Sony XR-75Z9K Service Manual

Hide thumbs Also See for XR-75Z9K:
Table of Contents

Advertisement

Quick Links

Download this manual
2023/12/21 05:23:12 (GMT+09:00)
SERVICE MANUAL (TROUBLESHOOTING)
ORIGINAL MANUAL ISSUE DATE: 2023.12
DISCLAIMER:
USE AT OWN RISK. SONY AND ITS AFFILIATES ARE NOT LIABLE FOR ANY DAMAGE
OR INJURY CAUSED TO ANY DIGITAL ELECTRONIC EQUIPMENT, PERSON, OR PROPERTY, WHICH
9-888-908-21
OCCURS DUE TO USE OF THE TOOLS, PARTS, DOCUMENTATION, OR OTHER MATERIALS HEREIN
PROVIDED, WHETHER FOR REPAIR, DIAGNOSIS, MAINTENANCE, MODIFICATION, OR OTHERWISE,
LCD TV
INCLUDING BUT NOT LIMITED TO: ANY INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL
DAMAGES; ANY LOSS OF DATA, PRIVACY OR PROFITS; OR ANY INABILITY TO USE, OR REDUCED
FUNCTIONALITY OF, THE DIGITAL ELECTRONIC EQUIPMENT.
PLEASE READ ALL INSTRUCTIONS IN
THIS MANUAL BEFORE PROCEEDING. PLEASE FOLLOW ALL STEPS IN THE ORDER IN WHICH
THEY ARE DESCRIBED. IF YOU DO NOT HAVE ALL TOOLS AND PARTS AVAILABLE TO YOU, OR ARE
NOT COMFORTABLE PERFORMING THE REPAIRS DESCRIBED HEREIN, DO NOT PROCEED.
Sony EMCS (Malaysia) Sdn. Bhd. HES-M
FAILURE TO FOLLOW THESE INSTRUCTIONS, OR USE THE PROPER TOOLS AND PARTS, MAY
DAMAGE YOUR PRODUCT, LEAD TO PERSONAL INJURY OR CAUSE PROPERTY DAMAGE.
© 2023.12
SYS SET

Advertisement

Table of Contents
loading

Related Manuals for Sony XR-75Z9K

Summary of Contents for Sony XR-75Z9K

  • Page 1 SERVICE MANUAL (TROUBLESHOOTING) ORIGINAL MANUAL ISSUE DATE: 2023.12 DISCLAIMER: USE AT OWN RISK. SONY AND ITS AFFILIATES ARE NOT LIABLE FOR ANY DAMAGE OR INJURY CAUSED TO ANY DIGITAL ELECTRONIC EQUIPMENT, PERSON, OR PROPERTY, WHICH 9-888-908-21 OCCURS DUE TO USE OF THE TOOLS, PARTS, DOCUMENTATION, OR OTHER MATERIALS HEREIN...
  • Page 2 2023/12/21 05:23:12 (GMT+09:00) MODEL LISTS THIS SERVICE MANUAL CONTAINS TROUBLESHOOTING INFORMATION FOR BELOW MODELS: MODEL XR-75Z9K XR-85Z9K SYS SET...

  • Page 3: Table Of Contents

    2023/12/21 05:23:12 (GMT+09:00) TABLE OF CONTENTS Title Page SAFETY NOTES SELF DIAGNOSIS FUNCTION TROUBLESHOOTING SOFTWARE UPDATE & RESET DIAGRAMS HANDLING GUIDE Please refer Service Manual (Disassembly) for below information:  Tools and Equipments  FFC Precautions  Disassembly and Removal Caution  Wire Dressing ...

