LCD TV
L26E62AZ
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L26E62AZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TCL L26E62AZ

  • Page 1 LCD TV L26E62AZ OPERATION MANUAL...
  • Page 3: Warning And Precaution

    WARNING AND PRECAUTION Read all of the instructions before operating the set. Keep these instructions well for later use. All instructions must be followed during the operation. PRODUCT Do not block or cover the ventilation openings on the back cover. Do not push any objects of any kind into this unit through the cabinet slots as they could touch the current carrying parts or short-circuit parts, resulting in fire, electric shock, or damage to the unit.
  • Page 4 WARNING AND PRECAUTION Keep away from direct Apparatus shall not be exposed to Do not use the set near dusty sunlight. dripping or splashing and no objects environments. filled with liquids, such as vases, shall be placed on the apparatus. CLEANING Dust the set by wiping the screen and cabinet with a soft, clean cloth or some special liquid cleaner.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS WARNING AND PRECAUTION..........TABLE OF CONTENTS............FUNCTIONS AND FEATURES..........EXTERNAL SCHEMATIC AND INSTALLATION....FRONT & SIDE PANEL................BACK PANEL..................BASE INSTALLATION................ANTENNA/CABLE CONNECTION............REMOTE CONTROL................SETTING UP YOUR TV............MENUS CONTROL..............BASIC OPERATION................ADJUSTING THE PICTURE ..............ADJUSTING THE SOUND..............
  • Page 6: Functions And Features

    FUNCTIONS AND FEATURES TV FUNCTION 1. Auto Volume Control 2. English menu 3. 3 Selectable Colour Temperatures 4. Full-function Infra-red Remote Control 5. Multi-system 6. 100 preset programs in Analogue mode, and 1000 preset programs in Digital mode 7. AV Input, S-Video, CMPT, VGA, HDMI, ANTENNA (DVB-T/ATV) sockets 8.
  • Page 7: External Schematic And Installation

    EXTERNAL SCHEMATIC AND INSTALLATION FRONT & SIDE PANEL The buttons lie at the side panel of the set. 1. INPUT button 5. PROGRAM DOWN button 9 SPEAKER 2. MENU button 6. PROGRAM UP button 3. VOLUME DOWN button POWER INDICATOR 4.
  • Page 8: Back Panel

    EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL VIDEO Pr/Cr Pb/Cb AUDIO DIGITAL AUDIO AUDIO VGA INPUT VGA AUDIO INPUT OUTPUT (OPTICAL) AV OUTPUT COMPONENT INPUT POWER ANTENNA IN RS-232 S-VIDEO HDMI VIDEO AUDIO AC POWER AC POWER 180-240V 180-240V 50/60Hz 50/60Hz 1.
  • Page 9 EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL VIDEO Pr/Cr Pb/Cb AUDIO DIGITAL AUDIO AUDIO VGA INPUT VGA AUDIO INPUT OUTPUT (OPTICAL) AV OUTPUT COMPONENT INPUT POWER ANTENNA IN RS-232 S-VIDEO HDMI VIDEO AUDIO AC POWER AC POWER 180-240V 180-240V 50/60Hz 50/60Hz 12 8 8.
  • Page 10 EXTERNAL SCHEMATIC AND INSTALLATION BACK PANEL AUDIO VIDEO AUDIO Pr/Cr Pb/Cb DIGITAL AUDIO VGA INPUT VGA AUDIO INPUT AV OUTPUT OUTPUT (OPTICAL) COMPONENT INPUT POWER ANTENNA IN RS-232 S-VIDEO HDMI VIDEO AUDIO AC POWER AC POWER 180-240V 180-240V 50/60Hz 50/60Hz 13.
  • Page 11: Base Installation

    EXTERNAL SCHEMATIC AND INSTALLATION BASE INSTALLATION Note: If the base has been assembled, just ignore the following instructions and go to the next section. 1. Spread a soft cushion over a flat table. The cushion should be larger in area than the set to avoid the damage to the unit during installation.
  • Page 12: Antenna/Cable Connection

    EXTERNAL SCHEMATIC AND INSTALLATION ANTENNA/CABLE CONNECTION There are two kinds of antenna in use. VHF TV ANTENNA TWO KINDS OF ANTENNA UHF TV ANTENNA To TV VHF/UHF No need to install adapter ANTENNA jack (Note 1) U/V MIXER COAXIAL ANTENNA Need to install adapter VHF/UHF When connected with...
  • Page 13: Remote Control

