and engage with the latch mechanisms (2).
  • Page 27 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Guide in cover (1) on left and right and engage using latch mechanisms (2) and (3). Check Check clamps (1) for damage; renew if necessary. Check latch mechanisms (2) for damage. Result »...
  • Page 28 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Connect connectors (1) and lock. Clip in the cable for the roof function centre (FZD) (2) in the cable clip. Thread the roof function centre (FZD) (1) as shown at a steep angle into the two guides (2) on the headlining (3).
  • Page 29 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Pass through the FZD frame and headlining with the special tool 2 298 505 and adjust the headlining correctly. Tighten the screws (1). Roof function centre Tightening 1,2 Nm torque Clip in the cover (1).
  • Page 30 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Connect the connector to the hands-free microphone (2). Close the insulation (1). Position hands-free microphone (1) in headlining (2) in the direction of the arrow. 30 – Installing front vanity mirror light Description is for left component only.
  • Page 31 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Position the front vanity mirror light (1) in the headlining (2). 31 – Install both counter supports for the sun visors Description is for left component only. Procedure on the right side is identical. ▶...
  • Page 32 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Connect the sun visor (2) with the corresponding connector. Guide the sun visor (2) into the headlining. Use cover (1). Attach the sun visor (2) on the counter support. 33 –...
  • Page 33 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Check retaining lugs (1) of cover (2) for damage. Result » Retaining lug is damaged. Measure Renew the cover. Check Check the clips (1) for damage and renew if necessary.

  • Page 34: Additional Information

    5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) 34 – Installing the trim panel for the rear left and right water channel Description is for left component only. Procedure on the right side is identical. Check the clips (1) and guides (2) on the trim panel for the water channel (3) for damage.
  • Page 35 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) A-pillar trim panel to body Used in step Sheet metal screw Tightening torque 2,6 Nm 4,8x38 Overview of Special Tools 0 496 569 (00 9 325) Wedge Common Used in step (Panel wedge) From 11/2008 this...
  • Page 36 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) Storage location Replaced by In connection with SI-Number 01 15 99 (483) Consisting of Replaced Order Designation Connection number with Removal aid Only available 0 496 as a set (2 289 (00 tools) under 9 341)
  • Page 37 5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) location Replaced by In connection with SI-Number 08 01 10 (635) 0 410 807 Accessories Common Used in step Pinchweld scraper set for removing seal residues such as window glass Usage adhesive or seals in the engine compartment.

  • Page 38: Overview Technical Data

    5/28/22, 10:13 AM Removing and installing/replacing headlining (for equipment specification with slide/tilt sunroof) 0 496 076 (00 9 470) Gauge Common Used in step (Gap gauge) From 1 to 5 mm (1; 1.5; Usage 2; 2.5 ...). For checking body gap dimensions.
  • Page 39 For informational purposes only. The information on this website is provided AS-IS with no warranties, express or implied, and is not guaranteed to be error-free, up-to-date or complete. NewTIS and BMW assume no liability for any loss or damage arising from the use or reliance on the information and content on this website.