  • Page 4: Safety Notes

    Replace these components with Sony parts whose part 8) Handle the wires or connectors of the backlight circuit with care. Damaging the numbers appear as shown in this manual or in supplements published by Sony. wires may cause a short circuit.
  • Page 5 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES ※Things to prepare in advance. 10) During the repair, DO NOT leave the POWER ON or Burn-in period for more than 1 hour while the TV is facing down on a cloth. Refer Figure 1. ESD wrist-strap. Figure 1.
  • Page 6 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES ESD cushion / sheet Handle with care. Do not swing Please use a bag containing the board or a special seat Regardless of Good board or Defective board, always put it on 1) Caution for Board handling(Stress).Be sure to observe the following contents. ESD cushion / sheet slowly.
  • Page 7 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES ※Installation example of wrist-strap. Keep vertical position and put in/take out from Box. Always put into ESD bag then place into Box/Container Box Please connect the clip to the metal part of the chassis of the TV with the wristband grounded.
  • Page 8 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES 1-4. Caution About the Lithium Battery. When holding board, do not hit or touch to Plastic part(s) 1) Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 2) Outer case broken battery should not contact to water. After take defective board out from TV, put it into ESD bag.
  • Page 9 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES 1-5. Safety Check-Out Stabilized power supply instrument and isolated voltage transformer: Use too much current capacity and isolated voltage transformer does not need After correcting the original service problem, perform the following safety to use stabilized power supply equipment. checks before releasing the set to the customer:- Specification of RMS voltmeter: Input resistance >...
  • Page 10 2023/12/21 05:23:12 (GMT+09:00) SAFETY NOTES 1-7. How to Find a Good Earth Ground. 1-8. Lead Free Information The circuit boards used in these models have been processed using Lead 1) A cold-water pipe is a guaranteed earth ground; the cover-plate Free Solder. The boards are identified by the LF logo located close to the retaining screw on most AC outlet boxes is also at earth ground.

  • Page 11: Self Diagnosis Function

    2023/12/21 05:23:12 (GMT+09:00) SELF DIAGNOSIS FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the Smart Core Red LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 12 2023/12/21 05:23:12 (GMT+09:00) SELF DIAGNOSIS FUNCTION Self Diag. Quick Reference (Not LED blinking [Record Only]) Error Item Detection Items TU_DEMOD TCON ERR <T> T-CON device I2C communication failure AUD_ERR_I2C <B> Audio amp I2C communication failure TEMP_ERR_I2C <B/H> Temp sensor I2C communication failure TU_DEMOD_I2C <B>...
  • Page 13 2023/12/21 05:23:12 (GMT+09:00) SELF DIAGNOSIS FUNCTION Retry Limitation by Remote/Power Key Smart Core Error Name Retry Permission Times Note Red LED blinking count Number of off/on action for MAIN_POWER MAIN_POWER STDWN_RTRY_LIMIT_MAINPOWR = 1 shutdown is recorded to STDWN_OFFON_CNT_MAIN_POWER. DC_ALERT (5V) STDWN_RTRY_LIMIT = 2 AUD_ERR STDWN_RTRY_LIMIT = 2 LD_ERR...