    EXTERNAL SCHEMATIC AND INSTALLATION REMOTE CONTROL REMOTE CONTROL KEYS MUTE To switch sound off and back on again. (standby) To turn the TV on or off (standby). MUTE INPUT To select TV signal source. A/DTV To switch between analogue TV mode and digital TV mode. INPUT A/DTV RADIO...
  • Page 14 EXTERNAL SCHEMATIC AND INSTALLATION For using the remote control, follow these instructions: 1. Open the back cover of the remote control, then insert two AAA 1.5V batteries with polarities matching with the marks inside the battery compartment. Then, close back cover. Point the remote control towards the infra-red remote sensor on the main unit.
  • Page 15: Setting Up Your Tv

    SETTING UP YOUR TV There are several steps you need to follow before you can turn on the TV. Follow the instructions below to set up and turn on your TV. 1. Plug one end of the cord into the back of the TV, and plug the other end into an appropriate wall outlet.
  • Page 16: Menus Control

    MENUS CONTROL This section explains the menus of your TV, to help you get the most from your TV. BASIC OPERATION 1. Press MENU on the remote control to display the overview menu. 2. Press PROGRAM UP/DOWN to select the desired item. 3.
  • Page 17: Adjusting The Sound

    MENUS CONTROL ADJUSTING THE SOUND The Sound menu lets you adjust audio output. Display the OVERVIEW menu by pressing the MENU button. Select the Sound option and press OK or VOLUME UP to confirm. Sound 08:05 The Sound menu appears with the following options: Effect Music Treble...
  • Page 18: Setting The Installation

    MENUS CONTROL Timer Type: use VOLUME UP/DOWN to select a type offered (Turn Off, Inactive, Turn On), which enables this function and provides access to the relevant options. Timer1 08:05 Timer Type Turn Off Channel • DTV: set a channel which you want to wake up. Press Channel DTV Time 17:27:00...
  • Page 19: Setting The Preferences

    MENUS CONTROL Channel Edit: edit channels, such as deleting channels, skipping channels, sorting channels, locking or unlocking channels. Select the Channel Edit option using PROGRAM UP/DOWN, and press OK or VOLUME UP to display the ATV Channel menu in ATV mode, or the DTV Channel menu in DTV mode.
  • Page 20 MENUS CONTROL Favorite Mode: select one from the favorite lists you have edited in the Organizer menu as the current active list using VOLUME UP/ DOWN. Once a favorite list is selected, you can only access all the channels included in the favorite list by pressing PROGRAM UP/ DOWN.
  • Page 21: Calendar And Games

    MENUS CONTROL CALENDAR AND GAMES The Cal/Game menu can be used to browse the calendar Cal/Game 08:05 and play games. Calendar Calendar: select this option using PROGRAM UP/DOWN, Boxman press OK or VOLUME UP to confirm. Calendar menu Tetris displays. Use VOLUME UP/DOWN to display different year, to display different month using PROGRAM UP/ DOWN.
  • Page 22: Special Functions

    SPECIAL FUNCTIONS CHANNEL LIST The List menu is a shortcut to access a channel. In ATV or DTV mode, press the LIST button on the remote control to display the List menu. The menu is displayed with the current channel selected. Browse through the previous or next pages using VOLUME UP/DOWN and select a channel on the current page using PROGRAM UP/DOWN, then press OK to display the selected channel.
  • Page 23: Troubleshooting

    TROUBLESHOOTING NO PICTURE, NO SOUND 1. Check if the fuse or circuit breaker is working. 2. Plug another electrical device into the outlet to make sure it is working or turned 3. Power plug is in a bad contact with the outlet. 4.
  • Page 24 TROUBLESHOOTING SNOWY DOTS AND INTERFERENCE If the antenna is located in the fringe area of a television signal where the signal is weak, the picture may be marred by dots. When the signal is extremely weak, it may be necessary to install a special antenna to improve the reception.
  • Page 25: Specification

    SPECIFICATION MAIN UNIT Audio output power: 8W Working voltage: 180-240V~ 50/60Hz Rated power consumption: 85W Power consumption: <1W (in standby mode) Screen size (diagonal): 66cm Dimensions (WXDXH): 706mm X 240mm X 522mm(with stand) Environment: Working temperature: 5 C~35 C Working humidity: 20%~80% Storage temperature: -15 C~45 C...
