- Page 1 Operating Instructions 3-447-212-03 1/11.23 Cable Tester KE7000 Ethernet FlexiTest Gossen Metrawatt GmbH | Südwestpark 15 | 90449 Nürnberg, Germany Phone: +49 911 8602-0 | Fax: +49 911 8602-669 info@gossenmetrawatt.com | www.gossenmetrawatt.com...
-
Page 2: Safety Instructions
Safety Instructions Read and follow these instructions carefully and completely in order to ensure safe and proper use. The instructions must be made available to all persons who use the instrument. Keep for future reference. General • Observe and comply with all safety regulations which are applicable for your work environment, in particular relevant safety regulations in accor- dance with DIN VDE 0100, DIN VDE 0800 and DIN VDE 0805. - Page 3 Operating Conditions • Do not use the instrument and its accessories after long periods of storage under unfavorable conditions (e.g. humidity, dust or extreme temperature). • Do not use the tester and its accessories after extraordinary stressing due to transport. •...
-
Page 4: Liability And Guarantee
Applications Please read this important information! Intended Use / Use for Intended Purpose The KE7000, hereinafter referred to as the instrument, is a simple test instru- ment for LAN, telecommunications and patch cables in the fields of IT and telecommunications. Unshielded or shielded cables with twisted pairs and RJ-11 or RJ-45 con- nectors (UTP, STP, FTP, 568A, 568B, USOC) can be tested. - Page 5 Instructions Information Concerning these Instructions Read these instructions carefully and attentively. They contain all necessary information for safe use of the instrument. Comply with them in order to pro- tect yourself and others from injury, and to avoid damaging the instrument. The latest version of these instructions is available on our website: https://www.gossenmetrawatt.de/en/services/download-center/ Errors and Suggestions for Improvement...
-
Page 6: Optional Accessories
The Instrument Scope of Delivery 2 ea. KE7000 1 ea. pouch Optional Accessories Some measurements/tests necessitate optional accessories. • RJ-45 to coax adapter (Z170A) for testing coaxial cables: Adapter set consisting of 2 ea. RJ-45 to BNC plug adapter and 2 ea. BNC to F female plug adapter Instrument Overview RJ-11/RJ-45 socket (on top) - Page 7 Symbols on the Instrument Warning concerning a source of danger (attention: observe documentation!) European conformity marking The test instrument may not be disposed of with household trash (see Page 14). Technical Data UTP (up to 4 pairs), STP, FTP, 568A, 568B, USOC, coaxial* Cable Type * only with optionally available adapter...
-
Page 8: Initial Startup
Initial Startup The instruments are powered by means of 9 V batteries (not included). Before inserting the batteries, disconnect all cables and switch the instrument off. Only use batteries which comply with the applicable specifications. The battery compartment is located on the back of the instrument. Open the battery compartments with a Phillips PH2 screwdriver, insert the batteries and then reclose the battery compartments. -
Page 9: Performing Tests
Performing Tests 2 instruments are required for testing. UTP (up to 4-pair), STP, FTP, 568A, 568B, USOC and coaxial cables can be tested for continuity, interruption, reversal, short-circuit, multiple faults and shield continuity. Procedure Ensure that cables are voltage-free. Connect one end of the cable under test to one of the instruments and the other cable end to the other instrument via the RJ-11/RJ-45 sockets. - Page 10 Interference Voltage Protection The instrument is protected against inadvertent contact with interference volt- age of up to 60 V DC . If (interference) voltage is inadvertently applied, this is indicated by the instru- ment (see examples below). The following screen is displayed until interfer- ence voltage has been eliminated.
- Page 11 Results (examples) The results are shown directly at the display. RJ-11 cable, no errors, RJ-45 cable, no errors, Coaxial cable, no errors, wires 3 through 6 all wires and shield wires 1 and 2 connected connected. connected. (pin 1: inner conductor, pin 2: shield).
-
Page 12: Storage And Transport
Storage and Transport Caution: Improper storage results in damage to the product. Store the instrument in its packaging and protect it from environmental influences. Caution: Improper transport results in damage to the product. Transport the instrument in its packaging and protect it from environ- mental influences. - Page 13 10. Contact, Support and Service Gossen Metrawatt GmbH can be reached directly and hassle-free – we have a single number for all of your needs! Whether you require support or train- ing, or have an individual inquiry, we can answer all of your questions here: +49 911 8602-0 Monday through Thursday: 8 a.m.
-
Page 14: Disposal And Environmental Protection
11. Disposal and Environmental Protection Proper disposal makes an important contribution to the protection of our en- vironment and the conservation of natural resources. Caution: Environmental Damage Improper disposal results in environmental damage. Fol- low the instructions concerning return and disposal in- cluded in this section. - Page 15 Packaging Materials We recommend retaining the respective packaging materials for the case that you might require servicing or calibration in the future. Warning: Danger of Asphyxiation Resulting from Foils and Other Packaging Materials Children and other vulnerable persons may suffocate if they wrap themselves in packaging materials, or their components or foils, or if they pull them over their heads or swallow them.
- Page 16 © Gossen Metrawatt GmbH Prepared in Germany • Subject to change, errors excepted All trademarks, registered trademarks, logos, product names and company names are the property of their respective owners.