  • Page 14: Troubleshooting

    2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING Triage Chart Before you make the service call: 1. Confirm the symptom from the customer. 2. Select that symptom from the chart. 3. Bring all the boards and cables listed for that symptom. 4. Follow the troubleshooting charts in the technical guides to isolate the board. 5.
  • Page 15 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.0 No Power No Power Check STBY 3.3V Replace harness C1708 between power Board and Power Board near CN1700 on main Board main board Harness Main Board u-Com Failure DDCON/LDO Main Device Failure SYS SET...
  • Page 16 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure P-on u-com control signal path summary BM5S22 Board LCD Model when mounted on IC420 MAIN BOARD PGOOD_1 3.3V_STBY #pin6 #pin21 DDC : 0.8V_M5_CORE (IC804) LD-Board P_ON_#1 DDCs : 0.9V_BE_DDC_1 (IC4802), 0.9V_BE_DDC_2 (IC4803), #pin18 BL_ON #pin19...
  • Page 17 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure BM5S22 Board LCD Model when mounted on IC420 START Check 12V_MON Check 12.7V_MAIN Line Check VDD R462 Voltage. and 12.7V_24V_AUDIO Line C510 Voltage. Check 3.3V_STBY Line (C1708, CN1700 #9pin) Is the voltage >2.6V? (from Power board).
  • Page 18 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure BM5S22 Board LCD Model when mounted on IC420 Previous page Check P_ON_#2 Check BL_ON CL417 or Change IC420 CL420 or R471 Voltage. Change IC420 P-on u-com #pin17 (IC420) Is the voltage >3.0V? is >3.0V? Check P_ON_HL CL415 or...
  • Page 19 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure P-on u-com control signal path summary BM5S22 Board LCD Model when mounted on IC401 MAIN BOARD PGOOD_1 3.3V_STBY #pin6 #pin9 DDC : 0.8V_M5_CORE (IC804) LD-Board P_ON_#1 DDCs : 0.9V_BE_DDC_1 (IC4802), 0.9V_BE_DDC_2 (IC4803), #pin12 BL_ON #pin7...
  • Page 20 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure BM5S22 Board LCD Model when mounted on IC401 START Check 12V_MON Check 12.7V_MAIN Line Check VDD Check 3.3V_STBY Line R462 Voltage. and 12.7V_24V_AUDIO Line C442 Voltage. (C1708, CN1700 #9pin) Is the voltage >2.6V? (from Power board).
  • Page 21 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.2 No Power U – com Failure BM5S22 Board LCD Model when mounted on IC401 Previous page Check P_ON_#2 Check BL_ON CL417 or Change IC401 CL420 or R471 Voltage. Change IC401 P-on u-com #pin13 (IC401) Is the voltage >3.0V? is >3.0V? Check P_ON_HL CL415 or...
  • Page 22 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.3 No Power – DDCON / LDO P_ON_#1 : P-on u-com IC401 #pin12 P_ON_#2 : P-on u-com IC401 #pin13 Check item summary Board Operation IC Ref Voltage supply Output ref. Enable pin Enable source Fuse Vcc ref. C508 or C514 BM5S22 DC/DC IC418 or IC419...
  • Page 23 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.3 No Power – DDCONs check Please refer page 22 for Reference Number. START Check IC600 / IC610 Check VCC voltage Check VCC voltage Change D800 C801 / CL819 D800 C601 / C666 Is voltage >3V? Is diode, okay? Is voltage >12V? Check 3.3V_STBY.
  • Page 24 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.3 No Power – DDCONs & LDO check Please refer page 22 for Reference Number. START Check fuse F4xx / F6xx/F8xx/F48xx Change Fuse Is fuse, OK? Check VCC voltage 1) Check POWER_ON P-on u-com IC401 #pin10 C4xx / C6xx/C8xx/C48xx (Refer 1.2 No Power U-Com Failure) Is voltage >12.0V? 2) Check Power board...
  • Page 25 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 1.3 No Power – DDCONs & LDO check Please refer page 22 for Reference Number. START Check VCC voltage Check 3.3V_STBY (Power board) C4xx/C8xx Is voltage >3V? Check Enable pin 1.2 No Power U-Com Failure voltage Is voltage >3V? Enable source Change DDCON Or LDO IC...
  • Page 26 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.0 2x LED Blinking – Main Power Error 2x blinking Check “12.7V_MAIN” Voltage > 13.2V? Power /LD* Board BM5S22 : Pin 5~7 of CN1700 Main Board SYS SET...
  • Page 27 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.0 2x LED Blinking – Main Power Error Check Point for BM5S22 Board PWB (A side) Detail CN1700 5,7pin 12.7V_MAIN SYS SET...
  • Page 28 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.1 3x LED Blinking – DC Alert 3x blinking (DC Alert) Check “5.0V_VBUS” Check “12.7V_MAIN” 4.959V<Voltage<5.285V? Voltage > 13.2V? Retry BM5S22 : C611 BM5S22 : Pin 5~7 of CN1700 Power /LD* Board Main Board Error Item Number of STBY LED Blinking Description DC_ALERT Main 5V power failure...
  • Page 29 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.1 3x LED Blinking – DC Alert Check Point for BM5S22 Board PWB (A side) Detail CN1700 5,7pin C611 12.7V_MAIN 5.0V_VBUS SYS SET...
  • Page 30 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.2 3x LED Blinking – AUD_ERR 3x blinking (AUD_ERR) Measure the Speaker Replace impedance by multi-meter Main Board Speaker Harness Main Board Less than 10Ωand More than 3Ω ? Replace Replace Power /LD* Board Power /LD* Board Speaker Speaker Error Item Number of STBY LED Blinking...
