75.0051.01 LZR-FLATSCAN S 20231227
®
LZR
-FLATSCAN S
COMPACT LASER SENSOR FOR INDUSTRIAL
DOORS, GATES, AND BARRIERS
MAX. DETECTION RANGE: 18' × 18'
User's Guide for product version 0101 and higher.
See product label for serial number.
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for LZR FLATSCAN S
Summary of Contents for LZR FLATSCAN S
- Page 1 DOORS, GATES, AND BARRIERS MAX. DETECTION RANGE: 18' × 18' Visit website for available languages User’s Guide for product version 0101 and higher. of this document. See product label for serial number. 75.0051.01 LZR-FLATSCAN S 20231227 Page 1 of 16...
- Page 2 DESCRIPTION Flatscan S is a compact, single-curtain, laser sensor with an opening angle of 90°. The sensor provides high- resolution coverage with 400 spots and configurable object size detection according to the given application. The laser sensor is CLASS 1 certified device according to IEC 60825-1. The visible laser beams are CLASS 2, and will automatically time out during normal operation.
-
Page 3: Technical Specifications
Specifications are subject to change without prior notice. All values measured in specific conditions. LED SIGNALS COLOR BEHAVIOR LED flashes detection power on LED flashes quickly error LED LED flashes slowly no power LED is off 75.0051.01 LZR-FLATSCAN S 20231227 Page 3 of 16... -
Page 4: Installation And Maintenance Notes
The installer can activate the visible beams if needed. CAUTION! Use of controls, adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure. Ensure compliance with applicable local, national, and international codes and standards. Page 4 of 16 75.0051.01 LZR-FLATSCAN S 20231227... - Page 5 " deviation at 10' distance. Please ensure that the curtain is in the correct position. Laser beam Visible spot Distance (ft) b (in) a (in) 3.28 0.49 0.06 6.56 0.98 0.12 9.84 1.48 0.18 13.12 1.97 0.24 16.40 2.46 0.30 a= width 75.0051.01 LZR-FLATSCAN S 20231227 Page 5 of 16...
- Page 6 A mounting bracket is required for FLATSCAN S installation. The instructions in this User's Guide describe the use of FLATSCAN S Mounting Bracket. a. Use the sensor mounting screws to secure the sensor to the bracket in the correct position (i.e. laser window at 90°).
-
Page 7: Field Positioning
NOTE: See page 5 for more information on the visible laser beams. LOOSEN = FIELD IN TIGHTEN = FIELD OUT 75.0051.01 LZR-FLATSCAN S 20231227 Page 7 of 16... - Page 8 When the approaching area is sloped, be sure that the sensor tilt angle closely matches the slope angle to ensure that the intended target can be detected at the specified distance. DRAFT DRAFT Page 8 of 16 75.0051.01 LZR-FLATSCAN S 20231227...
- Page 9 When the approaching area is sloped, be sure that the sensor tilt angle closely matches the slope angle to ensure that the intended target can be detected at the specified distance. DRAFT DRAFT 75.0051.01 LZR-FLATSCAN S 20231227 Page 9 of 16...
- Page 10 NOTE: See page 5 for more information on the visible laser beams. LOOSEN = FIELD IN TIGHTEN = FIELD OUT Page 10 of 16 75.0051.01 LZR-FLATSCAN S 20231227...
- Page 11 NOTE: If the Detection Field size is changed from the default, you must perform the appropriate teach-in for the given field. max. 30s FIELDS 1 & 2 (RECOMMENDED) max. 30s FIELD 1 max. 30s FIELD 2 max. 30s BACKGROUND BACKGROUND must be turned on. 75.0051.01 LZR-FLATSCAN S 20231227 Page 11 of 16...
- Page 12 = FIELD 2, side 1 = FIELD 1, side 2 = FIELD 2, side 2 The FLATSCAN S sensor is configured to understand metric measurements. If necessary, please convert your measurements from imperial to metric by multiplying your imperial measurements by 0.3.
- Page 13 100 ms 200 ms 300 ms 400 ms 500 ms 600 ms 700 ms 800 ms 900 ms DETECTION Turns on/off detection fields 1 or 2. AREA ACTIVATION field 1 & field 1 field 2 field 2 75.0051.01 LZR-FLATSCAN S 20231227 Page 13 of 16...
- Page 14 * Do not set background to ON when sensor is mounted in a horizontal orientation. If done, this will cause the sensor to go into error mode. LED ACTIVATION LED off LED on IMPORTANT: Ensure compliance with applicable local, national, and international codes and standards. Page 14 of 16 75.0051.01 LZR-FLATSCAN S 20231227...
-
Page 15: How To Use The Remote Control
FULL PARTIAL If unused for 30 minutes, the sensor will time out of the remote control session. Cut and restore power supply. The remote control session is accessible again within 30 minutes. 75.0051.01 LZR-FLATSCAN S 20231227 Page 15 of 16... -
Page 16: Troubleshooting
AAADM safety information label (e.g. ANSI/DASMA 102, ANSI/DASMA 107, UL294, UL325, and International Building Code). Verify that all appropriate industry signage, warning labels, and placards are in place. Tech Support: 1-800-407-4545 | Customer Service: 1-800-523-2462 General Tech Questions: techservices-us@BEAsensors.com | www.BEAsensors.com Page 16 of 16 75.0051.01 LZR-FLATSCAN S 20231227...
