Page 2
Introduction • Overview: This document contains step-by-step disassembly and reassembly instructions for RC7095. The instructions are illustrated where necessary with images of the part that is being removed, disassembled or reassembled. • Disassembly Instructions: When disassembling the tool, follow these general rules: Use proper tools and jigs to disassemble the tool.
Page 5
Vacuum Adaptor disassembly • Step 1: Open Air Inlet • Step 2: Open Screw • Step 3: Remove Vacuum counterclockwise by using a wrench counterclockwise by using Adaptor. 17mm. It is necessary to an allen wrench 3mm. counterhold the housing with a wrench 37mm or similar tool.
Valve disassembly • Step 1: Remove Cone • Step 2: Remove Pin by • Step 3: Open Regulator Muffler by using a using punch and hammer to Valve counterclockwise by screwdriver or simliar. remove Trigger. using a wrench 12mm.
Page 7
Valve disassembly • Step 4: Remove Spring and Valve Stem with O-Ring.
Page 8
Front Housing disassembly • Step 1: Remove Protection • Step 2: Open Screw • Step 3: Push Cover to the Rubber. counterclockwise by using front and remove it. an allen wrench 3mm.
Page 9
Front Housing disassembly • Step 4: Open Screws • Step 5: Open all Screws on • Step 6: Give a soft hit on counterclockwise by using a the other side Belt Drive Shaft to split the screwdriver PH1. counterclockwise. Housing.
Page 10
Front Housing disassembly • Step 7: Split the Housing completely.
Page 11
Belt Drive disassembly • Step 1: Remove Nut Set. • Step 2: Remove Motor • Step 3: Remove rear Belt Housing. Drive Shaft Kit.
Page 12
Belt Drive disassembly • Step 4: Remove front Belt • Step 5: Remove Belt. Drive Shaft Kit.
Gear Box disassembly • Step 1: Open Screw • Step 2: Remove Bevel • Step 3: Remove Sliding counterclockwise by using an allen Gear. Key. wrench 2mm. It is necessary to counterhold the Spindle with a flat wrench 14mm.
Page 14
Gear Box disassembly • Step 4: Open Gear Box • Step 5: Push out Bearing by • Step 6: Remove Gear Box Housing counterclockwise using a punch. No hammer from Motor. by using a wrench 38 mm. necessary.
Page 15
Gear Box disassembly • Step 7: Remove Washer. • Step 8: Remove Gear Plate • Step 9: Push out Bearing by from Ring Gear. using a punch. No hammer necessary.
Page 16
Gear Box disassembly • Step 10: Push out Pins by • Step 11: Remove Idler using a punch. No hammer Gears. necessary.
Motor disassembly • Step 1: Pull out Motor from • Step 2: Remove Front End • Step 3: Remove Bearing Motor Housing. Plate with soft hits on Rotor from Front End Plate by Shaft. using a punch. No hammer necessary.
Page 18
Motor disassembly • Step 4: Remove Cylinder. • Step 5: Remove Rotor • Step 6: Remove Rotor from Blades. Rear End Plate by using a punch and hammer.
Page 19
Motor disassembly • Step 7: Remove Bearing from Rear End Plate by using a punch and hammer.
Page 20
Reassembly instructions • Reassembly is the reverse of disassembly process. • Use proper tools and jigs to reassemble the tool. • Make sure that all components are strictly clean. • Use care to ensure that all components are returned to their proper positions. •...
