Summary of Contents for TCL L26E62A3
- Page 1 LCD TV L26E62A3 L32E62A3 OPERATION MANUAL...
- Page 2 CAUTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. The lighting flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the person.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment 1. Read these instructions. B. Objects have fallen or liquid has been spilled into the appliance; 2. Keep these instructions. C. The appliance has been exposed to rain; 3. Heed all warnings. D. The appliance does not appear to operate normally or exhibits a marked change in performance;...
- Page 4 Table of Contents...
- Page 5 Chapter 1 Introduction Precautions Read all of the instructions before operating the set. Keep these Cleaning instructions well for future use. Dust the set by wiping the screen and the cabinet with a soft, clean Product cloth or some special liquid cleaner. Do not apply excessive force to the screen when cleaning.
- Page 6 Introduction Side Panel Buttons 1. PROGRAM UP button Scans up through the channel list. In the menu system, it points up to items and adjusts menu controls. 2. PROGRAM DOWN button Scans down through the channel list. In the menu system, it points down to items and adjusts menu controls. 3.
- Page 7 Introduction Sockets AV2 RCA audio + video sockets (input) at the back These sockets can be used to connect a range of equipment, including video AUDIO2 recorders, camcorders, decoders, satellite receivers, DVD players, or games consoles. The VIDEO2 socket provides composite video connection. VIDEO2 AV1 RCA audio + video sockets (input) at the back AUDIO1...
- Page 8 Introduction Headphone socket at the back Use the relevant socket at the back of the TV set to connect headphones or stereo earphones. Remote Control Functions Most of your television's functions are available via the menus that appear on the screen.
- Page 9 Chapter 2 General Operation Switching on Follow the instructions on this page on how to switch on your TV set. 1. Insert two AAA batteries in the remote control. Precautions on using batteries: - Only use the battery types specified. - Make sure you use the correct polarity.
- Page 10 General Operation Channel Set-up Channel set-up involves selecting all the settings required to be able to search for and store all the channels you can receive. Make sure that the television is switched on and follow all the steps in turn specified hereafter. SETUP Display the menu using the MENU button.
- Page 11 General Operation Displaying Status Information In TV mode you can press the INFO button on the remote control to display the number of the relevant channel, the time, and the color system. The word MUTE displays when you mute the sound. In PC mode you can press the INFO button on the remote control to display the time, as well as the source of the signal being received and the resolution.
- Page 12 Chapter 3 Advanced Functions Adjusting the Picture The menus for adjusting the picture are used to obtain the best picture setting according to your preference, the type of programme you are watching and the ambient lighting. PICTURE Display the menu by pressing the MENU button. Select the PICTURE icon and press the up or down direction button to confirm.
- Page 13 Advanced Functions Setting Favorite Channels You can define the channels you watch most often as your favorite channels. This will allow you to create your own list of channels which you can access more quickly using the FAVORITE button on the remote control. Display the menu by pressing the MENU button.
- Page 14 Advanced Functions Programming the Turn-on Timer This function can be used to set the time for the set to turn itself on. 1. Select the TURN ON option. Using the left or right direction button, choose ON or OFF to activate this function and access the relevant options. Select OFF to disable this function.
- Page 15 Chapter 4 Other Information Troubleshooting Ghost Most problems you encounter with your TV can be corrected by Ghosts are caused by the television signal following two paths. One is consulting the following troubleshooting list. the direct path, the other is reflected from tall buildings, hills, or other objects.
- Page 16 72-HE62A3-E009A...