  • Page 31 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.3 4x LED Blinking – LD_ERR 4x blinking (LD_ERR) High (3.3V) Check “LD_ERR_DET” Voltage LCD model ? Panel BM5S22 : CL5206 Low (0V) Replace LD board Main Board LD Board Error Item Number of STBY LED Blinking Description LED driver failure/LED voltage protection LD_ERR OLED...
  • Page 32 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.3 4x LED Blinking – LD_ERR Check Point for BM5S22 Board PWB (A side) Detail CL5206 LD_ERR_DET SYS SET...
  • Page 33 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.4 4x LED Blinking – BCM_ERR 4x blinking (BCM_ERR) High (3.3V) Check “BE_LD_RDY” Voltage LCD model ? Panel BM5S22 : CL5223 Low (0V) Replace LD board Main Board LD Board Error Item Number of STBY LED Blinking Description LD IC initialize or I2C communication failure BCM_ERR OLED...
  • Page 34 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.4 4x LED Blinking – BCM_ERR Check Point for BM5S22 Board PWB (A side) Detail CL5223 BE_LD_RDY SYS SET...
  • Page 35 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.5 5x LED Blinking – P_ID_ERR 5-times blinking Replace Replace Main Board Panel (T-con) Check Replace VDD on T-CON Board Power Board Symptom Symptom Power Board = 12V (±10%) improvement improvement Main Board Panel (T-con) Symptom Replace the Harness improve Between Power Board Harness...
  • Page 36 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.6 6x LED Blinking – Backlight_ERR 6x blinking Harness / Connection Symptom Check Check “BL_ERR” Voltage High (3.3V) broken Improvement Harness connection Replace Harness between Power /LD* board to harness BM5S22 : CL5207 Main Board Harness / Connection OK Symptom Low (0V) Improvement...
  • Page 37 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.6 6x LED Blinking – Backlight_ERR Check Point for BM5S22 Board PWB (A side) Detail CL5207 BL_ERR SYS SET...
  • Page 38 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 2.7 7x LED Blinking – TEMP_ERR 2.8 8x LED Blinking – 4KBE_ERR 8x blinking 7x blinking Replace Setting Main Board circumstance is, OK? Set to another Temperature, location, etc. Ventilation, etc. Symptom improvement Replace Main Board Main Board Aging for a few hours Panel SYS SET...
  • Page 39 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 3.1 No Sound – Speaker No Sound Speaker Check ・[Speakers] setting is [TV Speakers]? ・Nothing is connected to Headphone terminal and Bluetooth ? ・Volume setting is not too small? ※ This confirmation way is only for traditional speaker & exciter. In PIEZO Tweeter case, we can confirm OK or NG by listening.
  • Page 40 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 3.2 No Sound – Headphone / Audio / Opt Out No Sound No Sound Headphone out / Audio out Opt out Check [Settings] Check ・[Speakers] setting is [TV Speakers]? ・Volume setting is not too small? ・[Digital Audio Out] is [PCM] ? ・[Digital audio out volume] is [Max]? no sound Replace B-PWB...
  • Page 41 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 3.7 No Sound – Tuner 3.8 No Sound – HDMI 1/2/3/4 No Sound No Sound with normal picture Check the picture Refer to 4.5 HDMI NO PICTURE Only RF tuner input? Check sound by other TV Refer to 3.1 No Sound set which is same model Check Source equipment Is Distributor used ?
  • Page 42 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.0 No Picture No Picture Test pattern Unplug displayed ONT2 board CN2400 & Main board CN6200 Refer to the flow 1.0 Check Smart Core Got Any Normal FFC Harness Behavior and check the power Display? @AC OFF condition. (Blinking) supply problem Then Power ON...
  • Page 43 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING Input Skip Function 4.1 Video Analog Signal Path Non-Detect Detect Input Signal (Typical) (Typical) Video (Side Mini Jack) VIDEO_DET Video 3.3V IC1000 AH9-GPIO56 AL31:CVBS0P CVBS0P AH9:GPIO56 VIDEO_DET Video IC1000 (Side Mini Jack) SYS SET...
  • Page 44 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.2 No Picture Condition Actions to be taken No Picture Refer to IC troubleshooting for further Muffin [IC1000] investigation Problem Video J2800 No Picture Connector Problem Change Connector Check J2800 NG (Vpp: 0V) Check if input OSD J2800 Connection, VIDEO_ is GREY OUT Connectivity...
  • Page 45 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner IC1000 (SoC) IF/AGC Video Analog Demod. TU300* Digital Demod. X_Demod_RST_STBY DVB-T/T2/S/S2 Audio IC3101 DTMB Digital ISDB-T Demod. ATSC 3.0 ISDB-T/S/S3 Decoder JP/ATSC 3.0/Philippines only SYS SET...
  • Page 46 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner Notes: I2C - Parts for I2C SDA line: R3036, R3040, C3005 - Parts for I2C SCL line : R3035, R3039, C3006 RF input no picture / noisy picture Waveform confirmation point • I2C_TU_SDA line: JL3013 •...
  • Page 47 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner *I2C: Please refer Digital Tuning BM5S22 (Top View) C3028 R3037 LNB12V BM5S22 Tuner portion(Top View) BM5S22 (Bottom View) Q604 R643 Q605 JL3019: 3.3V BM5S22 Tuner portion(Bottom View) SYS SET...
