- Page 1 MANUAL/ AUTO RANGE MULTIMETER K8610 ED1 June 2023...
-
Page 2: General Safety Warnings
& understand all information before operating. Save this manual for future use. This Kincrome Digital Multimeter is designed in accordance with IEC61010-1 (Safety Standard promulgated by the International Electro technical Commission). Please read safety precautions before using them. - Page 3 Manual/ Auto Range Multimeter K8610 Symbols The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use. Volts Class II Tool, Double Insulated Direct Current Fuse Alternating Current Conforms to European Union directives Read the instruction manual before use.
-
Page 4: General Safety Instructions
Manual/ Auto Range Multimeter General Safety Instructions K8610 Use the Meter only as specified in this manual, or the 1) Work Area Keep the work area clean and well lit. Cluttered protection provided by the Meter might be impaired. Do not use the Meter in wet environments. -
Page 5: Know Your Product
Manual/ Auto Range Multimeter Know Your Product K8610 1 - NCV INDUCTION 2 - LED WORKLIGHT REGION 3 - LCD DISPLAY 4 - SEL FUNCTION CONVERSION 4 - HOLD DATA / BACK LIGHT ON/OFF (press SEL to turn on and cancel automatic... - Page 6 Manual/ Auto Range Multimeter Know Your Product (cont) K8610 METER TERMINALS Meaning Input terminal for measuring ac and dc current to 10 A. Common (return) terminal for all measurements. Input terminal for measuring voltage, continuity, resistance, capacitance, frequency and testing diodes.
-
Page 7: Troubleshooting
Manual/ Auto Range Multimeter Trouble Shooting K8610 If your instrument does not work properly, the following methods can help you quickly solve general problems, if the failure is still not eliminat- ed, please contact Kincrome Customer Service. Symptom Remedy Display not working... - Page 8 Manual/ Auto Range Multimeter µ m M k Operation (cont.) p Hz Live K8610 ZERO LINE/FIRE LINE MEASUREMENT (LIVE) Please follow these specific operations: AUTO Turn the range switch to the ‘Live/NCV’ position. The screen will display ‘ACV’ when in an unmeasured state.
-
Page 9: Vdc Mode
Manual/ Auto Range Multimeter µ Operation (cont.) m M k K8610 p Hz Live VDC ( ) MODE Range Resolution Accuracy AUTO *99.99mV 10µV V.F.C **999.9mV 100µV ± 0.5%reading ± 2digit µ 9.999V m M k 99.99V 10mV p Hz... -
Page 10: Diode And Continuity Test
Manual/ Auto Range Multimeter Operation (cont.) K8610 DIODE AND CONTINUITY TEST Range Resolution Accuracy µ The buzzer sounds The open circuit voltage is m M k continuously. The resistance approximately 1V. Press the of two points is less than SEL key to switch between the... - Page 11 Manual/ Auto Range Multimeter Operation (cont.) K8610 9.999 Hz-9.999KHz input frequency voltage range: 100mV to 600V RMS RESISTANCE Range Resolution Accuracy 999.9Ω 0.1Ω ± 0.8%reading ± 5digit 9.999kΩ 1Ω µ 99.99kΩ 10Ω ± 0.8%reading ± 2digit m M k 999.9kΩ...
-
Page 12: Operation (Cont)
Reinstall the battery cover and lock the cover. SPARE PARTS Part No Description Quantity K8640-1 Test Leads K8640-2 Fuse * Please Note: Kincrome reserve the right to change spare parts at any time without notice. -
Page 13: Warranty
Kincrome Express Warranty, you can, at your cost, send the product to the above address for repair or replacement. Your rights under a Kincrome Express Warranty are in addition to any other rights you have under the Australian Consumer Law or other applicable laws.
