DC 3 Blade Ceiling Fan INSTRUCTION MANUAL
Glacier DC Ceiling Fan INSTRUCTION MANUAL
With LED (-L) model
Images are for reference only and may vary slightly from actual product.
Images are for reference only and may vary slightly from actual product.
Ceiling Fan Installation Manual Rev 1.2
Ceiling Fan Installation Manual
MODELS:
DC31203WH, DC31203WH-L, DC31203WHWC, DC31203WH-LWC
GLA1203WH, GLA1203WH-L, GLA1303WH, GLA1303WH-L
DC31203BL, DC31203BL-L, DC31203BLWC, DC31203BL-LWC
Thank you for purchasing this quality Ventair DC ceiling fan. To ensure correct function and safety,
please read all instructions before using the product and keep all instructions for future reference.
MUST BE
CAUTION
DIY
INSTALLED BY
Read Instructions Carefully
A LICENSED
For Safe Installation and Fan
ELECTRICIAN
Operation
Advertisement
Table of Contents
Related Manuals for Ventair Glacier DC
Summary of Contents for Ventair Glacier DC
- Page 1 GLA1203WH, GLA1203WH-L, GLA1303WH, GLA1303WH-L DC31203BL, DC31203BL-L, DC31203BLWC, DC31203BL-LWC Thank you for purchasing this quality Ventair DC ceiling fan. To ensure correct function and safety, please read all instructions before using the product and keep all instructions for future reference. MUST BE...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS WARNING: FOR SAFE USE OF THIS FAN, AN ALL-POLE DISCONNECTION MUST BE INCORPORATED INTO THE FIXED WIRING INACCORDANCE WITH THE WIRING RULES. As outlined in clause 7.12.2 of AS/NZS 60335-1 for meeting the minimum electrical safety of this standard. Please note warranty will be void if installation is without an all-pole disconnection incorporated in the fixed wiring in accordance with the wiring rules. -
Page 3: Before Installation
In this case, Damage, marks or scratches are not covered by the in home warranty. In this case, please contact Ventair to discuss replacement parts. product should be returned to place of purchase for a replacement. - Page 4 BEFORE INSTALLATION MOUNTING BRACKET • The ceiling fan must be installed in a location so that the blades have a minimum 300mm spacing from the tip of the blade to the nearest objects or walls. • Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 20kg, with the two Fixing screws provided.
-
Page 5: Hanging The Fan
Complete the electrical connection at the mounting bracket terminal block. • Fix the EARTH cable from motor to the mounting bracket. NOTE: DC 3 is a Class I electrical product. NOTE: Glacier DC is a Class I electrical product. (Refer to Fig 6.). Fig 6... - Page 6 FINISHING THE INSTALLATION • Connect fan to the receiver (can be done before or after sliding receiver into place). A. For fan models without light, plug cable marked ‘motor’ into remote control box. See Fig 7.2 B. For fan models with light, plug cable marked ‘motor’ and ‘LED’ into remote control box. See Fig 7.1 •...
- Page 8 )$9-%$'*-.%)-0' -($)"%,-.' )$9-%$'*-.%)-0' -($)"%,-.' <6' G4(+'Q#--'&Q13,2'3*'`LYa'8#+' <6' G4(+'Q#--'&Q13,2'3*'`LYa'8#+' Please note: The Glacier DC ‘Remote Handset’ cannot be used either simultaneously, 1&'+*Q'1+'&3#+/H.'"*/%6' 1&'+*Q'1+'&3#+/H.'"*/%6' or in conjunction with, a ‘Wall Controller’ (DC wall Controller available seperately) )$9-%$'*-.%)-0' -($)"%,-.' X'`H%%5a'Q1--'H%'2%#(/6' X'`H%%5a'Q1--'H%'2%#(/6' !)'.*4(')#+'2#&'#'-1$23A'32%'-1$23' )$9-%$'*-.%)-0' -($)"%,-.' !)'.*4(')#+'2#&'#'-1$23A'32%'-1$23'...
- Page 9 Handset '2%42@23! 21" V/+-%,("P(=/+%>*((,=Q".&+(=&)),=1" 31" Y,.,*E,=1"Y,.,*E,%">,%%/?,%"4=&>"(@,"@/+-%,("/+-"*%")&./(,-"*+"'FF,="./+&FA" &4"(@,"4/+1" X" R@,"NL":"=,>&(,".&+(=&)".&>,%"F=,<F/*=,-"/("(@,"4/.(&=A"/+-"*%"=,/-A"(&" The Glacier DC remote control comes pre-paired at the factory and is ready to '%,1" B/*=*+?"C*))"&+)A"D,"=,K'*=,-"*+"%*('/(*&+%">,+(*&+,-"D,)&C1" )$9-%$'*-.%)-0' -($)"%,-.' " P8(-9:;<(P(H>J@B>(DE;L9>B(B@(C@;BH@=(Q(@H(J@H>(34(R(6=EL>(4>:=:;<(GE;9( 1. Using 1 remote handset to control 2 or more Glacier DC Ceiling fans X"$"=,>&(,".&+(=&)".&+%*%(%"&4"(C&"F/=(%1"...
-
Page 10: Important Facts
Higher wattage, heavier AC type ceiling fan motors. The Glacier DC range are one of the quietest wattage, heavier AC type ceiling fan motors. The Skyfan DC Range are one of the quietest... -
Page 11: Technical Information
The cost of a service person will only be paid for manufacturer defect. Ventair. This warranty is not valid if any repairs or replacement is undertaken without the Once a service person has been out, if any fault is found to be an installation or user prior approval of Ventair.