  • Page 48 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING Notes: 4.4 No Picture - Tuner - Parts for IFOUT_N line : C3011 FOR ANALOG TUNING - Parts for IFOUT_P line : C3010 - Parts for IFAGC line : R3003 ,R3024, C3023 Insert correct signal in correct ANT terminal. Analog Tuning For LA only Confirm ANT or...
  • Page 49 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner Notes: - Parts for IFOUT_N line : C3011 FOR DIGITAL TUNING 1: @ For TW,CH,HK,LA,PA - Parts for IFOUT_P line : C3010 - Parts for IFAGC line : R3003 ,R3024, C3023 Digital Tuning 1 Insert correct signal in correct ANT terminal.
  • Page 50 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner Notes: I2C - Parts for I2C SDA line: FOR DIGITAL TUNING 2: @ US ATSC3.0 and Philippines R3036, R3040, C3005 - Parts for I2C SCL line : R3035, R3039, C3006 Digital Tuning 2 Waveform confirmation point •...
  • Page 51 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner BM5S22 (Top View) R3024 R3027 BM5S22 Tuner portion(Top View) C3010 C3011 R3035 IFOUT_P IFOUT_N R3036 BM5S22 Tuner portion(Top View) SYS SET...
  • Page 52 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.4 No Picture - Tuner C3023 BM5S22 (Bottom View) RB3001 BM5S22 Tuner portion(Bottom View) JL3012: TU_I2C_SCL R3109 R3116 JL3013: R3040 R3039 C3117 R3117 TU_I2C_SDA R3123 R3114 R3122 R3113 R3121 R3005 R3006 R3120 R3003 BM5S22 Tuner portion(Bottom View) SYS SET...
  • Page 53 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 4.5 No Picture – HDMI 1/2/3/4 No Picture ONT2 board Check with other Check with ① ② FFC (CN2200) other ONT2 board Check HDMIcable Change HDMI cable Change V by One FFC Change ONT2 board （CN2200) Is 8K signal? Connect to HDMI4 OK (Other Input is OK) Check other...
  • Page 54 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 5.0 Key Switch – Buttons Error Switch Module Type On Board Switch Type Check harness Change Main Side key buttons connection between board error Side key buttons error Harness connection issue Main board and switch module Key mechanical parts issue Change switch Change switch Switch module issue...
  • Page 55 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 5.1 IR Remote Commander Error Check harness IR remote commander does connection between Harness connection not respond Main board and Smart issue Core Change harness Main board to Smart Core between Main board to harness issue Smart Core harness Change Smart Core Smart Core issue Change Main board...
  • Page 56 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 5.2 Light Sensor Error Check harness Setting is “ON” Backlight level does not Check UI setting and connection between Harness connection make sure light sensor change when ambient light Main board and Smart issue changed setting is “ON” Core Setting is “OFF”...
  • Page 57 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 5.3 CAS ID Unknown Check harness Backlight level does not Check UI setting and Setting is “ON” connection between Harness connection make sure light change when ambient Main board and Smart issue light changed sensor setting is “ON” Core Setting is “OFF”...
  • Page 58 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.0 Network Malfunction – Ethernet Wired [Network Set-up] >[Wired Set-up] on the TV Connection Fail Connection Results Connection Results Main board Cable Connection Local Access Internet Access Check Failed Failed Failed Check Auto Wired Set-up Local router Proxy setting IP address setting DHCP server Ethernet Cable...
  • Page 59 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.2 Wireless Network Malfunction Wireless Network on the TV Error message or no scan result Is the Wi-Fi radio appear in the network setting? strength too weak Main Board or even No signal? Hardware defect suspected. Check with another Access Point Go to the next page Wi-Fi/BT module...
  • Page 60 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.3 Bluetooth Malfunction Voice Remote doesn’t work Bluetooth Mouse/Keyboard/Controller doesn’t work Bluetooth Speaker/Headphone/ doesn’t work Please refer Voice Remote manual Home > Settings > Bluetooth Settings Bluetooth Mouse/Keyboard/Controller Can turn On BT and Can find the BT devices Bluetooth Speaker/Headphone operation manual Check harness Loose harness...
  • Page 61 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.4 Built in MIC Malfunction Built in mic doesn’t work Check Mic switch Turn on Mic switch on TV Change FFC Cable Check harness connection Connect properly between Main board and between Main board and Receiver Board Receiver board Change Receiver board Change Main board SYS SET...
  • Page 62 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.5 Magnet connector type Camera (Bundle) No image Symptom improvement OK sound Turn on camera No image and OK sound hardware switch on cause : switch Off No image and No sound Camera No image and No sound Symptom Check magnet improvement...
  • Page 63 2023/12/21 05:23:12 (GMT+09:00) TROUBLESHOOTING 6.5 USB connector type Camera (Accessory) No image Symptom improvement Turn on camera OK sound No image and OK sound hardware switch on cause : switch Off Camera No image and No sound No image and No sound USB file play : Symptom Try to play the...

  • Page 64: Software Update & Reset

    2023/12/21 05:23:12 (GMT+09:00) SOFTWARE UPDATE & RESET Caution: DO NOT power off while the update is in progress. USB Update 1:Download USB image and unzip file. 2: Copy zip file to USB memory root folder. 3: USB memory insert TV. 4-b:USB image is not newer soft version. 4-a:USB image is newer soft version.
  • Page 65 2023/12/21 05:23:12 (GMT+09:00) SOFTWARE UPDATE & RESET How to do Factory Data Reset – with UI Method 2) Select System/Device Preferences 3) Select ‘About’ 1) At Home Menu, go to Settings 4) In About, Select ‘Reset’ 5) In Reset, Select ‘Factory data reset’ 7) Select ‘Yes’...
  • Page 66 2023/12/21 05:23:12 (GMT+09:00) SOFTWARE UPDATE & RESET Factory Data Reset – force method (without UI) Press and hold the Power button. (The position of the Power button depends on the model.) AC on. Hold the Power button down for several seconds until the system starts Factory Data Reset. SYS SET...

  • Page 67: Diagrams

    2023/12/21 05:23:12 (GMT+09:00) DIAGRAM 75” Connecting Diagram SYS SET...
  • Page 68 2023/12/21 05:23:12 (GMT+09:00) DIAGRAM 85” Connecting Diagram SYS SET...

  • Page 69: Handling Guide

    2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE Information <FLUSH SURFACE> There are no bezel in front side. Need to be careful in case of handling. Easy to crack panel by pushing SYS SET...
  • Page 70 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 1. Holding Position SYS SET...
  • Page 71 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 2. Carry Condition It is easy to deform by holding in this area SYS SET...
  • Page 72 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 3. Resting Condition Hold long sides Hold short sides SYS SET...
  • Page 73 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 3. Resting Condition Hold short sides SYS SET...
  • Page 74 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 4. Prohibited Method Handle P-mod without gloves Press on P-mod during Assy & Disassy SYS SET...
  • Page 75 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 5. Restricted Area Rear Cover Avoid touch Rear cover hook during P-mod handling SYS SET...
  • Page 76 2023/12/21 05:23:12 (GMT+09:00) HANDLING GUIDE 6. Prohibited Daruma Position Do not use the upper Daruma hole . There is a risk of contact near the FFC SYS SET...
  • Page 77 2023/12/21 05:23:12 (GMT+09:00) Sony EMCS (Malaysia) Sdn. Bhd. English 9-888-908-21 HES-M © 2023.12 SYS SET...
  • Page 78 SERVICE MANUAL (DISASSEMBLY) ORIGINAL MANUAL ISSUE DATE: 2023.12 DISCLAIMER: USE AT OWN RISK. SONY AND ITS AFFILIATES ARE NOT LIABLE FOR ANY DAMAGE OR INJURY CAUSED TO ANY DIGITAL ELECTRONIC EQUIPMENT, PERSON, OR PROPERTY, WHICH 9-888-908-U1 OCCURS DUE TO USE OF THE TOOLS, PARTS, DOCUMENTATION, OR OTHER MATERIALS HEREIN...
  • Page 79 2023/12/21 05:16:18 (GMT+09:00) MODEL LISTS Model Remote Destination XR-75Z9K RMF-TX900U RMF-TX900U XR-85Z9K RMF-TX900U SYS SET...

  • Page 80: Please Refer Service Manual (Disassembly) For Below Information

    2023/12/21 05:16:18 (GMT+09:00) TABLE OF CONTENTS Title Page TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 : XR-75Z9K DISASSEMBLY AND REMOVAL CAUTION BOARD LOCATION WIRE DRESSING EXPLODED VIEW AND PART LIST SECTION 2 : XR-85Z9K DISASSEMBLY AND REMOVAL CAUTION BOARD LOCATION WIRE DRESSING...

  • Page 81: Tools & Equipments

    2023/12/21 05:16:18 (GMT+09:00) TOOLS & EQUIPMENTS 1 LIST OF ITEMS TO PREPARE i. Screwdriver (e.g., #2 Phillips Screwdriver) ii. Multimeter iii. ESD Wrist Straps iv. Metal Washer (Flat) or Coin (for remove Rear Cover) v. Ruler (for remove Rear Cover) vi. Service Manual (Disassembly) (for remove & replace details) Thickness: approx.

  • Page 82: Ffc Precautions

    2023/12/21 05:16:18 (GMT+09:00) FFC PRECAUTIONS ※Caution: DO NOT hold / touch copper side during FFC handling. FFC Insertion Method ESSENTIAL CAUTION INFO THAT MUST BE FOLLOWED BY PRODUCTION FOR ANY FFC INSERTION METHOD STRAIGHT INSERT Connector Connector DO NOT INSERT FFC IN INSERT FFC IN SLANTING CONDITION STRAIGHT CONDITION...
  • Page 83 2023/12/21 05:16:18 (GMT+09:00) FFC PRECAUTIONS Caution for FFC with Housing Connector CAUTION FOR FFC WITH CONNECTOR INSTALLATION AT PANEL SIDE ABNORMAL HANDLING WILL CAUSE CONTACT SHIFTED & FOREIGN PARTICLES ISSUE AS PICTURE BELOW: ZIFF FFC Insertion Caution Close actuator securely to lock Do not push inwards with excessive force.

  • Page 84: Section 1: Xr-75Z9K

    2023/12/21 05:16:18 (GMT+09:00) SECTION 1: XR-75Z9K 1-1. DISASSEMBLY AND REMOVAL CAUTION REAR COVER 1. Remove Cover (7 Covers). STAND COVER R (3L WLF) STAND COVER CR (3L MKY) STAND COVER CL (3L MKY) STAND COVER L (3L WLF) COVER TML V(3L WLF)
